A program "runs" in either mode, but can only be downloaded and debugged when the
RCM3750 is in the program mode.
Refer to the
Rabbit 3000 Microprocessor User's Manual
gramming port and the programming cable.

4.3.2 Standalone Operation of the RCM3750

The RCM3750 must be programmed via the RCM3700 Prototyping Board or via a similar
arrangement on a customer-supplied board. Once the RCM3750 has been programmed
successfully, remove the programming cable from the programming connector and reset
the RCM3750. The RCM3750 may be reset by cycling the power off/on or by pressing the
button on the Prototyping Board. The RCM3750 module may now be removed
RESET
from the Prototyping Board for end-use installation.
CAUTION: Power to the Prototyping Board or other boards should be disconnected
when removing or installing your RCM3750 module to protect against inadvertent
shorts across the pins or damage to the RCM3750 if the pins are not plugged in cor-
rectly. Do not reapply power until you have verified that the RCM3750 module is
plugged in correctly.
User's Manual
for more information on the pro-
31
