Summary of Contents for WebGate MD1600H

  • Page 1 User Guide MD1600H (v 1.0)

  • Page 2: Fcc Compliance Statement

    FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Important Notice

    When installing eDVR, be cautious to locate on safe places where children are unreachable. 6. If eDVR does not operate properly, please contact the closest WEBGATE distributor for after sales service. Tampering or disassembling the product will void the warranty.

  • Page 4: Table Of Contents

    Introduction..........................7 Description..........................9 Front Part.......................... 9 2.1. MD1600H front part....................9 2.1.1. Rear Part......................... 11 2.2. MD1600H rear part ....................11 2.2.1. 2.3. Summery of Installation ....................12 Basic Structure .......................... 13 Monitoring..........................13 3.1. Basic Screen monitoring ....................13 Single full screen mode ....................
  • Page 5 3.11. Screen Lock control......................20 Utilizing Quad monitor....................21 3.12. Monitoring ......................21 3.12.1. Monitoring & Playback..................... 22 3.12.2. Playback ..........................23 4.1. Various Playback mode(Playback) ..................23 Playback on standard monitor (16 division) ..............23 4.1.1. Playback to divided Channel(4/9/16)................23 4.1.2.
  • Page 6 Setup........................52 5.6.2. 5.6.3. System Alarm ......................53 Monitor Setup ......................... 55 5.7. 5.8. System Setup ........................56 Audio Setup......................56 5.8.1. Time Schedule Setup ....................57 5.8.2. Special Time ......................58 5.8.3. 5.8.4. Security Setup......................59 Disk Setup ....................... 61 5.8.5.

  • Page 7: Overview

    Overview 1. Introduction eDVR MD1600 Series is new conceptual DVR(Digital Video Recorder), which can record 16ch ananlog video channel, Audio, Text & Alarm data etc simultaneously. Also, it upgrades video quality and file size applying MPEG algorithm. Quick Setup menu in eDVR MD1600 Series makes possible to direct recording by only connection between Power &...

  • Page 8: Main Features

    - Digital Water Mark - Register max. 16 units eDVR to Control Center Lite-D (PC user interfacer) [Total 256 channel managements (16 eDVR MD1600H x 16ch) through one S/W program] <Note> It supports only DVD backup. CD backup will be supported later.

  • Page 9: Description

    2. Description 2.1. Front Part 2.1.1. MD1600H front part (1) Status LED (2) Remote controller (3) Power switch receiver (4) USB Interfacer (5) Function buttons (6) Channel button (7) Menu & Directions (1) Status LED : It indicates Power input, and light on at Power in.
  • Page 10 (5) Function buttons : Function to copy recorded images COPY In single monitoring mode, press the button to activate COPY menu : Function to diplay all video connected sequentially Press more than 1 sec. to operate User Sequnce mode : Function to monitor multi video images in a screen((4/9/16 division channel) MULTI : Function to select video channel to control PTZ in Monitor model.

  • Page 11: Rear Part

    STOP : To stop replaying 싱글/분할 모드에서 다음 채널 또는 분할 모드에 맞는 채널 그룹으로 전환 합니다. 2.2. Rear Part 2.2.1. MD1600H rear part (1) Audi In/Out (4) Video input & (3) Power connector Video Loop back (7) FAN (6) Serial & DIO Port...

  • Page 12: Summery Of Installation

    2.3. Summery of Installation - Camera connection - Monitor connection - Ethernet connection (for remote connection) - Audio connection - Power connection & Operation <Note> Extension through NVS04, IEEE 1394b will be supported later. For the details, please contact to local distributor.

  • Page 13: Basic Structure

    All analog video image channels connected to eDVR is displayed to screen by Power connection. It is to utilize all monitoring mode of eDVR MD1600 series. <Attention> MD1600H support Quad monitor(1~4) and Monitor 1~4 supports all following functions. Therefore, the following functions explains base on all Monitor 1~4. 3.1. Basic Screen monitoring After Power connection, MD1600H operates on automately.

  • Page 14: Manual Recording

    3.4. Manual Recording By the press [REC] button for user recording, it records as long time as it set the time. It is prior to Normal Rec, Event Rec. And it records by user recording set in disregard for any recording setup when user recording starts.

  • Page 15: System Standard Mode

    3.5.1. System Standard mode By [SEQ] button, it can monitor auto switching of all channels. Press [MENU] for the setting switching term. Move to “Monitor” from OSD menu. Press [▷] to move from “Monitor” to “Monitor 1”. Select “Seq. Switching(sec)” and set value from 1 sec. to 60 sec. At OFF set, auto switch mode does not operate.

  • Page 16: User Sequence Mode

    3.5.2. User Sequence mode Press [SEQ] button longer than 1 sec. User Sequence is to set User Sequence Configuration from “Monitor 1” in OSD menu. <Attention> 1. User mode can define max. 16 channels. 2. The above picture defines 6 Sequence, and it is displayed in order as 4 division(1,2,3,4)  Full ...

  • Page 17: Alarm Mode

    3.6. Alarm mode It can be set to Pop-up automatically relevant screen when alarming. Set pop-up period can be set into “Alarm Pop-up (sec)” inferior to “Monitor” menu. At the simultaneous alarming in several channels, it displays the division as many channel as alarmed.

  • Page 18: Ptz Control

    3.9. PTZ Control Connect PTZ controller to eDVR and set relevant protocol from “Serial Setup” menu, then PTZ can operate while monitoring live images. Press [SELECT] button first. Channel select icon is on the screen, Shift to channel to control PTZ with directional key. (Press [SELECT] at single screen mode) Press [MENU] at channel selection icon displayed to view PTZ (Pan/Tilt, Zoom/Focus, Load Preset, Save Preset).

  • Page 19: Utilizing Save Preset

    3.9.4. Utilizing Save Preset This menu is used to set new Preset at real-time monitoring mode. Control camera location using ‘Pan/Tilt’and ‘Zoom/Focus’menu. Press [SELECT] button and select Channel. Press [MENU], then select ‘Save Preset’from OSD. Press relevant Number button to set in Preset. 3.9.5.

  • Page 20: Relay Control

    3.10. Relay control The function to Relay On/Off. (MD1600H supports 4 Relay Output.) Press [RELAY] button to display “Relay On” icon on screen. Then Relay Out signal is out by pressing the relevant number of Relay among 1~4 number button.

  • Page 21: Utilizing Quad Monitor

    window for user password input will be displayed at any button press. And Lock mode will be released with correct password input. 3.12. Utilizing Quad monitor 3.12.1. Monitoring Monitor 1 monitors several video channels, and Monitor 2 is for bigger screen of channel 1. Also Monitor 3 for Sequence mode and Monitor 4 is capable of monitoring Alarm Pop-up images.

  • Page 22: Monitoring & Playback

    3.12.2. Monitoring & Playback Monitor 1~4 are capable of searching several video/playback in single & divided sreen. Namely, several channels can be monitored and playback separately and simultaneously. But Playback can be monitored in 1 monitor among Monitor 1~4, and the rest 3 monitors for monitoring.

  • Page 23: Playback

    4. Playback 4.1. Various Playback mode(Playback) 4.1.1. Playback on standard monitor (16 division) Press Playback button [▷] at Monitoring mode. It playback images with initial 1x speed. <Attention> At Monitor mode, Playback buttom will play the recorded image from Channel 1. Namely, it will always start playback of channel 1 from 30sec.

  • Page 24: Various Playback Functions

    4.1.5. Various Playback functions ▷ (PLAY) : Playback 1x speed. Press [▷]playback button at single monitor mode will playback recorded images of monitoring channel. Press [▷]playback button at multi monitor mode will always playback recorded images of no. 1 channel. When the execute playback by pressing [▷] playback button, it playback from the time when user connects to playback lately.

  • Page 25: Search Mode

    4.2. Search mode This menu is to playback specific time data from the time frame and searching log at Playback mode. From for the time to start recorded data, To indicates the last time. Select From/To and press [ENTER] to move to the relevant time.

  • Page 26: Copy / Backup / Delete

    4.3. Copy / Backup / Delete This menu describes how to copy/backup/delete recorded images. Press [SELECT] and [MENU] in order and Playback mode. 4.3.1. Copy Image Use USB Memory Stick etc to copy selected channel images in some part. Time Slect the range of Copy.

  • Page 27: Backup Data

    4.3.2. Backup Data Start Date & Time / End Date & Time Slect the range of backup. Select Disk Select the disk to use backup device. <Note> Uncompleted backup file 100% can not be played normally in PC <Note> It does not support USB device as backup. It supports CD-R/DVD-R, and over (CD-R Media 700MB / DVD R Media 4G) in CD-R Media.

  • Page 28: Delete Data

    4.3.3. Delete Data The menu to delete specific rage of data in present HDD recorded. Delected data is limited to present HDD used, and it does not affect to backup disk. The range of delete data is from oldest data to the data that the time selected. <Note>...

  • Page 29: Configuration

    5. Configuration 5.1. Quick Setup There are 3 methods in Video recording setup - Quick Setup, Recording, Alarm Recording menu. Quick Setup is the menut to set recording easily in same condition of all analog channels. Recording is to set recording in more various conditions by time period or channel.
  • Page 30 Time Zone Select the times using left-right directional key from eDVR front. Every time pressing direction changes the time zone. (Press [EXIT] to return to previous menu. It is as same as OSD menu.) Daylight Saving(Summer Time applied) This menu is linked to Time zone set menu. Namely, it is activated when selected summer time zone is set from Tim Zone set menu.
  • Page 31 Selet the method of Time Format. Using Legt-Right key set Time Formate “MM/DD/YYYY” or “YYYY/MM/DD”. Date/Time Using Left, Right key will shift Year, Month, Date menu, and select each menu with Upper & Lower button. Apply Date/Time To apply Date/Time value, press “Apply Date/Time” button to display the following window. <Note>...

  • Page 32: Recording Setup

    5.1.2. Recording Setup Quick Setup is to set same conditions to all analog channels in every hour. <Button Input> Select “Recording” menu inferior to “Quick Setup”. Configuration Status It just indicates the setup status of recording only. If user sets recording condition to Quick Setup, it is indicated to “Macro Setup”...
  • Page 33 Channel Status Set whether it activates all analog channels. Defult value is “On”. Recording Speed/Quality There are all 5 setup conditions. (No Rec./Low/Standard/High/Custom). The conditional Setup except “Custom” comes to auto synchronize with “Speed(ips)”and “Quality”, Quality can set the each separately. At the setup condition of “Alarm Recording”, “Standard”와 “Pre/Post Alarm”...

  • Page 34: Camera Setup

    5.2. Camera Setup This is to setup the condition of every camera. At Quick Setup menu, it sets every camera to the same condition. Set values are applied in same at monitoring & recording mode. <Button Input order> After pressing [MENU], shift to “Cam # 1~Cam #16” inferior menu of “Camera”. Name Set Camera name.
  • Page 35 This is shown the video signal(NTSC/PAL) input only, and its setup is carried through Jumper in MD1600H. When booting MD1600H, it will automatically recognize video signal from first recognized video signal set by examing from ch 1 to 16. If there is no video input connection, it will follow Jumper set.
  • Page 36 Brightness/Contrast Select the value from “–9” and “+9” using [◄ ] or [► ] buttong after pressing [ENTER]. Covert Covert On will hide the channel at Monitoring mode. Select “A / B / Both / Off” using [◄ ] or [► ] buttong after pressing [ENTER]. PTZ Home/PTZ Idle Time Shift to Preset assigned if it has no movement in certain time while PTZ control Set Preset number and Time using [◄...

  • Page 37: Manual Recording Setup

    5.3. Manual Recording setup This menu is to set video recording condition by user when pressing [REC] button. If manual recording starts, Normal Rec & Event Rec is ingored and it records based on user recording setup. Recording Speed/Quality There are all 4 setup conditions. (No Rec/Low/Standard/High/Custom). Setup condition except “Custom” will synchronize “Speed(ips)”...

  • Page 38: Schedule Recording Setup

    <Note> 1. In case of set ‘No Rec.’ in Schedule Rec., it records as a set of Pre Alarm. While Schedule Recording, it records Pre Alarm section in speed(ips) of a set Schedule Rec. 2. When Post Alarm is set to Latched, it maintains user recording continuously till the stop pressing [REC] button by user.

  • Page 39: Setup By Channel

    <Note> 1. The difference of recording setup in Quick Setup is that there is no audio recording setup, and sets whether Special Time Recrding & Event Recording sets or not. 2. What Alarm Recording Off is set, Alarm Rec. menu is not available. To set Alarm Rec. menu, Alarm Recording of Recording menu should be set to “On”...
  • Page 40 <Time Schedule Setup> Shift to“System” menu to set Time Schedule. Weekday Start/End Set Time zone from Monday to Sunday using Left, Right key button. The unset zoon can be set to Weekend time zone. Day Start/End Set Day time zone using Up, Down button. The unset zoon can be set to Night time zone. Recording Speed/Quality There are all 5 setup conditions.
  • Page 41 Resolution There are all 3 conditions. (CIF/HALF/D1). At this menu, resolution set is applied to every User recording, Event recording. CIF : 360x240 @ NTSC, 360x288 @ PAL HALF : 720x240 @ NTSC, 720x288 @ PAL (HALF D1) D1 : 720x480 @ NTSC, 720x576@ PAL (FULL D1) Special Time Recording This menu is to differenciate recording conditions by setup of specific time zone.

  • Page 42: Alarm Recording Setup

    Event Recording After pressing [ENTER] button, set “On/Off” using [◄ ] or [► ] button. Detailed Alarm recording conditions sets from “Alarm Recording” menu. Here only can set recording according to alarm recording setup. 5.5. Alarm Recording Setup This menu is to set Alarm Recording condition. After setup Recording condition, “Event recording” menu from “Recording”...

  • Page 43: Motion Detection Setup

    Configuration It can set 16 sensors (S1~S16) separately. 5.5.2. Motion Detection Setup This menu is to set MD of each channel. Global sets all channels (Cam #1~Cam#16) in the same together, and setup can differ separately. Motion Detection It sets 4 different sensitivity of MD; Off, Lowest, Low, Std, High, Highest. MD Area It sets MD zone.
  • Page 44 5.5.2.1. Motion Detection Setup by Channel MD setup by channel is same as Global setup. And it can set MD zone additionally when MD sets by channel. Custom Area It sets MD zone by user NTSC 22x15, PAL 22x18 First default value is set to “Select All”. If “Custom Area” pressed, Window for MD zone setup is opened.
  • Page 45 < MD Zone Setup > It can set MD zone by user directly. If “Custom Area” is pressed, sell NTSC 22x15, PAL 22x18 for setup is displayed. Selected MD zone is in grey color. To select MD zone, use direction key for the wanted zone and press“ENTER” to apply.

  • Page 46: Text Setup

    5.5.3. Text Setup This menu is to set text data input. It has to be set COM1 part from “System -> Serial Setup” menu on OSD. Recording It is On or Off to save the Text input. Sync Text With Select the channel synchronize with Text data.
  • Page 47 Delimiter Value of Delimiter can be different according to every device. Refer to their manual or inquire it to purchasing stores of its model. Timeout(ms) Following lines defined here means maximum number of text line from one data. Even if there is standized data, there can be a short and long data.

  • Page 48: Global Alarm Recording

    5.5.4. Global Alarm Recording Set all analogue channels in same condition. Sensor/MD Set synchronizing with Sensor/MD. Pairing means 1:1 synchronization between the channel and Sensor/MD. Text When set “On”, it deals text input of relevant channe as Alarm Event and is saved. <Note>...

  • Page 49: Setup By Channel

    5.5.5. Setup by Channel Alarm Source (*=All) Through Alarm Source, 4 Sensors and 1 MD, Text input is selectable. Selection of Sensor is set by pressing relevant number button. Selection of MD, Text can be On/Off by direcitional key. Select Preset of PTZ by relevant Alarm input. <Note>...
  • Page 50 Post Alarm (sec) It can set max. 60 seconds. <Note> 1. In case of set ‘No Rec.’ in Schedule Rec., it records as a set of Pre Alarm. While Schedule Recording, it records Pre Alarm section in speed(ips) of a set Schedule Rec. 2.

  • Page 51: Alarm Action Setup

    5.6. Alarm Action Setup According each Time schedule, it sets Relay action. It sets to 5 different time period, Full Time, Weekday(Day), Weekday(Night), Weekend(Day), Weekend(Night). After Schedule setup, it sets Relay, Buzzer, Email etc to operate Alarm action. 5.6.1. Schedule Select Action Source Sensor and MD can be set max 4 or ANY for Relay1~Relay4, Buzzer, E-mail.

  • Page 52: Setup

    5.6.2. Setup Relay Configuration Set the use or not for R1~R4. Buzzer Set the use of Buzzer or not. E-mail Addr. Input E-mail address to inform Alarm. Sender Addr. Input “Sender” address in the typr of who@where. Mail Duration (min) E-mail notification is to send message in terms of Mail Duration set, but not every time that Alarm is occurred.

  • Page 53: System Alarm

    <Note> Network setup is set to DNS for E-mail notification. 5.6.3. System Alarm 5.6.3.1. System Alarm Setup It is to set ON/OFF of Alarm for the notification of system faulty. HDD Fail Alarm action is operated when HDD disconneced or abnormal action. HDD Almost Full It operates alarm action when connected HDD is almost full.
  • Page 54 Password Fail It operates Alarm when wrong User or Admin password input. WRS Reg. Fail It operates Alarm when disconnection of WRS. 5.6.3.2. Alarm Method Setup It is to set ON/OFF of Alarm when system alarm is occurred. Warning Message When setup this menu, it display warning message through pop-up.

  • Page 55: Monitor Setup

    5.7. Monitor Setup It sets the monitor for the display of video from monitor 1 to 4. Available meni for monitor 1~4 are all same. Alarm Pop-up (sec) It sets auto Pop-up display for the alarm. Pop-up display time can be set from 5~10 second. If it sets to “Keep”, it keeps to display Pop-up image and press any button to release Keep mode.

  • Page 56: System Setup

     4 divisions(5,6,7,8)  Full mode(5)  Full mode(8)  9 divisions(9,10,11,12,13,14,15,16). 5.8. System Setup 5.8.1. Audio Setup MD1600H supports 4channel Audio recording. But it operates with any channel when video playback. Recording It sets whether Audio records or not.

  • Page 57: Time Schedule Setup

    5.8.2. Time Schedule Setup It sets the time period from Week & Weekend, Day and Night. Weekday Start/End Using Left, Right key sets the time period from Weekday. Other unassigned time is for the Weekend. Day Start/End Using Up, Down button sets Day time period. Other time is applicable to the Night time.

  • Page 58: Special Time

    5.8.3. Special Time It can set another specific time zone in each time zone(Week day, Week night, Weekend day and night), For example, various conditions setting separately such as mealtime or meeting time is applicable. It used for the set of regular exceptial time. Max. 4 different specific time can set. Exception Days It used for the setup of irregular exceptional time, max.

  • Page 59: Security Setup

    5.8.4. Security Setup 5.8.4.1. Local Password User Password It is only capable of monitoring and playback only with user registery. Default set is “1111”. Admin Password Authorized administrator can control every function. Default set is “9999”.
  • Page 60 5.8.4.2. Remote Users Admin ID setup Admin ID “admin” cannot be changed. Password of admin is set and has all rights and unchangeable. User ID setup Max. 10 user’ s ID can be set. To register the user, change Use’ s value to “Y” and input ID & password. Basic value is available for all monitoring/playback/Relay.

  • Page 61: Disk Setup

    5.8.5. Disk Setup Auto Deletion When no HDD space left for recording, it deletes the recorded data automatically. Backup Reminder This menu is to inform backup time by everyday, every week, every month. Day/Date/Time It applies the value of setup differently according to value of “Backup Reminder”. Block PlayBack This menu is to playback the recorded images from HDD in limited time.

  • Page 62: Network Setup

    5.8.6. Network Setup There are 5 Sub menus. ; Network, xDSL, WRS, Port Setting, NTP Setting 5.8.6.1. Network When eDVR connects to network, it is to set relevant network information. Type It sets the type(Ethernet/xDSL) of network line connected to eDVR. It sets ‘Ethernet’at the connection of network through leased line, Cable model or LAN based connection.
  • Page 63 ‘DHCP’is used in LAN that DHCP server works. Nornally, in mid or large scale, it operates DHCP server via LAN but generally use NAT (Network Address Translation) function via HUB in small. IP Address, NetMask, and Gateway Address, DNS, Port, Bandwidth limit It sets IP address, Network Mask, Broadcast address, Gateway , DNS address, and Port, Bandwidth limit.
  • Page 64 IP address, it renews the information in WRS server regularly. If user registers the interval ‘0’ or eDVR does not transmit any data for 2 days, the data is removed from WRS. WRS URL This menu is to set server address to register. WRS addresses that WebGate operates now are www.webgateinc.com or mycam.to.
  • Page 65 <Attention> 1. If domain address such as www.webgateinc.com or mycam.to is input in WRS URL, DNS server IP should be noted on “System  Network  DNS1”. 2. DHCP line such as Cable/DSL receives DNS address automatically and does not require an entry. Group ID Group ID is to set group name that eDVR registered.
  • Page 66 5.8.6.4. NTP Setting NTP(Network Time Protocol) synchronizes the time of every devices connected to network. It consists of Server that offers standard time on network, and Client for synchronization that receives the time from server connected. Sync With NTP It can On/Off NTP function. NTP Mode It sets NTP mode of eDVR operating in Client or both.

  • Page 67: Serial Setup

    It sets interval (min.) of Time synchronization. <Note> When NTP Mode is Client, Sync with NTP must be set to On. 5.8.7. Serial Setup MD1600H can set all 4 COM port. Device Set external device connected. Interface This menu is to set which interface can use among RS485 from “RS485” menu.

  • Page 68: Status Overview

    5.8.8. Status Overview It shows status & temperature of HDD relevant to video recording and Fan speed. Earliest / Latest Recording It shows intial starting time and last time of the recorded file. Disk Capacity It shows total HDD capacity installed. Used Space It shows HDD capacity recordable.

  • Page 69: Miscellaneous

    FAN RPM It shows FAN speed installed in eDVR. 5.8.9. Miscellaneous <Order of Button input> - After press [MENU] button, move to “Miscellaneous” inferior to “System”. Remote Control ID Max 16 controller ID can set up and contril via 1 remote controller. Set to Off if it is not used. <How to register Remote Controller>...
  • Page 70 Keyboard Control Addr This menu is to set Keyboard address when all functions of eDVR is controllered by Keyboard button. Default value is set to “1”. If several eDVRs connect to a keyboard, 32 channel can clash. Then set to the other address of keyboard.

  • Page 71: Disk Manager (Utility)

    5.9. Disk Manager (Utility) It explains adding or formatting internal, external Hard disk. eDVR supports various external storage. < Order of Button input> - After press [MENU] button, move to “Utility” inferior to “System”.

  • Page 72: Disk Manager

    5.9.1. Disk Manager Installed Hard disk is automatically recognized. Select Disk Select disk to set. Action Select wanted work among the menus, “Add/Remove/ Confirm Removed/Add used”. [Add] : Add Disk. Use disk that there is no partion table. Partion table can be removed from PC.
  • Page 73 deleting data through Add Used. FAT32 Format when connecting external Hard disk. FAT32 Format Execute FAT32 Format for Backup/Copy in partition of under 250GB. For execution of FAT32 format, creat partition through disk manager of PC first. If HDD size is over 250GB, create several partitions smaller than 250GB and execute FAT32 formate in each partition.

  • Page 74: Usb Utility

    5.9.2. USB Utility It supports firmware upgrading and setup saving & sending, Text file saving for printing set value through USB. Update F/W After saving upgrade firmware for USB use to USB device, connect eDVR and press ‘Update F/W’for firmware upgrading. Upgrade firmware for USB use is supplied in “~.date” file. Print Settings(.txt) Function to save Set value for printing into USB device in Text file.
  • Page 75 Load Settings Set the system as set value saved in USB device. Save Settings Save present set value to USB device.

  • Page 76: Extension

    Extension 6. External device connection External device connection is based on the standard of MD1600H 6.1. Using Text device There are 4 essential setups to use Text devices; Text menu, RS232 menu of Serial Setup, Alarm Rec. menu, Recording menu.

  • Page 77: Setup In Rs232 Menu Of Serial Setup

    6.1.2. Setup in RS232 menu of Serial Setup Set connectable device in COM1 of Serial Setup menu, and also set Baud Rate, Parity, Stop, Data with relevant value.

  • Page 78: Setup In Alarm Rec

    6.1.3. Setup in Alarm Rec If there is video channel want to record with Text sync., set Text Event from Off to On.

  • Page 79: Setup In Recording

    6.1.4. Setup in Recording If any channel like to record with Text, set Alarm recording to ‘On’. Full Time is to set all Week day & night, Weekend day & night, and change menu to set Weekday and Weekend differently. <...

  • Page 80: Using Keyboard

    6.2. Using Keyboard There are 2 essential setups to use Keyboard; RS232 menu of Serial Setup, PTZ menu of Serial Setup 6.2.1. Setup in COM1 menu of Serial Setup Set connectable device in RS232 in Serial Setup menu to Keyboard. Also set Baud Rate, Parity, Stop, Data with relevant value.

  • Page 81: Appendix

    APPENDIX APPENDIX APPENDIX...

  • Page 82: Technical Specifications

    #1. Technical Specifications General 32bit RISC Processor Flash memory 32MB 256MB Main memory Embedded LINUX Video channel 16Ch. analog video inputs via BNC connector NTSC or PAL video format are supported (Auto detect) Storage device Int.: 4 HDD bays including 2 hot swap-bay Ext: 2 IEEE 1394b (FireWire) connection ports* 2 eSATA connection ports 1 Network Storage port (RJ45)*...

  • Page 83: Monitor Output

    Schedule recording Daily : Day / Night / Four-segment time frame Weekly : Weekdays / Weekends, Exception days Conditions : Normal / Event Text Data recording POS/ATM transaction information archived along with corresponding video data Manual(Emergency) record triggered by font key Manual recording Audio Recording &...
  • Page 84 Environment 5 ~ 45℃ Operation temperature Storage temperature -10 ~ 55℃ Operation humidity 30~80%, free of condensation Storage humidity 93% below, free of condensation Data Backup/Expansion/Copy External HDD(via 1394b or eSATA) Data backup Internal CD-R/DVD-R 5~ 95% alarm Backup reminder External USB memory disk(USB 1.1 compatible) on USB port AVI Copy Input/Output...
  • Page 85 Power consumption Max. 85W Typical 60W Mechanical Dimension (WⅹDⅹH) 430.0 x 362.0 x 88.0 5.5 kg (with one HDD) Weight...

  • Page 86: Utilizing Ip Address In Local Network

    #2. Utilizing IP address in Local network #2.1. Outline When internet uses, it connects to another server for acquisition of data or email communication through IP address. So it is not connectable to Internet without IP address. At present, authorized IP has limits to use in worldwide. And there are 5 grades from A to E in network that possesses many IP.
  • Page 87 IP address : 3 numbers in X4 indicates Host ID that is addressed from 0 to 255. But, generally, 0 & 255 is used to network ID & Broadcast address, but 1 to 244 IP address used in practical. Network ID: As Local network ID, the address indicates network identity in Internet. Generally, it addresses most superior number in local network.
  • Page 88 (2) When structure 2 networks in same size (1/2 + 1/2), Sub-Network ID: xxx.xxx.xxx.0 Gateway Address: xxx.xxx.xxx.1 Subnet Mask: 255.255.255.128 Broadcast Address: xxx.xxx.xxx.127 IP Addresses: xxx.xxx.xxx.2 – xxx.xxx.xxx.126 Sub-Network ID: xxx.xxx.xxx.128 Gateway Address: xxx.xxx.xxx.129 Subnet Mask: 255.255.255.128 Broadcast Address: xxx.xxx.xxx.255 IP Addresses: xxx.xxx.xxx.130 –...
  • Page 89 (4) When structure 4 networks (1/4 + 1/4 + 1/4+1/4) Sub-Network ID: xxx.xxx.xxx.0 Gateway Address: xxx.xxx.xxx.1 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.63 IP Addresses: xxx.xxx.xxx.2 – xxx.xxx.xxx.62 Sub-Network ID: xxx.xxx.xxx.64 Gateway Address: xxx.xxx.xxx.65 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.127 IP Addresses: xxx.xxx.xxx.66 – xxx.xxx.xxx.126 Sub-Network ID: xxx.xxx.xxx.128 Gateway Address: xxx.xxx.xxx.129 Subnet Mask: 255.255.255.192...
  • Page 90 PelikanCam 555 W Lambert Rd Ste A Brea, CA 92821 Tel : (714) 672-0333 Fax : (714) 672-0360 support@pelikancam.com www.PelikanCam.com The contents of this manual can be modified in accordance with Firmware or Software upgrade. In the interest of continually improving products, approval & outlook can be modified without prior notice...
