The programming port may also be used as a serial port via the
connector on the
DIAG
programming cable.
In addition to Serial Port A, the Rabbit 3000 startup-mode (SMODE0, SMODE1), status,
and reset pins are available on the programming port.
The two startup mode pins determine what happens after a reset—the Rabbit 3000 is
either cold-booted or the program begins executing at address 0x0000.
The status pin is used by Dynamic C to determine whether a Rabbit microprocessor is
present. The status output has three different programmable functions:
1. It can be driven low on the first op code fetch cycle.
2. It can be driven low during an interrupt acknowledge cycle.
3. It can also serve as a general-purpose CMOS output.
The reset pin is an external input that is used to reset the Rabbit 3000.
Refer to the
for more information.
Rabbit 3000 Microprocessor User's Manual
User's Manual
29
