WebGate Hybrid DVR Series Quick Manual

Hd-cctv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENGLISH
HD-CCTV DVR
Hybrid DVR Series

Quick Guide

(EN Rev 1.7)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hybrid DVR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WebGate Hybrid DVR Series

Summary of Contents for WebGate Hybrid DVR Series

  • Page 1: Quick Guide

    ENGLISH HD-CCTV DVR Hybrid DVR Series Quick Guide (EN Rev 1.7)

  • Page 2: Before Using The Product

    ENGLISH Components Please check the below to make sure you have every component. Remote Control & Batteries Mouse power cord Rack bracket(optional) * SD video input extension SW & Manual CD PoC Adaptor * Quick guide screw cable (*) * Varies between different models Before using the product, Please read the below carefully before using this product.
  • Page 3 ENGLISH HDMI Monitor connection 1920X1080p resolution is suppoeted. Please check if monitor can support this resolution before connection. DVR’s video output : 1920 x 1080p  <Warning> Use of HDMI certified cable is recommended when connecting to a HDMI Monitor. VGA Monitor connection 800X600, 1024X768, 1280X1024, 1920X1080 resolution is suppoeted.

  • Page 4: Hdd Registration And Format

    (2) Check “YES” for the fomatted HDD.. < > warning Please call Webgate or Webgate dealers for HDD compatibility Copy copy In case backup media is well connected, click [Copy] button in FUNC menu and back media is auto detected.

  • Page 5: Network Settings

    DDNS DDNS setting at DVR Menu  Network  DDNS User can give a domain name to a DVR by using WEBGATE’s DDNS service, WNS(Webgate Naming Service). DDNS setting at a DVR 1. Change DVR’s port which is not in use (e.g. 8000) 2.

  • Page 6: Record Configuration

    ENGLISH Record Configuration Menu  Record  Program Continuous Recording - The maximum recording performance for Normal and Event recording 1. Menu > Record > Record > Continuous Record > Program A > Program Edit 2. Select Program “A” and set all channels as Normal Record “FPS 30, Quality 7”, Event Record “FPS 30, Quality 7”...
  • Page 7 ENGLISH Playback Search name function description Playback button Use buttons to control the playback. screen Displays the playback videos. log viewer Displays the log seen on timeline Calendar/time Select a date on the calendar to view the data of the date. search timeline Displays the info of the unit and search the playback sections.
  • Page 8 ENGLISH Time search If the user enter a date and time and click , DVR’s playback time moves to that time. Calendar search When calendar search is run, it marks the dates on which there were recordings. Select a date from calendar you want to search, and it moves to that date.

  • Page 9: Remote Monitoring & Control

    ENGLISH Remote monitoring & control Users can connect DVRs, control and monitor it remotely by using Control Center (WEBGATE’s CMS program) Installation of Control Center Execute “Control Center Setup vx.x.x.exe” to install the Control Center. Start of Control Center After installation is completed, click “Control Center Monitor” icon and execute it.
  • Page 10 ENGLISH Add Unit Click [Add] icon on the toolbar or execute [Add Unit] by clicking mouse right button at “My Units”. 1) Select “URL/IP Adress” 2) Enter proper IP address and Port, then click [Find] button. If the DVR is located inside local network, you can easily find the DVR by clicking [Auto Detect] button.
  • Page 11 ENGLISH Port Forwarding & P2P Cloud Manual port forwarding (1) Connect to a router by default IP address. (2) Go to “Port range forward” setup page. (3) Set DVR IP address & Port of DVR connected to the router then check ‘Enable’ and save. (4) Connect to IP and Port number of DVR which are assigned from PC to router.There will be Webviewer login page once DVR connection is successful.
  • Page 12 ENGLISH (6) Connect to external internet IP address of router and DVR’s setup port. If DVR connection is successful, you may see Webviewer’s login page of DVR. (7) Enter ID and Password of DVR의 to see monitoring page in which live image of DVR is displayed. UPnP port forwarding When using Internet Sharing device(Router) which supports UPnP, this function will let users to have an easy access to many DVRs that are connected to the internet sharing device.
  • Page 13 ENGLISH HDcctv Alliance Premium to your HD-CCTV W E B G A T E WEBGATE Div, Daemyung Corporation Co., Ltd. 6F,Hanlim Venture Town B/D, 284, Gongdan-ro, Gunpo-si, Gyeonggi-do, Korea(15809) Tel +82. 31. 428. 9383 Fax +82. 31. 455. 3955 sales@webgateinc.com...
