Accuracy Statement For Merisense (Ms700X-Xxxxxx) - Meriam meriGauge plus User Manual

9R479-IR

Accuracy Statement for meriSense (MS700x-xxxxxx)

Range limits
Sensor pressure ranges
Media compatibility
Temperature limits
Operating temperature
Process temperature
Warm-up time
meriGauge plus System User Manual
info@Meriam-Direct.com
MS700 meriSense
Contact sales@meriam.com
information about the following part numbers:
+ 1 216 281 1100 or (800) 817-7849.
MS700 meriSense sensors
Part number Ranges
ZMS700-AI0015
ZMS700-CI0015 –15 psi to 15 psi
ZMS700-AI0030
ZMS700-CI0030 –15 psi to 30 psi
ZMS700-AI0100
ZMS700-CI0100 –15 psi to 100 psi
ZMS700-CI0300 –15 psi to 300 psi
ZMS700-CI0500 –15 psi to 500 psi
ZMS700-CI1000 –15 psi to 1 000 psi
ZMS700-CI3000 –15 psi to 3 000 psi
•
Includes all combined effects of linearity, repeatability,
hysteresis, stability, and temperature over the specified
calibrated temperature range for one year.
•
Not recommended for continuous use
below 0.02 psi absolute.
316 SS
–10 °C to 50 °C (14 °F to 122 °F)
•
Up to 95 % RH non-condensing.
•
No change in accuracy over operating temperature range.
•
Gauge must be zeroed to achieve rated specification.
–10 °C to 50 °C (14 °F to 122 °F)
Five (5) minutes.
to purchase these parts and for more
Type
0 psi to 15 psi Absolute
Compound
0 psi to 30 psi Absolute
Compound
0 psi to 100 psi Absolute
Compound
Compound
Compound
Compound
Compound
April 2016
10
1.888.610.7664
