Final Assembly - ETC Source Four PARN Assembly Manual

16

Final Assembly

Reference Part
Number Number
1 7061A2020
2 7061A2020-1
3 7061A2001
4 7061A2001-1
5 7061A3006
6 7061A3006-1
7 7061A4010-2
8 7061A4010-1
9 HW5125
10 HW5126
11 HW5139
12 HW5172
13 HW522
14 HW8144
15 HW8144-01
16 7061A3007
17 7061A4014
18 7061A4013
19 7061A4015
20 HW2154
21 7061A4012
Source Four PARNel Assembly Guide
14
15
13
11
7
8
Description
S4 PAR zoom base assembly, black
S4 PAR zoom base assembly, white
Lamp socket assembly, black
Lamp socket assembly, white
Yoke bracket, black
Yoke bracket, white
PAR zoom clear/wave lens
PAR zoom stippled/wave lens
Bolt, carriage 5/16-18 X .75" BO
Washer, flat .375 X .875 X .078 B/Z
Washer, 1/4 split ring lock, B/Z
Bolt, hex 1/4-20 X 1.0" grade 5 B/Z
Washer, flat 1/4 B/Z
Handle, yoke knob, black
Handle, yoke knob, white
PAR gel frame, 7 .25"
Focus knob gear
Focus knob bushing
Focus knob
Screw, PPH, 6-19 X 1/2L, 48-2 Plastite
Lens rotator
9
10
12
17
18
19
20
Figure 1
5
3
6
4
13
11
12
21
1
2
Quantity
Required
1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
1
1
1
1
3
