Parts List

Below is a partial list of applied rooftop unit replacement
parts. Contact a local sales representative for additional
information
Table 26:
Component
designation
MCB Main control board
CCB1 Auxiliary cooling control board (DX Circuit #1 or generic condenser)
CCB2 Auxiliary cooling control board (DX circuit #2)
EHB1 Auxiliary electric heat control board
ERB1 Auxiliary energy recovery control board
– RS-485 communication module (for auxiliary control boards)
– Standoffs for mounting RS-485 communication module (PN 060006202) onto auxiliary control board (PN
112026101)
– Keypad/display
– Keypad, main control board cable
ZNT1 Zone temperature sensor with tenant override
Zone temperature sensor with tenant override & remote setpoint adjustment (SCC units only)
DAT Discharge air temperature sensor (50 ft cable length-field cut to length)
ENT Entering fan air temperature sensor (50 ft cable length-field cut to length)
OAT Outside air temperature sensor (50 ft cable length-field cut to length)
RAT Return air temperature sensor (50 ft cable length-field cut to length)
SPS1 Static Pressure sensor: duct, No. 1
SPS2 Static pressure sensor: duct, No. 2
Static pressure sensor: building (space) pressure
T2 Transformer: 115/24 VAC
T3 Transformer: 115/24 VAC
T9 Transformer: 115/24 VAC
HUM1 Humidity sensor: wall mount
Humidity sensor: duct mount
PC5 Dirty filter switch: first filter section
PC6 Dirty filter switch: final filter section
PC7 Airflow proving switch
DHL Duct high limit switch
OAE Enthalpy control: electromechanical
Enthalpy control: electronic (used with RAE)
RAE Return air enthalpy sensor (used with electronic OAE)
SD1 Smoke detector: supply air
SD2 Smoke detector: return air
– BACnet MS/TP communication module (RS-485)
– BACnet/IP communication module (IP cable 10BASET)
– L M space comfort controller (SCC) communication module
ON ARK
– L M discharge air controller (DAC) communication module
ON ARK
– 5 VDC precision power supply
– Serial port ribbon cable
– MCB battery
– MCB connector repair kit
Daikin IM 696-4
Description Daikin part number
060006101
112026101
(replaces 106102701)
112026101
(replaces 106102701)
112026101
(replaces 106102701)
112026101
(replaces 106102801)
060006202
048166707
060006301
111044601
111048101
111048102
060004705
060004705
060004705
060004705
049545007
049545007
049545006
060004601
060004601
060630801
067294901
067295001
065493801
065493801
060015801
065493801
030706702
049262201
049262202
049025001
049025001
060006202
060006201
060006203
060006204
111049610
111047201
BR2325
300036605
