User Manual
Package Contents
Please unwrap the product, and place the product on a flat place or in the place to be installed.
Check if the main unit and all the following accessories are included in the product package.
HDC400M
DVR
Battery
AC code
HDC401M
DVR
Battery
AC code
Remote Controller
HDD Bracket & Screw
SW & Manual CD
Remote Controller
HDD Bracket & Screw
SW & Manual CD
English
Mouse
Power Adapter
Quick Guide
Mouse
Quick Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WebGate HDC400M
Summary of Contents for WebGate HDC400M
-
Page 1: Package Contents
Package Contents Please unwrap the product, and place the product on a flat place or in the place to be installed. Check if the main unit and all the following accessories are included in the product package. HDC400M Remote Controller Mouse Battery HDD Bracket &... -
Page 2: Before Starting
English오류! 알려지지 않은 문서 속성 이름입니다. Before Starting Please take note of the followings before using this prod Do not use the product in outdoor Do not spill water or liquid in the connection part of the product ... -
Page 3: Connecting To The Monitor
English Connecting to the monitor Check resolution of monitor before connection. When using HDMI Port : 1920 x 1080p ( HDMI v1.2 Standard ) <Note> Make sure to use a camera supporting HD-SDI standard. We stongly recommend to use HDMI certified cable when connecting DVR output to HDMI monitor Connecting camera Connect HD-SDI camera to DVR using recommended coaxial cable. -
Page 4: Network Connection
English오류! 알려지지 않은 문서 속성 이름입니다. [Schedule] [Program] Schedule Recording Schedule recording is recording function based on schedule set by user. Please set DATE, TIME and Program. Set record mode as “Schedule & Event” and set each DATE and TIME. Program setup Menu ... -
Page 5: Network Setting
English Network Setting Menu Network Network Ethernet Set type as Ethernet and input IP, Netmask, Gateway, DNS provided by administrator. The way to input is using directional key or mouse wheel. ADSL(PPPoE) Change type for Network menu into xDSL then go to xDSL menu. Change Port in Ethernet (User must remember Port) Enter ID and P/W in xDSL menu provided when registered in PPPoE . - Page 6 English오류! 알려지지 않은 문서 속성 이름입니다. (4) Connect using DVR setup port of router address in the PC using same router. (DVR default port : 80). (5) Check internet address of router to access to DVR from external PC. (6) Connect to DVR setup port of internet address in router. (7) Webviewer installer downloader will be running once connection to DVR is achieved.
