User Manual V0.4
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This Device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Caution :
Any changes or modifications in construction of this device which are
not expressly approved the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE :
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications, However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-
Consult the dealer or an experienced radio/TV technician for help.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Disposal of used batteries according to the general recommendations against the
environmental pollution.
WEBGATE INC.
CAUTION
eDVR DS412
1 / 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WebGate DS412
Summary of Contents for WebGate DS412
-
Page 1: Fcc Compliance Statement
User Manual V0.4 eDVR DS412 FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This Device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 2: Important Notice
For DS412 cleaning, gently wipe the outside with a clean dry cloth. 3. Be sure to use a DC adapter that is provided by Web Gate Inc. Connecting DS412 directly to a AC current, may cause electric damages to DS412. - Page 3 User Manual V0.4 eDVR DS412 EDVR Manual Version : 0.4 Making Date : January, 28, 2003 Revision Date : February, 25, 2003 1. Install & Run 1.1. Descriptions A. Front Panel DIGITAL VIDEO RECODER AX-100L ALARM MENU HELP WEBGATE IEEE1394...
- Page 4 User Manual V0.4 eDVR DS412 SEARCH : To search the recorded image in Playback mode (5) Direction/Replaying Button MENU : To set PTZ and configuration menu ENTER : To confirm the selected menu HELP : EXIT : To exit form the selected menu Arrow key : Replay function or menu moving function B.
- Page 5 User Manual V0.4 eDVR DS412 1.2. Connect Device A. Connect Video B. Connect Monitor C. Connect Ethernet D. Connect Audio E. Connect Power & Run 2. Monitor It is to monitor real time image. Ch. 1~4 are for analogue image input via BNC cable, and Ch. 5~16 are for digital image input of network camera via network.
- Page 6 User Manual V0.4 eDVR DS412 (1) Press the [MULTI] button for viewing several channels simultaneously. (2) Whenever pressing the [MULTI] button, 4-9-16-13 split screens are chang ed in due order. (3) In quad-split mode, images of channels 1 to 4 show. Channels 1 to 9 in 9-split mode, chann els 1 to 16 in 16-split mode, and channels 1 to 12 in 13-split mode.
- Page 7 User Manual V0.4 eDVR DS412 (5) Press the [MENU] button. (6) PTZ menu (PAN/TILT, ZOOM/FOCUS, Preset, Preset Save) shows. (7) Press the [ENTER] button after selecting one. (8) When selecting ‘PAN/TILT’ or ‘ZOOM/FOCU S’, [UP/DOWN] arrow key is for ‘TILT/FOCUS’...
- Page 8 User Manual V0.4 eDVR DS412 (3) ▌▌ (PAUSE) : To pause replaying (4) ►►(FAST FORWARD) : Whenev er pressing the button, replaying speed increases gradually (x1, x2, x4, x8, x16) ◄◄ (FAST REWIN D) : Whenever pressing the button, reverse replaying speed increases...
- Page 9 User Manual V0.4 eDVR DS412 (3) The matching point between horizontal and vertical bar is selecting value. (4) Or enter the related numbers in order of horizontal/vertical. (For example, i n order to select “N”, press [4] and [3] button.) Press the [ENTER] button in ord er to confirm the selected value.
- Page 10 User Manual V0.4 eDVR DS412 2) Network menu Refresh: If selecting it, all local cameras are listed up. If using this menu, it is needless to enter each local camera’s IP address manually in “Login” menu. D. Normal Recording * There are four types (Weekday Day/Weekday Night/Weekend Day/Weekend Night).
- Page 11 User Manual V0.4 eDVR DS412 F. Relay * There are four types(Weekday Day/Weekday Night/Weekend Day/Weekend Night). Setup: It can be set from Relay1 to Relay4. It is for sending digital output signal in case of alarm triggered event(MD or Sensor).
- Page 12 - WRS Interval/URL/Group: It is to set server registering interval, server’s URL, or configured group ID. - Status: It shows xDSL’s accessing status. * Currently(25, February), eDVR supports only Ethernet, not xDSL. After upgrading xDSL function, WebGate will let you know it instantly. WEBGATE INC. 12 / 12...
- Page 13 User Manual V0.4 eDVR DS412 6)-3 Server - Monitoring Port/Playback Port: DVR use 8001 port as Monitoring port and 8105 port as Playback port. When selecting one for changing, the related dialogue box is indicated. - Firewall/Port: When using Firewall, set is as ‘Yes’ and enter its port.
