WebGate MD1600L eDVR User Manual

Hide thumbs Also See for MD1600L eDVR:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
eDVR User Guide
MD1600L
(v 1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD1600L eDVR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WebGate MD1600L eDVR

Summary of Contents for WebGate MD1600L eDVR

  • Page 1 eDVR User Guide MD1600L (v 1.0)

  • Page 2: Fcc Compliance Statement

    FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. OTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 When installing eDVR, be cautious to locate on safe places where children are unreachable. 6. If eDVR does not operate properly, please contact the closest WEBGATE distributor for after sales service. Tampering or disassembling the product will void the warranty.

  • Page 4: Table Of Contents

    Contents Overview ............................7 Introduction ..........................7 Description..........................9 2.1. Front Part .......................... 9 2.1.1. MD1600L front part ....................9 2.2. Rear Part ......................... 11 2.2.1. MD1600L rear part ....................11 2.3. Summery of Installation ....................12 Basic Structure .......................... 13 Monitoring ..........................
  • Page 5 3.11. Screen Lock control ......................20 3.12. Bookmark function ...................... 21 Playback ..........................21 4.1. Various Playback mode(Playback) ..................21 4.1.1. Playback on standard monitor (full screen) ..............21 Playback to divided Channel(4/9/16)................21 4.1.2. 4.1.3. Playback channel no. 5~16 at 4/9 channel division ............21 4.1.4.
  • Page 6 5.7. Monitor Setup ......................... 53 5.8. System Setup ........................54 5.8.1. Audio Setup ......................54 5.8.2. Time Schedule Setup ....................55 Special Time ......................56 5.8.3. 5.8.4. Security Setup ......................57 5.8.5. Disk Setup ....................... 59 5.8.6. Network Setup ......................60 5.8.7.

  • Page 7: Overview

    Overview 1. Introduction eDVR MD1600L is new conceptual DVR(Digital Video Recorder), which can record 16ch ananlog video channel, Audio, Text & Alarm data etc simultaneously. Also, it upgrades video quality and file size applying MPEG algorithm. Quick Setup menu in eDVR MD1600L makes possible to direct recording by only connection between Power &...

  • Page 8: Main Features

    Main features - It supports 16ch video - Supports 1 ch bi-directional audio - Supports recording, playback, network recording, network playback simultaneously (Pentaplex) - Max. CIF, 480(NTSC) / 400(PAL) ips recording speed - Max. 960(MD1600L) ips real-time display speed - Real time video surveilliance and recording via PC monitor & CCTV monitor - Support 1 S-Video and 1 VGA Monitor output - Internal hardware Quad Splitter for analog channel - Internal software multiplexer for 16channel division monitoring...

  • Page 9: Description

    2. Description 2.1. Front Part 2.1.1. MD1600L front part (1) Status LED (7) Menu & Directions (3) Power switch (2) Remote controller (4) USB Interfacer (5) Function buttons (6) Channel button receiver (1) Status LED : It indicates Power input, and light on at Power in. : Indicates Ethernet &...
  • Page 10 (5) Function buttons : Function to diplay all video connected sequentially Press more than 1 sec. to operate User Sequnce mode : Function to monitor multi video images in a screen((4/9/16 division channel) MULTI : Function to select video channel to control PTZ in Monitor model. SELECT And function to select video channel to Copy/Backup/Delete in Playback mode.

  • Page 11: Rear Part

    : Each press of the button will increase playback speed gradually (x1, x2, x4, x8, x16, x32, x64) : To pause Live/replaying PAUSE : To stop replaying STOP From single/split mode, it will switching as desire channel group or split mode. 2.2.

  • Page 12: Summery Of Installation

    2.3. Summery of Installation - Camera connection - Monitor connection - Ethernet connection (for remote connection) - Audio connection - Power connection & Operation...

  • Page 13: Basic Structure

    Basic Structure 3. Monitoring All analog video image channels connected to eDVR is displayed to screen by Power connection. It is to utilize all monitoring mode of eDVR MD1600L. 3.1. Basic Screen monitoring After Power connection, MD1600L operates on automately. It boots with LED on.

  • Page 14: Manual Recording

    3.4. Manual Recording By the press [Enter] button for user recording, it records as long time as it set the time. It is prior to Normal Rec, Event Rec. And it records by user recording set in disregard for any recording setup when user recording starts.

  • Page 15: System Standard Mode

    3.5.1. System Standard mode By [SEQ] button, it can monitor auto switching of all channels. Press [MENU] for the setting switching term. Move to “Monitor” from OSD menu. Press [▷] to move from “Monitor” to “Monitor”. Select “Seq. Switching(sec)” and set value from 1 sec. to 60 sec. At OFF set, auto switch mode does not operate.

  • Page 16: User Sequence Mode

    3.5.2. User Sequence mode Press [SEQ] button longer than 1 sec. User Sequence is to set User Sequence Configuration from “Monitor” in OSD menu. <Attention> 1. User mode can define max. 16 channels. 2. The above picture defines 6 Sequence, and it is displayed in order as 4 division(1,2,3,4) Full screen(1) division(5,6,7,8)

  • Page 17: Alarm Mode

    3.6. Alarm mode It can be set to Pop-up automatically relevant screen when alarming. Set pop-up period can be set into “Alarm Pop-up (sec)” inferior to “Monitor” menu. At the simultaneous alarming in several channels, it displays the division as many channel as alarmed.

  • Page 18: Ptz Control

    3.9. PTZ Control Connect PTZ controller to eDVR and set relevant protocol from “Serial Setup” menu, then PTZ can operate while monitoring live images. Press [SELECT] button first. Channel select icon is on the screen, Shift to channel to control PTZ with directional key. (Press [SELECT] at single screen mode) Press [MENU] at channel selection icon displayed to view PTZ (Pan/Tilt, Zoom/Focus, Load Preset, Save Preset).

  • Page 19: Utilizing Save Preset

    3.9.4. Utilizing Save Preset This menu is used to set new Preset at real-time monitoring mode. Control camera location using ‘Pan/Tilt’ and ‘Zoom/Focus’ menu. Press [SELECT] button and select Channel. Press [MENU], then select ‘Save Preset’ from OSD. Press relevant Number button to set in Preset. 3.9.5.

  • Page 20: Relay Control

    3.10. Relay control The function to Relay On/Off. (MD1600L supports 4 Relay Output.) Press [RELAY] button to display “Relay On” icon on screen. Then Relay Out signal is out by pressing the relevant number of Relay among 1~4 number button. Press [RELAY] to Relay Off.

  • Page 21: Bookmark Function

    3.12. Bookmark function This function is for force occurred event for current monitoring image. It will produced by pressing ‘0’ button from Monitor mode, and there will be no alter or indication. The Bookmark will be transaction as event and it can be search and playback from Search function.. 4.

  • Page 22: Various Playback Functions

    Press [ZOOM] one more to return original screen mode. 4.1.5. Various Playback functions ▷ ▷ ▷ ▷ (PLAY) : Playback 1x speed. Press [▷]playback button at single monitor mode will playback recorded images of monitoring channel. Press [▷]playback button at multi monitor mode will always playback recorded images of no.

  • Page 23: Search Mode

    4.2. Search mode This menu is to playback specific time data from the time frame and searching log at Playback mode. From for the time to start recorded data, To indicates the last time. Select From/To and press [ENTER] to move to the relevant time.

  • Page 24: Copy / Backup / Delete

    4.3. Copy / Backup / Delete This menu describes how to copy/backup/delete recorded images. Press [SELECT] and [MENU] in order and Playback mode. 4.3.1. Copy Image Use USB Memory Stick etc to copy selected channel images in some part. Time Slect the range of Copy.

  • Page 25: Backup Data

    4.3.2. Backup Data Start Date & Time / End Date & Time Slect the range of backup. Select Disk Select the disk to use backup device. < ote> Uncompleted backup file 100% can not be played normally in PC < ote> It does not support USB device as backup.

  • Page 26: Delete Data

    4.3.3. Delete Data The menu to delete specific rage of data in present HDD recorded. Delected data is limited to present HDD used, and it does not affect to backup disk. The range of delete data is from oldest data to the data that the time selected. <...

  • Page 27: Configuration

    5. Configuration 5.1. Quick Setup There are 3 methods in Video recording setup - Quick Setup, Recording, Alarm Recording menu. Quick Setup is the menut to set recording easily in same condition of all analog channels. Recording is to set recording in more various conditions by time period or channel.
  • Page 28 Time Zone Select the times using left-right directional key from eDVR front. Every time pressing direction changes the time zone. (Press [EXIT] to return to previous menu. It is as same as OSD menu.) Daylight Saving(Summer Time applied) This menu is linked to Time zone set menu. Namely, it is activated when selected summer time zone is set from Tim Zone set menu.
  • Page 29 Selet the method of Time Format. Using Legt-Right key set Time Formate “MM/DD/YYYY” or “YYYY/MM/DD”. Date/Time Using Left, Right key will shift Year, Month, Date menu, and select each menu with Upper & Lower button. Apply Date/Time To apply Date/Time value, press “Apply Date/Time” button to display the following window. <...

  • Page 30: Recording Setup

    5.1.2. Recording Setup Quick Setup is to set same conditions to all analog channels in every hour. <Button Input> Select “Recording” menu inferior to “Quick Setup”. Configuration Status It just indicates the setup status of recording only. If user sets recording condition to Quick Setup, it is indicated to “Macro Setup”...
  • Page 31 Channel Status Set whether it activates all analog channels. Defult value is “On”. Recording Speed/Quality There are all 5 setup conditions. (No Rec./Low/Standard/High/Custom). The conditional Setup except “Custom” comes to auto synchronize with “Speed(ips)”and “Quality” Quality can set the each separately. At the setup condition of “Alarm Recording”, “Standard”와 “Pre/Post Alarm”...

  • Page 32: Camera Setup

    5.2. Camera Setup This is to setup the condition of every camera. At Quick Setup menu, it sets every camera to the same condition. Set values are applied in same at monitoring & recording mode. <Button Input order> After pressing [MENU], shift to “Cam # 1~Cam #16” inferior menu of “Camera”. Set Camera name.
  • Page 33 <TIP> Display Letter input window to input characters. According to menu, letter input window can be different, but Set is the same. Use direction key for letter input. Select letter using [▲/▼] button. Press [►] to input after select the input letter. Press [◄] to Shift back and delete.
  • Page 34 Brightness/Contrast Select the value from “–9” and “+9” using [◄] or [►] buttong after pressing [ENTER]. Covert Covert On will hide the channel at Monitoring mode. Select “A / B / Both / Off” using [◄] or [►] buttong after pressing [ENTER]. PTZ Home/PTZ Idle Time Shift to Preset assigned if it has no movement in certain time while PTZ control Set Preset number and Time using [◄] or [►] buttong after pressing [ENTER].

  • Page 35: Manual Recording Setup

    5.3. Manual Recording setup This menu is to set video recording condition by user when pressing [REC] button. If manual recording starts, Normal Rec & Event Rec is ingored and it records based on user recording setup. Recording Speed/Quality There are all 4 setup conditions. (No Rec/Low/Standard/High/Custom). Setup condition except “Custom” will synchronize “Speed(ips)”...

  • Page 36: Schedule Recording Setup

    < ote> In case of set ‘No Rec.’ in Schedule Rec., it records as a set of Pre Alarm. While Schedule Recording, it records Pre Alarm section in speed(ips) of a set Schedule Rec. When Post Alarm is set to Latched, it maintains user recording continuously till the stop pressing [REC] button by user.

  • Page 37: Setup By Channel

    < ote> 1. The difference of recording setup in Quick Setup is that there is no audio recording setup, and sets whether Special Time Recrding & Event Recording sets or not. 2. What Alarm Recording Off is set, Alarm Rec. menu is not available. To set Alarm Rec. menu, Alarm Recording of Recording menu should be set to “On”...
  • Page 38 <Time Schedule Setup> Shift to“System” menu to set Time Schedule. Weekday Start/End Set Time zone from Monday to Sunday using Left, Right key button. The unset zoon can be set to Weekend time zone. Day Start/End Set Day time zone using Up, Down button. The unset zoon can be set to Night time zone. Recording Speed/Quality There are all 5 setup conditions.
  • Page 39 Resolution There are all 3 conditions. (CIF/HALF/D1). At this menu, resolution set is applied to every User recording, Event recording. CIF : 360x240 @ NTSC, 360x288 @ PAL HALF : 720x240 @ NTSC, 720x288 @ PAL (HALF D1) D1 : 720x480 @ NTSC, 720x576@ PAL (FULL D1) Special Time Recording This menu is to differenciate recording conditions by setup of specific time zone.

  • Page 40: Alarm Recording Setup

    Event Recording After pressing [ENTER] button, set “On/Off” using [◄] or [►] button. Detailed Alarm recording conditions sets from “Alarm Recording” menu. Here only can set recording according to alarm recording setup. 5.5. Alarm Recording Setup This menu is to set Alarm Recording condition. After setup Recording condition, “Event recording” menu from “Recording”...

  • Page 41: Motion Detection Setup

    Configuration It can set 16 sensors (S1~S16) separately. 5.5.2. Motion Detection Setup This menu is to set MD of each channel. Global sets all channels (Cam #1~Cam#16) in the same together, and setup can differ separately. Motion Detection It sets 4 different sensitivity of MD; Off, Lowest, Low, Std, High, Highest. MD Area It sets MD zone.
  • Page 42 5.5.2.1. Motion Detection Setup by Channel MD setup by channel is same as Global setup. And it can set MD zone additionally when MD sets by channel. Custom Area It sets MD zone by user TSC 22x15, PAL 22x18 First default value is set to “Select All”. If “Custom Area” pressed, Window for MD zone setup is opened.
  • Page 43 < MD Zone Setup > It can set MD zone by user directly. If “Custom Area” is pressed, sell TSC 22x15, PAL 22x18 for setup is displayed. Selected MD zone is in grey color. To select MD zone, use direction key for the wanted zone and press“ENTER” to apply.

  • Page 44: Text Setup

    5.5.3. Text Setup This menu is to set text data input. It has to be set COM1 part from “System -> Serial Setup” menu on OSD. Recording It is On or Off to save the Text input. Sync Text With Select the channel synchronize with Text data.
  • Page 45 Delimiter Value of Delimiter can be different according to every device. Refer to their manual or inquire it to purchasing stores of its model. Timeout(ms) Following lines defined here means maximum number of text line from one data. Even if there is standized data, there can be a short and long data.

  • Page 46: Global Alarm Recording

    5.5.4. Global Alarm Recording Set all analogue channels in same condition. Sensor/MD Set synchronizing with Sensor/MD. Pairing means 1:1 synchronization between the channel and Sensor/MD. Text When set “On”, it deals text input of relevant channe as Alarm Event and is saved. <...

  • Page 47: Setup By Channel

    5.5.5. Setup by Channel Alarm Source (*=All) Through Alarm Source, 4 Sensors and 1 MD, Text input is selectable. Selection of Sensor is set by pressing relevant number button. Selection of MD, Text can be On/Off by direcitional key. Select Preset of PTZ by relevant Alarm input. <...
  • Page 48 < ote> In case of set ‘No Rec.’ in Schedule Rec., it records as a set of Pre Alarm. While Schedule Recording, it records Pre Alarm section in speed(ips) of a set Schedule Rec. When Post Alarm is set to Latched, it maintains user recording continuously till the stop pressing [REC] button by user.

  • Page 49: Alarm Action Setup

    5.6. Alarm Action Setup According each Time schedule, it sets Relay action. It sets to 5 different time period, Full Time, Weekday(Day), Weekday(Night), Weekend(Day), Weekend(Night). After Schedule setup, it sets Relay, Buzzer, Email etc to operate Alarm action. 5.6.1. Schedule Select Action Source Sensor and MD can be set max 4 or ANY for Relay1~Relay4, Buzzer, E-mail.

  • Page 50: Setup

    5.6.2. Setup Relay Configuration Set the use or not for R1~R4. Buzzer Set the use of Buzzer or not. E-mail Addr. Input E-mail address to inform Alarm. Sender Addr. Input “Sender” address in the typr of who@where. Mail Duration (min) E-mail notification is to send message in terms of Mail Duration set, but not every time that Alarm is occurred.

  • Page 51: System Alarm

    < ote> Network setup is set to DNS for E-mail notification. 5.6.3. System Alarm 5.6.3.1. System Alarm Setup It is to set ON/OFF of Alarm for the notification of system faulty. HDD Fail Alarm action is operated when HDD disconneced or abnormal action. HDD Almost Full It operates alarm action when connected HDD is almost full.
  • Page 52 Password Fail It operates Alarm when wrong User or Admin password input. WRS Reg. Fail It operates Alarm when disconnection of WRS. 5.6.3.2. Alarm Method Setup It is to set ON/OFF of Alarm when system alarm is occurred. Warning Message When setup this menu, it display warning message through pop-up.

  • Page 53: Monitor Setup

    5.7. Monitor Setup It sets the monitor for the display of video from monitor. Alarm Pop-up (sec) It sets auto Pop-up display for the alarm. Pop-up display time can be set from 5~10 second. If it sets to “Keep”, it keeps to display Pop-up image and press any button to release Keep mode. Seq.

  • Page 54: System Setup

    User Sequence Configuration It can edit Auto transmit function for user mode. <Attention> 1. It can define all 16 user mode. 2. The picture for example defines 6 Sequences in order as shown 4 division(1,2,3,4) Full mode(1) 4 divisions(5,6,7,8) Full mode(5) Full mode(8) 9 divisions(9,10,11,12,13,14,15,16).

  • Page 55: Time Schedule Setup

    When playback recorded image, it sets which it works together. 5.8.2. Time Schedule Setup It sets the time period from Week & Weekend, Day and Night. Weekday Start/End Using Left, Right key sets the time period from Weekday. Other unassigned time is for the Weekend. Day Start/End Using Up, Down button sets Day time period.

  • Page 56: Special Time

    5.8.3. Special Time It can set another specific time zone in each time zone(Week day, Week night, Weekend day and night), For example, various conditions setting separately such as mealtime or meeting time is applicable. It used for the set of regular exceptial time. Max. 4 different specific time can set. Exception Days It used for the setup of irregular exceptional time, max.

  • Page 57: Security Setup

    5.8.4. Security Setup 5.8.4.1. Local Password User Password It is only capable of monitoring and playback only with user registery. Default set is “1111”. Admin Password Authorized administrator can control every function. Default set is “9999”.
  • Page 58 5.8.4.2. Remote Users Admin ID setup Admin ID “admin” cannot be changed. Password of admin is set and has all rights and unchangeable. User ID setup Max. 10 user’s ID can be set. To register the user, change Use’s value to “Y” and input ID & password. Basic value is available for all monitoring/playback/Relay.

  • Page 59: Disk Setup

    5.8.5. Disk Setup Auto Deletion When no HDD space left for recording, it deletes the recorded data automatically. Backup Reminder This menu is to inform backup time by everyday, every week, every month. Block PlayBack This menu is to playback the recorded images from HDD in limited time. It can set from Day 1 to 31.

  • Page 60: Network Setup

    5.8.6. etwork Setup There are 5 Sub menus. ; Network, xDSL, WRS, Port Setting, NTP Setting 5.8.6.1. etwork When eDVR connects to network, it is to set relevant network information. Type It sets the type(Ethernet/xDSL) of network line connected to eDVR. It sets ‘Ethernet’ at the connection of network through leased line, Cable model or LAN based connection.
  • Page 61 ‘DHCP’ is used in LAN that DHCP server works. Nornally, in mid or large scale, it operates DHCP server via LAN but generally use NAT (Network Address Translation) function via HUB in small. IP Address, etMask, and Gateway Address, D S, Port, Bandwidth limit It sets IP address, Network Mask, Broadcast address, Gateway , DNS address, and Port, Bandwidth limit.
  • Page 62 IP address, it renews the information in WRS server regularly. If user registers the interval ‘0’ or eDVR does not transmit any data for 2 days, the data is removed from WRS. WRS URL This menu is to set server address to register. WRS addresses that WebGate operates now are www.webgateinc.com or mycam.to.
  • Page 63 <Attention> 1. If domain address such as www.webgateinc.com or mycam.to is input in WRS URL, DNS server IP should be noted on “System Network DNS1”. 2. DHCP line such as Cable/DSL receives DNS address automatically and does not require an entry. Group ID Group ID is to set group name that eDVR registered.
  • Page 64 5.8.6.4. TP Setting NTP(Network Time Protocol) synchronizes the time of every devices connected to network. It consists of Server that offers standard time on network, and Client for synchronization that receives the time from server connected. Sync With TP It can On/Off NTP function. TP Mode It sets NTP mode of eDVR operating in Client or both.

  • Page 65: Serial Setup

    Interval (min) It sets interval (min.) of Time synchronization. < ote> When NTP Mode is Client, Sync with NTP must be set to On. 5.8.7. Serial Setup MD1600L can set all 3 COM port. Device Set external device connected. Interface This menu is to set which interface can use among RS485 from “RS485”...

  • Page 66: Status Overview

    5.8.8. Status Overview It shows status & temperature of HDD relevant to video recording and Fan speed. Earliest / Latest Recording It shows intial starting time and last time of the recorded file. Disk Capacity It shows total HDD capacity installed. Used Space It shows HDD capacity recordable.

  • Page 67: Miscellaneous

    FA RPM It shows FAN speed installed in eDVR. 5.8.9. Miscellaneous <Order of Button input> - After press [MENU] button, move to “Miscellaneous” inferior to “System”. Remote Control ID Max 16 controller ID can set up and contril via 1 remote controller. Set to Off if it is not used. <How to register Remote Controller>...
  • Page 68 Keyboard Control Addr This menu is to set Keyboard address when all functions of eDVR is controllered by Keyboard button. Default value is set to “1”. If several eDVRs connect to a keyboard, 16 channel can clash. Then set to the other address of keyboard.

  • Page 69: Disk Manager (Utility)

    5.9. Disk Manager (Utility) It explains adding or formatting internal, external Hard disk. eDVR supports various external storage. < Order of Button input> - After press [MENU] button, move to “Utility” inferior to “System”.

  • Page 70: Disk Manager

    5.9.1. Disk Manager Installed Hard disk is automatically recognized. Select Disk Select disk to set. Action Select wanted work among the menus, “Add/Remove/ Confirm Removed/Add used”. : Add Disk. Use disk that there is no partion table. Partion table can be removed [Add] from PC.
  • Page 71 deleting data through Add Used. FAT32 Format when connecting external Hard disk. FAT32 Format Execute FAT32 Format for Backup/Copy in partition of under 250GB. For execution of FAT32 format, creat partition through disk manager of PC first. If HDD size is over 250GB, create several partitions smaller than 250GB and execute FAT32 formate in each partition.

  • Page 72: Usb Utility

    5.9.2. USB Utility It supports firmware upgrading and setup saving & sending, Text file saving for printing set value through USB. Update F/W After saving upgrade firmware for USB use to USB device, connect eDVR and press ‘Update F/W’ for firmware upgrading.
  • Page 73 Load Settings Set the system as set value saved in USB device. Save Settings Save present set value to USB device.

  • Page 74: Extension

    Extension 6. External device connection External device connection is based on the standard of MD1600L 6.1. Using Text device There are 4 essential setups to use Text devices; Text menu, RS232 menu of Serial Setup, Alarm Rec. menu, Recording menu. 6.1.1.

  • Page 75: Setup In Rs232 Menu Of Serial Setup

    6.1.2. Setup in RS232 menu of Serial Setup Set connectable device in COM1 of Serial Setup menu, and also set Baud Rate, Parity, Stop, Data with relevant value.

  • Page 76: Setup In Alarm Rec

    6.1.3. Setup in Alarm Rec If there is video channel want to record with Text sync., set Text Event from Off to On.

  • Page 77: Setup In Recording

    6.1.4. Setup in Recording If any channel like to record with Text, set Alarm recording to ‘On’. Full Time is to set all Week day & night, Weekend day & night, and change menu to set Weekday and Weekend differently. <...

  • Page 78: Using Keyboard

    6.2. Using Keyboard There are 2 essential setups to use Keyboard; RS232 menu of Serial Setup, PTZ menu of Serial Setup 6.2.1. Setup in COM1 menu of Serial Setup Set connectable device in RS232 in Serial Setup menu to Keyboard. Also set Baud Rate, Parity, Stop, Data with relevant value.

  • Page 79: Appendix

    APPE DIX APPENDIX Appendix...

  • Page 80: Technical Specifications

    #1. Technical Specifications General 32bit RISC Processor 32MB Flash memory 128MB Main memory Embedded LINUX 16Ch. analog video inputs via BNC connector Video channel NTSC or PAL video format are supported (Auto detect) Int.: 2 HDD bays including Storage device Ext: 1 eSATA connection ports Supports Disk management tool for all disks.

  • Page 81: Monitor Output

    Daily : Day / Night / Four-segment time frame Schedule recording Weekly : Weekdays / Weekends, Exception days Conditions : Normal / Event POS/ATM transaction information archived along with Text Data recording corresponding video data Manual(Emergency) record triggered by font key Manual recording Audio Recording &...
  • Page 82 Data Backup/Expansion/Copy External HDD(eSATA) Data backup External CD-R/DVD-R(eSATA) 5~ 95% alarm Backup reminder External USB memory disk(USB 1.1 compatible) on USB port AVI Copy Input/Output Video Output 1 CVBS main monitor 1 S-Video 1 VGA 16 Loop out 1 Input : Line-in, 1 Vpp Audio 1 Output : Line-out, 1Vpp Software-controlled 1 internal buzzer...
  • Page 83 Mechanical Dimension (Wⅹ ⅹ ⅹ ⅹ Dⅹ ⅹ ⅹ ⅹ H) 430.0 x 362.0 x 44.0 5.04 kg (with one HDD) Weight...

  • Page 84: Utilizing Ip Address In Local Network

    #2. Utilizing IP address in Local network #2.1. Outline When internet uses, it connects to another server for acquisition of data or email communication through IP address. So it is not connectable to Internet without IP address. At present, authorized IP has limits to use in worldwide. And there are 5 grades from A to E in network that possesses many IP.

  • Page 85: Network Class

    #2.3. etwork Class 1) Address feature IP address : 3 numbers in X4 indicates Host ID that is addressed from 0 to 255. But, generally, 0 & 255 is used to network ID & Broadcast address, but 1 to 244 IP address used in practical. etwork ID: As Local network ID, the address indicates network identity in Internet.
  • Page 86 Subnet Mask: 255.255.255.128 Broadcast Address: xxx.xxx.xxx.255 IP Addresses: xxx.xxx.xxx.130 – xxx.xxx.xxx.254 (3) When structure 3 networks (1/2 + 1/4 + 1/4) Sub-Network ID: xxx.xxx.xxx.0 Gateway Address: xxx.xxx.xxx.1 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.63 IP Addresses: xxx.xxx.xxx.2 – xxx.xxx.xxx.62 Sub-Network ID: xxx.xxx.xxx.64 Gateway Address: xxx.xxx.xxx.65 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.127...
  • Page 87 (4) When structure 4 networks (1/4 + 1/4 + 1/4+1/4) Sub-Network ID: xxx.xxx.xxx.0 Gateway Address: xxx.xxx.xxx.1 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.63 IP Addresses: xxx.xxx.xxx.2 – xxx.xxx.xxx.62 Sub-Network ID: xxx.xxx.xxx.64 Gateway Address: xxx.xxx.xxx.65 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.127 IP Addresses: xxx.xxx.xxx.66 – xxx.xxx.xxx.126 Sub-Network ID: xxx.xxx.xxx.128 Gateway Address: xxx.xxx.xxx.129 Subnet Mask: 255.255.255.192...
  • Page 88 WEBGATE Inc. 6F, Hanlim Venture Town Bldg., 689-6, Geumjeong-dong, Gunpo-si, Gyeonggi-do, Korea (435-862) Tel : (82-31) 428-9300 Fax : (82-31) 455-3955 Sales@webgateinc.com www.webgateinc.com The contents of this manual can be modified in accordance with Firmware or Software upgrade. In the...
