attribute name and the applicable settings for each. The factory
default values are shown in bold font.
Table 22: Software configuration string
Configuration
Description
string position
1 Unit Type
2 Cooling Type
Compressoriz
3 ed cooling
configuration
Generic
4 condenser
stages
Low ambient 0 No
5
Condenser
*
6
fan type
7 Damper type
8 DesignFlo
9 Heating type
Max heating
10
stages
11,12, and 13 Max heat rise Three digits (default = 100)
Discharge fan
14
type
Return fan
15
type
Daikin IM 696-4
Values (default in bold)
0 RA zone control
1 RA DAT control
2 100 OA zone control
3 100 OA DAT control
0 None
1 Compressorized clg
2 Chilled water (2-wire FB)
A Chilled water (3-wire FB)
0 2 comp/2 stage
1 2 comp/3 stage
2 2 comp/4 stage
3 2 comp/6 stage
4 3 comp/4 stage
5 4 comp/4 stage
6 6 comp/6 stage
7 4 comp/8 stage
8 Generic condenser
1 – 8 Stages (Default = 8)
1 Yes
0 No evap cond control
1 2 cond fans/cir– ABB VFD
2 2 cond fans/cir– Graham VFD
3 2 cond fans/cir– Reliance VFD
4 2 cond fans/cir– no VFD
5 3 cond fans/cir– ABB VFD
6 3 cond fans/cir– Graham VFD
7 3 cond fans/cir– Reliance VFD
8 3 cond fans/cir– no VFD
0 None
1 Single position 30% (2-wire FB)
2 Single position 100% (2-wire FB)
3 Economizer (2-wire FB)
A Single position 30% (3-wire FB)
B Single position 100% (3-wire FB)
C Economizer (3-wire FB)
0 No DesignFlo
1 018–030 (800) (non-precision PS)
2 036–040 (802) (non-precision PS)
3 045–075 (047) (non-precision PS)
4 080–135 (077) (non-precision PS)
A 018–030 (800) (precision PS)
B 036–040 (802) (precision PS)
C 045–075 (047) (precision PS)
D 080–135 (077) (precision PS)
0None
1F BP ctrl
2Multi staged
3Modulated gas, 3–1 (2-wire FB)
4Modulated gas, 20–1 (2-wire FB)
5Steam or hot water (2-wire FB)
6Single stage gas
7Single stage electric
AModulated gas, 3–1 (3-wire FB)
BModulated gas, 20–1 (3-wire FB)
CSteam or hot water (3-wire FB)
1 – 8 stages (default = 1)
0 Constant volume
1 Variable inlet vanes
2 Variable freq drive
0 Constant volume
1 Variable inlet vanes
2 Variable freq drive
3 No Return fan
4 Propeller exhaust
Table 22: Software configuration string (continued)
Configuration
Description
string position
Return/
exhaust fan
16 capacity
control
method
Second
17 pressure
sensor type
Entering fan
18
temp sensor
Energy
19
recovery
20 Final filter
Heating
21
configuration
Cooling
22
configuration

Main Control Board (MCB) Data Archiving

All MCB control parameters and the real time clock settings
are backed up by the MCB battery when power is removed
from the MCB. In the event of a battery failure, the MCB
includes a data archiving function. Once a day, just after
midnight, all the MCB control parameter settings are archived
to a file stored in the MCB FLASH memory. If the MCB is
powered up with a low or defective battery (or with the battery
removed), the most recently archived data is restored to the
controller.
Note – When this archived data restoration process occurs, it
increases the controller start up and initialization time
period by approximately 75 seconds.
Service Information
Values (default in bold)
0 None
1 Tracking
2 Bldg press
3 Position
0 None
1 Duct
2 Bldg
0 No
1 Yes
0 None
1 Constant speed wheel
2 Variable speed wheel
0 No
1 Yes
0 Draw through preheat
1 Draw through reheat
2 Blow through
0 Draw through
1 Blow through
33
