WebGate UHN1600-H2 User Manual

Hd-cctv nvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

HD-CCTV NVR
Digital Video Recorder
UHN Series
User's Manual
(EN Rev 1.0)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHN1600-H2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WebGate UHN1600-H2

Summary of Contents for WebGate UHN1600-H2

  • Page 1 HD-CCTV NVR Digital Video Recorder UHN Series User’s Manual (EN Rev 1.0)
  • Page 2 HD-CCTV NVR Install & User Guide HD-CCTV NVR Manual. Thank you for purchasing a Network Video Recorder. Before installation or operation please become familiar with the user manual and other referenced manuals mentioned in the booklet. User manual, software and hardware described here are protected by copyright by law. With the exception of copying for general use within fair use, copying and reprinting of the user manual, either partially or in entirety, or translating it into any another language without the consent of our Corporate office is strictly prohibited.

  • Page 3: Table Of Contents

    Contents Introduction 5 Warning 5 Main Specification by Models 6 Key Features 7 Components 9 Product Description 10 Installation 15 Connecting other devices 19 Setup Wizard 22 Usage 24 FUNC Menu 24 Menu structure 24 Monitoring 26 Remote monitoring & control 30 Playback, Search and Copy 32 Copy 34 Configuration 35...
  • Page 4 Mobile Application 77 registration method for iOS app 77 Register method for Android app 78 Mobileviewer 78 Appendix 79 Problem solving [FAQ] 79 Compatible HDD 80 Factory default set-up values 80 Product specification 82 Product Dimension 86...

  • Page 5: Introduction

    Introduction Warning Warning  Please do not bend or press power cord by force which could lead to fire.  Be careful not to pull or plug with wet hands to avoid fire or electric shock.  Must connect the power cord to a grounded outlet. It may cause electric shock and injury, and may cause product malfunction.

  • Page 6: Main Specification By Models

    Main Specification by Models 64 channel 16 channel NVR 36 channel PoE NVR 64 channel NVR HOT SWAP NVR Function UHN1600-H2 UHN3616P-H4 UHN6400-H8 UHN6400-H16S SATA*2 SATA*4 SATA*8 + eSATA*2 SATA*16 + eSATA*1 HDD Hot Swap Max Resolution of IP Camera...

  • Page 7: Key Features

    Key Features Products support IP camera supporting Onvif Profile-S or WESP. Products support real-time live monitoring, real-time recording/playback, backup, push alarm and audio of connected IP camera. Other DVR’s video channel can be treated as an IP camera and NVR supports all NVR functions to other DVR’s video channel.
  • Page 8 Voice Recording Supports real time voice input and recordinig function.  Real time 1ch voice input and recording function  Input : 1ch RCA, Output : 1ch RCA (Rear), 1ch HDMI (Rear)  Audio recording and playback can be performed simultaneously Search and Playback Various useful functions for search &...

  • Page 9: Components

    Components Please check the below to make sure you have every part. 16 CHANNEL NVR / 36 CHANNEL PoE NVR / 64 CHANNEL NVR SW & Manual CD Mouse Quick guide 19” Rack bracket HDD mounting screw Adapter & Power Cord (*) &...

  • Page 10: Product Description

    Product Description 16 CHANNEL NVR Front view Part name Function description Shows record status and it turns on while recording Shows network connection status and it turns on if network is connected It turns on when power is ON USB 포트 USB port for USB memory or mouse.
  • Page 11 36 CHANNEL PoE NVR Front view function description part name Shows record status and it turns on while recording Shows network connection status and it turns on if network is connected It turns on when power is ON USB port USB port for USB memory or mouse.
  • Page 12 64 CHANNEL NVR Front view function description part name Shows record status and it turns on while recording Shows network connection status and it turns on if network is connected It turns on when power is ON USB port USB port for USB memory or mouse. Rear view part name function description...
  • Page 13 64 CHANNEL HOT SWAP NVR Front view part name function description ALARM Shows event status and it turns on if event is occurred It turns on when power is ON LAN1 Shows network connection status of LAN1 and it turns on if network is connected LAN2 Shows network connection status of LAN2 and it turns on if network is connected 1~16...
  • Page 14 part name function description ALARM IN: External sensor input port AUDIO OUT/AUDIO IN AUDIO IN : Audio input connection terminal AUDIO OUT : Speaker output terminal Ground Connection Connection terminals that connects NVR to an outside device Power Input AC100V~AC240V power cord socket. If power cord is not connected to an grounded outlet, it may cause damage or malfunction of the product.

  • Page 15: Installation

    Installation Check settings This NVR is high quality security device with a high capacity built-in HDD and important curcuits. Before installation, please read carefully below recommendations as high internal temperature of the product can lead to damages and shorten product life cycle. Power ground Must connect the power cord to the grounded outlet.
  • Page 16 HDD installation 16 CHANNEL NVR 36 CHANNEL PoE NVR...
  • Page 17 64 CHANNEL NVR...
  • Page 18 64 CHANNEL Hot Swap NVR...

  • Page 19: Connecting Other Devices

    Connecting other devices VIDEO Output (HDMI) connection Support HDMI monitor having 1920X1080 and UHD/4K (3840X2016) resolution. Also, NVR can automatically detect the max resolution of HDMI monitor when the HDMI resolution is set to “UHD/4K (Preferred)”. So, if the monitor supports only FHD, the video output resolution will be FHD. If the monitor supports UHD/4K, the video output resolution will be UHD/4K.
  • Page 20 Connecting eSATA Device If external eSATA storage is used, it can be connected to a rear eSATA port. Additional power for eSATA device will be required as NVR doesn’t supply power. <Note> 1. Check compatibility of eSATA with NVR as not all eSATA are compatible with NVR. 2.
  • Page 21 Connecting RS485 K/B serial port to external device Keyboard device can control all functions of NVR and IP PTZ camera connected to NVR when Keyboard device is connected to RS485 K/B serial port of NVR. Also, multiple keyboards connected in parallel can be used. Keyboard can select NVR’s ID and can control specific NVR among parallel connected NVRs.

  • Page 22: Setup Wizard

    Setup Wizard Setup Wizard can help user setup “language, network, DDNS, time, harddisk, record mode” with ease. It runs automatically when NVR boots initially. User can run Setup Wizard on “Menu > System > Tool > Setup Wizard”. Start Select language and choose whether to use Setup Wizard or not. Network Set up IP address of NVR or skip network setup.
  • Page 23 Time and time zone Setup time, standard time zone and daylight saving time (DST). Network(NTP) autotime synchronizing 1) In case NVR is connected to internet – In use 2) In case NVR is not connected to internet – Not in use Daylight saving time(DST, summer time) 1) DST saving time is used –...

  • Page 24: Usage

    Usage FUNC Menu All NVR functions can be controlled by using Mouse. To open FUNC menu, click the mouse’s right button at live or playback screen. FUNC menu at Live screen Search - Recording data Search/Playback  Copy – Copy recorded data ...
  • Page 25 Menu Structure Press [MENU] key on front panel or click [Main Menu] button under FUNC menu to enter the setup menu. To exit menu, press “X”. Main menu The selected tab is shown in bright color and the sub-menu box will show the chosen Sub-menu Selected sub-menu will disply the chosen item and the related setting will be shown.

  • Page 26: Monitoring

    Monitoring Basic screen The basic screen will be maximum multi screen NVR supports and if rebooted after multi-screen mode has been modified, previous multi-screen mode will be shown. (NVR default account admin / 12345) <Note> The default password is very weak for security. It is highly recommended that user must change the password periodically.
  • Page 27 Image popup will be performed after setting image popup “enable” and selecting event source (sensor, motion detection, no video, text). To use flame detection function, Webgate’s flame detection camera (N1080BL-AF-F2) should be connected. After connection, NVR can automatically detect the sensor as a flame detector. (It is not possible to change the sensor type by manually.)
  • Page 28 Snapshot picture Please click on Snapshot while image is Freeze in single live monitoring. Copy them to USB too. Click FUNC menu -> Tool -> Snapshot to copy image to USB memory without stopping or pausing image. Instant PTZ If Instant PTZ in Tool menu is set activated, PTZ mode will be on automatically upon single channel, which PTZ function is set.
  • Page 29 Patrol On Select the patrol number and click “On”. Patrol Off Refer the patrol status and select the patrol number which you want to off. And click “Off”. <Note> Focus may not be controlled for Onvif IP camera channel. Camera Setup This menu is used to enter the OSD menu of connected camera.

  • Page 30: Remote Monitoring & Control

    Remote monitoring & control Users can connect NVRs, control and monitor it remotely by using Control Center (CMS program) Installation of Control Center Execute “Control Center Setup vx.x.x.exe” to install the Control Center. Start of Control Center After installation is completed, click “Control Center Monitor” icon and execute it. (ID: admin / Password: admin) Screen configuration of Control Center Item...
  • Page 31 Add Unit Click [Add] icon on the toolbar or execute [Add Unit] by clicking mouse right button at “My Units”. 1) Select “URL/IP Adress” 2) Enter proper IP address and Port, then click [Find] button. If the NVR is located inside local network, you can easily find the NVR by clicking [Auto Detect] button.

  • Page 32: Playback, Search And Copy

    Playback, Search and Copy Playback Screen Composition name function description Time Search Set the time to want to play. Use buttons to control the playback. ▶: Forward x1 playback Playback control ◀: Backward x1 playback button ll : Pause ▶▶: Step forward during pause state, or playbacak speed changing during playback state. ◀◀: Step reverse during pause state, or reverse playback speed changing during playback state.
  • Page 33 Playback Mode To enter the playback mode, press “SEARCH” of status bar, or press right button of mouse and enter [FUNC]  [SEARCH] in monitoring mode. Time search Set the time to want to play and press . Then the playback time will be moved to set time. Calendar search When calendar search is run, it marks the dates on which there were Recordings.

  • Page 34: Copy

    Copy This menu is for copying (backup) recorded videos. There are 2 types of copying, EXE, and AVI. Only authorized users by security settings can use the Copy function. For more about authority settings, please refer to (user setup) section. To run copy function, click COPY button under Function menu.

  • Page 35: Configuration

    Configuration System configuration Please set time/disk/authority. Date/time Menu  System  Date/Time Before recording setting, NVR has proper time information. NVR has ‘UTC +09:00 Seoul’ as default time zone. <Note> 1. To search NVR’s recording data properly, NVR should have exact time zone information.
  • Page 36 Menu  System  Date/Time  Sync with NTP NTP (Network Time Protocol) synchronizes the time of all connected device. To set NVR time to standard time open server which offers standard time on the network and client which is connected to open server to receive time and synchronize it with standard time.
  • Page 37 Recorded part for 2 days. Record during 10 days. Record during 10 days. Start record In progress of record Start record In progress of record [Picture 1] [Picture 2] Data deletion This function allows only recordings of preassigned date to be viewed. For example, if playback block is set at 3 days, then NVR will only save data for 3 days and will delete data more than 3 days old even if auto-deletion isn’t on.
  • Page 38 User settings Menu  System  User Settings NVR users will either be manager or user. Managers can use all functions of NVR without limitation and can set up user settings. Up to 10 users can be registered and each user can only use functions for which they’ve been given access to.
  • Page 39 Utility Menu  System  Utility Utility sets up NVR name, language, etc. NVR alias Set the NVR alias when connected to network. Language Select a language for a system. Key buzzer Button sound can be turned on or off for keyboard. NVR keyboard ID This menu sets the address of keyboard when using all functions of NVR by keyboard.
  • Page 40 Firmware upgrade Can update firmware by USB Memory stick Steps for USB upgrade 1) Put firmware file into USB memory and insert it into NVR 2) Select “Firmware update” button 3) Select “Yes” to the popup “Upgrade firmware from USB disk?” 4) NVR will reboot automatically.
  • Page 41 NTSC/PAL Setup NTSC/PAL mode of the NVR. • NTSC-NVR is running on NTSC(60/30Hz) fixed mode • PAL- NVR is running on PAL(50/25Hz) fixed mode <Note> Please reboot to apply the changed setting. Setup Wizard Setup wizard runs automatically on NVR’s initial boots up. It can be run through “Menu >...

  • Page 42: Network

    Network Configure network info when NVR is connected to a network. Network settings Menu  Network  Network  Ethernet Select NVR’s network type between Ethernet Or XDSL. Ethernet Select ‘Ethernet’ when the NVR is connected with dedicated line, cable modem or LAN environment. xDSL Select ‘xDSL’...
  • Page 43 <Note> If IP camera is connected to PoE port, user should do as follows to connect the webpage of that IP camera. Connect LAN cable of PC or notebook PC with one of NVR’s PoE port. Set the IP address of PC (or notebook PC). IP address should be in the same subnet with IP Address2 (PoE) of NVR.
  • Page 44 RTSP It is short for Real Time streaming Protocol) and streams real time live image of NVR Authentification On: Only authorized users can view RTSP video. Authentification Off: Non-authorized users can view RTSP video. Stream1 : Main Stream Stream2 : Sub Stream In order to view channel 1 of NVR (Ex: 192.168.1.10), input “rtsp://192.168.1.10/ch1/stream1”.
  • Page 45 Service streaming (Service Channel/Remote DVR) User can select ‘Service Channel’ to provide multi channel realtime monitoring on mobile application or ‘Remote DVR’ to control and monitor the NVR from remote location. Service Channel (to be supported) Each channel can be 30 fps (realtime monitoring) at mobile viewer even if multi division mode is selected.
  • Page 46 Remote DVR User can control the NVR from remote location by using Remote DVR function which is similar to remote desktop of Windows PC. User can see NVR’s main monitor output on PC (Control Center or WebViewer) and mouse control is possible. Please follow below steps to use Remote DVR function on Control Center.
  • Page 47 DDNS Menu  Network  DDNS User can give a domain name to a NVR by using DDNS service, WNS. DDNS setting at a NVR DDNS setting at a NVR 1. Change NVR’s port which is not in use (e.g. 8000) 2.
  • Page 48 Menu  Network  WRS If a NVR is connected to cable modem or xDSL modem, ISP (Internet Service Provider) may change NVR’s IP address unexpectedly. So, the user can not get the IP address of the NVR. If a user register a NVR to WRS server, the user can easily connect the NVR by using Control Center.
  • Page 49 Radius menu  network  RADIUS Radius function manages many NVR accounts with one account using Radius server. Radius menu configures status, IP address, and port. Status should be configured as enable in order to use Radius function. Port by default can use 1812 and if server assigns a port, then it needs to be configured..

  • Page 50: Devie Settings

    6. Click “Save Changes” button to apply. * “Clear” button can erase all configurations at once. <Note> 1. IP camera registration 1) Webgate’s IP camera: select WESP 2) IP camera supporting Onvif: select Onvif 2. DVR’s channel Registration 1) Supporting FW (1) Lower than FW 8.2 –...
  • Page 51 ADD CAMERA WIZARD All IP camera and DVR which are in the same subnet can be registered at once by using ADD CAMERA WIZARD. IP Address Show IP address of IP camera or DVR. Note that only IP cameras and DVRs which re in the same subnet can be shown in the list.
  • Page 52 Select All IP cameras or DVRs on the list can be automatically assigned to NVR channels. Add Selected Cameras IP cameras (or DVRs) which are assigned to [NVR Ch.] can be added at once by clicking [Add Selected Cameras]. After clicking [Add Selected Cameras], [ADD CAMERA WIZARD] window will be closed. To apply setting, please click [Save Changes] on [Device] window.
  • Page 53 Patrol NVR support 8 patrols. User can change configuration and the name of patrol. Preset: Patrol can have 8 presets. User can set the sequence of presets. Interval(Sec): Set the interval of each preset. After interval time, PTZ is moved to the next preset position. The range of interval time is 1 ~ 255 sec.
  • Page 54 Monitor menu  device  monitor Configure SEQ, MULTI, HDMI Resolution, VGA Resolution. Auto Sequence (SEQ) To use Auto Sequence, click [FUNC menu]-[Tool]-[SEQ]. To escape from Sequence mode, click again [FUNC menu]-[Tool]-[SEQ] or click [SEQ] on the right upper side of screen.
  • Page 55 VGA RESOLUTION Resolution of VGA port can be changed. Selectable resolutions are 800x600, 1024x768, 1280x1024, 1920x1080, Please reboot to apply new resolution. Audio menu  device  audio Configure audio channel, audio recording, volume, synchronization, mixing on this menu. Audio Channel The channel number which audio is output.
  • Page 56 Text menu  device  Text This menu is for configuring the device, baudrate, etc of text device. Max 4 text can be connectable using USB to serial cable. Recording Set On/Off of recording of Text input. Video Ch Select channel to synchronize with text. Device Choose from Manual, Star Finger 007, VSI Pro, VSI Hydra for text input device.

  • Page 57: Event Configuration

    Event Configuration Event menu  event  event Event set up has 3 set up procedures, event, motion, and sensor. Activate Event Check User can activate the event check. If not checked, all events will be ignored. If schedule is set to ‘Always Check’, event will always be checked. If schedule is set to ‘Custom’, event will be checked during only user defined schedule.
  • Page 58 If event in event sourch happens, event notification will be delivered to mobile application in push alarm. <Note> 1. To use fire detection feature, please connect WEBGATE’s flame detection camera (N1080BL-AF-F2) 2. Select sensor of fire detection camera channel as Flame Detector.
  • Page 59 EVENT SOURCES Select Sensor, Motion Detection, Video Loss, Text or System for activating event. System event sources of HDD Fail, fan fail, password fail, WRS registration fail, power on and recording fail can be checked (some or all). HDD Fail Event notification for HDD performance problems or connection status problems.
  • Page 60 E-mail Configuration Recipient Address Input E-mail address with receiver’s E-mail info. E-mail format should be xxxx@xxxxxx.xxx and the users must only use combination of numbers and the English letters Max. 3 recipients can be registered. Sender’s E-mail address Sender’s E-mail address is set when user use E-mail for output selection and user setup E-mail address as xxxx@xxxxxx.xxx.
  • Page 61 Motion detection Menu  event  motion NVR can activate motion detection for each channel. The motion detection seting of the IP camera such as motion detection area and sensitivity should be done on the IP camera. If motion detection is activated, motion detection can be a source of event.
  • Page 62 Remote Sensor Device User can map the input signal from remote sensor device to the sensor switch. By using this function, remote sensor device can be used as an even source for relay, buzzer, email, FTP, video popup, camera preset, alarm push, etc.

  • Page 63: Record Setting

    Record Setting NVR can set frame rate (frame per second) of IP camera according to the record setting of NVR, but can not configure the quality (bit rate, bps). Please use the webpage of IP camera to configure the quality. Record mode has 3 types as normal/event, schedule/event, and emergency record.
  • Page 64 be deleted. If user does not select schedule and click ‘Delete’, then previously selected item will be deleted first and deletion will be achieved in reverse of time set up. • Delete All: whole schedule will be deleted <Warning> The time zone can not overlap with the previously set time zone. Max 50 schedules can be registered. Pre Event Duration (Record time before event) User can select between 1~5sec and time ahead of event will be recorded as much as time set by user.
  • Page 65 Edit Program Menu  Record  Edit Program ‘Edit Program’ is menu for modifying record program. Number of program is 9 (from A to I) and each program has predefined setting. Each program can be modified by user. User can set the frame rate of each channel.

  • Page 66: Webviewer

    WebViewer WebViewer is Web application program loaded to monitor real-time image or to monitor the images recorded through Web browser to PC located remotely. System requirement Recommendation Items Core i5 3.0GHz Main Memory 512MB or higher Video Memory 1024MB PCI-E Graphic Card Support AGP Accelerate (AMD Radeon HD 7000 Series or Display Higher) Support PCI-E 16X or higher...

  • Page 67: Monitor

    Monitor When it is authorized with User ID & Password input at Login page, it moves to monitor page. At Monitor page, it is possible to monitor real time image of cameras connected to NVR, or it can control PTZ camera, Relay, and Microphone function according...
  • Page 68 Relay operation It can On or Off Relay of the unit. Click the number button to activate Relay On, then the icon Changes from Blue to orange color. Not activated Relay button means, the product is no supported. Relay is need user’s authority. Refer to user manual in the unit for the setup of User’s authority of Relay.
  • Page 69 Using PTZ During monitoring, select a channel with PTZ configuration and right-click to select “PTZ” to use PTZ. PTZ control lets users use Pan/Tilt, Zoom/Focu functions. Pan, Tilt control There is a cross line in the middle and click image to operate Pan, Tilt.

  • Page 70: Playback

    Playback This page is to playback recorded images, and user who has authority of ‘HDD’ among user ID or administrator can use this function. Playback that is made up 16 divisions can play the images by searching through colander by recording period and moving the period.

  • Page 71: Back Up

    Back up There are re4 (Multi channel) and avi(single channel) Set From, To time and select the channel for backup Point out the location for backup. Input in Password/Verify. In case of playback backed up file, correct password should be input. Move to Web Monitor Click ‘Go’...
  • Page 72 32x, 64x, and All’. ⑤ It is the function to set play area. After click the button, it can select play area ‘10min, 30min, 1hour, 3hour, 6hour, 12hour, 24hour’. ⑥ It can select DirectX use or not. If check DirectX mode, it can play image into Direct Draw based on graphic card and performance of PC.

  • Page 73: Html5 Webviewer

    HTML5 Webviewer HTML5 is the new technology which does not require any active-x or plug-ins and is not depend on OS. NVR supports HTML5 webviewer which can monitor the NVR with web browsers supporting HTML5. (Currently HTML5 Webviewer does not support 4M and 4K video input. HTML5 Webviewer will support 4M and 4K in the near future) System Requirements Items...
  • Page 74 Screen Division At initial monitor page, all video channels will be shown with the maximum division. The number of video channels will be depend on the NVR model. You can change the screen division mode by clicking Icon. Single Division Double click the video channel to see with single division mode.

  • Page 75: Playback

    Playback By clicking icon at the top, user can playback the NVR’s recorded video. Note that only authorized users for playback/search can use playback function. At initial playback page, all video channels will be shown with the maximum division. The number of video channels will be depend on the NVR model.
  • Page 76 Timeline Timeline shows the recording status including event information. Timeline with grey means ‘no event’. Timeline with yellow means that motion is detected. Timeline with red means that sensor is input. <Note> Only x1 forward playback and pause are supported. Backup User can backup by clicking icon.

  • Page 77: Mobile Application

    Mobile Application Mobile application is supported for Smart Phone (Android and iOS). It is available to serach and install as free of charge in Apple App store & Google Android Store. (Please refer 5 page to find out the name of application.) ...

  • Page 78: Register Method For Android App

    Register method for Android app URL register 1. Touch “+” button after application installed. 2. Select URL in category. 3. Touch “Find” button then there’s unit name and IP address shown. Touch save button to finish unit register. 4. Touch unit created to enter unit’s screen. WRS register 1.

  • Page 79: Appendix

    Appendix Problem solving [FAQ] problem & symptom solution If system power isn’t on, LED on the  Check the power of system system front won’t operate  Check power voltage in out  Check or replace power supply if power doesn’t turn on after above procedure No video on some channels with black ...

  • Page 80: Compatible Hdd

    Compatible HDD For compatible HDD information, please refer to technical supports of manufacturer. Factory default set-up values System Time Current time Time zone UTC +09:00 Seoul Date/time Daylight Saving Time (DST) Date Format Month/Day/Year Sync with NTP Overwrite Disk Block Playback Off / 5Day User admin...
  • Page 81 Resolution HDMI resolution 1920x1080 VGA resolution 1920x1080 Event Activate Event Check Schedule Always Check Event Actions Buzzer Email Video Popup System Alarm Always on event System HDD Fail Password Fail Others Inactivate Camera Preset Alarm Push Enable System HDD Fail E-mail Setup Recipient Address 1 receiver@gmail.com...

  • Page 82: Product Specification

    Product specification 16 CHANNEL NVR VIDEO INPUT IP C a m e r a w ith Onv if pr otocol & W ESP pr otocol C ha nne l 16C H IP v ide o input Pr otocol s NETW OR K Pr otocol W ESP, Onv if Pr ofil e S 1 G iga bit Ethe r ne t R J - 45 por t ( 10/ 100/ 1000Mbps)
  • Page 83 36 CHANNEL PoE NVR VIDEO INPUT Pr otocol s IP C a m e r a w ith Onv if pr otocol & W ESP pr otocol C ha nne l 36C H IP v ide o input Pr otocol W ESP, Onv if Pr ofil e S NETW OR K 1 G iga bit Ethe r ne t R J - 45 por t ( 10/ 100/ 1000Mbps)
  • Page 84 64 CHANNEL NVR VIDEO INPUT IP C a m e r a w ith Onv if pr otocol & W ESP pr otocol C ha nne l 64C H IP v ide o input Pr otocol s NETW OR K Pr otocol W ESP, Onv if Pr ofil e S 2 G iga bit Ethe r ne t R J - 45 por t ( 10/ 100/ 1000Mbps)
  • Page 85 64 CHANNEL HOT SWAP NVR VIDEO INPUT IP C a m e r a w ith Onv if pr otocol & W ESP pr otocol C ha nne l 64C H IP v ide o input Pr otocol s NETW OR K Pr otocol W ESP, Onv if Pr ofil e S 2 G iga bit Ethe r ne t R J - 45 por t ( 10/ 100/ 1000Mbps)

  • Page 86: Product Dimension

    Product Dimension 16 CHANNEL NVR 36 CHANNEL NVR...
  • Page 87 64 CHANNEL NVR 64 CHANNEL HOT SWAP NVR...
  • Page 88 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or Open Source License Report on the Product otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License.
  • Page 89 A “covered work” means either the unmodified Program or a work based on the Program. for the User Product in which it has been modified or installed. Access to a network may be denied when To “propagate” a work means to do anything with it that, without permission, would make you directly or the modification itself materially and adversely affects the operation of the network or violates the rules secondarily liable for infringement under applicable copyright law, except executing it on a computer or and protocols for communication across the network.
  • Page 90 the Free Software Foundation. If the Program does not specify a version number of the GNU General library, complete source code means all the source code for all modules it contains, plus any associated Public License, you may choose any version ever published by the Free Software Foundation. interface definition files, plus the scripts used to control compilation and installation of the library.
  • Page 91 free software distribution system which is implemented by public license practices. Many people have the Work, provided that such additional attribution notices cannot be construed as modifying the License. made generous contributions to the wide range of software distributed through that system in reliance on You may add Your own copyright statement to Your modifications and may prvide dditional or different consistent application of that system;...
  • Page 92 products derived from this software without specific prior written permission. NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF THIS SOFTWARE IS PROVIDED ``AS IS'' AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTIBILITY AND FITNESS FOR This product includes cryptographic software written by Eric Young(eay@cryptsoft.com).
  • Page 93 Manufacturer might service at user’s cost for following request made by customer. Customer notice.  Please make regular schedule to check unit status (Daily check is recommended).  Manufacturer will not take any responsibility on the physical/human damage caused by robbery, natural disaster.
  • Page 94 For requesting service? Please inform details of malfunctions correctly. Free or non-free repair will be decided based on details of warranty card. WebGate, Daemyung Corporation Co., Ltd. 6F Hanlim Venture Town B/D 284 Gongdanro Gunpo Gyeonggido, 435-862 Korea Main TEL: +82-31-428-9300 Client Service TEL: +82-1644-3421 The damage coming from following condition will be repaired at customer’s cost.
  • Page 95 The W HDcctv Alliance Premium to your HD-CCTV W E B G A T E WEBGATE Daemyung Corporation Co., Ltd. 6F,Hanlim Venture Town B/D, 284, Gongdan-ro, Gunpo-si, Gyeonggi-do, Korea(15809) Tel +82. 31. 428. 9383 Fax +82. 31. 455. 3955 sales@webgateinc.com...

This manual is also suitable for:

Uhn seriesUhn3616p-h4Uhn6400-h8Uhn6400-h16s
