The Data Log mode

meriGauge plus System User Manual
info@Meriam-Direct.com
View the "BATT %" before you begin
Data Log Lite runs up to one hour.
Note: Do not start data log if the outline of the battery
icon is flashing.
Only one data set at a time
Data Log Lite can record and hold only one data set at a time.
Note: When you press and hold the
appears in the LCD display, a new data set
DATA LOG
begins to record over the existing data set.
Start the data logging process
1. Press the Display key until you see Data Log appear in
the LCD display.
2. Press and hold the
Zero
The data log symbol starts to flash indicating it is
recording data. Data Log Lite records data every 15
seconds for one hour.
3. –COMPLETE—appears after one hour.
Note: Auto Off is suspended during data logging. If you
selected 5 Minutes for Auto Off, then meriGauge plus
remains on for one hour and 5 minutes and then turns
off.
Complete the data logging process
Here are some of the actions that can complete the data
logging process before the one hour:
•
Press and hold the
Zero
• Press the key to turn off the meriGauge plus.
Power
• Remove the meriGauge plus from a sensor.
• Connect the meriGauge plus to the meriLink.
April 2016
key while
Zero
key until you see STARTING--.
–
key until you see --STOPPING--.
