B.1.8 Jumper Configurations
Figure B-10 shows the header locations used to configure the various RCM3700 Prototyp-
ing Board options via jumpers.
JP1
JP2
Battery
JP4
JP8
JP5 JP6 JP7
Figure B-10. Location of RCM3700 Prototyping Board Configurable Positions
User's Manual
105
