Page 1: User Manual
BiPAC 5200G RC Series 802.11g ADSL2+ Firewall Router User Manual Version released 2.12.13.0(RE2.C31)3.12.17.0 Last revised date 9-14-2010... -
Page 2: Table Of Contents
Table of Contents Chapter 1: Introduction ..................1 Introduction to your Router ................1 Features .....................3 Application Illustrations ...............6 Chapter 2: Installing the Router ................7 Package Contents..................7 Hardware Overview ...................8 Front LEDs ..................8 Rear Panel ..................9 Cabling .....................10 Chapter 3: Basic Installation ................11 Network Configuration ................12 Configuring PC in Windows 7 ............12 Configuring PC in Windows Vista............14... - Page 3 Routing ....................45 NAT ....................47 ADSL ....................52 Access Management ................53 ACL ....................53 Filter ....................54 SNMP ....................58 UPnP ....................59 DDNS ....................60 Maintenance ....................61 Administration ...................61 Time Zone ..................62 Firmware ...................63 SysRestart ..................64 Diagnostics ..................65 Status .......................66 Device Info ..................66 System Log ..................68 Statistics ....................69 Help ......................72 Appendix: Product Support &...
-
Page 4: Chapter 1: Introduction
Chapter 1: Introduction Introduction to your Router Welcome to Billion BiPAC 5200G RC Series ADSL2+ Firewall Router. Your Billion router is an “all- in-one” unit, combining an ADSL modem, ADSL router and Ethernet network switch, providing everything you need to get the machines on your network connected to the Internet over your ADSL broadband connection. - Page 5 For advanced users, Virtual Service function allows the product to provide limited visibility to local machines with specific services for outside users. An ISP (Internet Service Providers) provided IP address can be set to the product and then specific services can be rerouted to specific computers on the local network.
-
Page 6: Features
Features ADSL Multi-Mode Standard Supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It also supports rate management that allows ADSL subscribers to select an Internet access speed suiting their needs and budgets. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt(G.992.1); G.lite(G992.2)), G.hs (G994.1), G.dmt.bis (G.992.3), G.dmt.bisplus (G.992.5)). - Page 7 web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others. Domain Name System (DNS) Relay It provides an easy way to map the domain name (a friendly name for users such as www.yahoo. com) and IP address. When a local machine sets its DNS server with this router’s IP address, every DNS conversion request packet from the PC to this router will be forwarded to the real DNS in the outside network.
- Page 8 Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI. Firewall Supports simple firewall with NAT technology and provides option for blocking access from Internet, like Telnet, FTP, WEB, SNMP and IGMP. PPP over Ethernet (PPPoE) Provides embedded PPPoE client function to establish a connection.
-
Page 9: Application Illustrations
Application Illustrations 5210G RC 5200G RC / 5200G RD... -
Page 10: Chapter 2: Installing The Router
Chapter 2: Installing the Router Important Note for Using this Router Package Contents BiPAC ADSL2+ Firewall Router Power adapter CD containing the online manual USB cable (only for BiPAC 5210G RC) RJ-11 ADSL/telephone Cable Quick Start Guide Micro-filter / Splitter (optional) Ethernet (RJ-45) Cable... -
Page 11: Hardware Overview
Hardware Overview Front LEDs 5210G RC 5200G RC / 5200G RD Meaning Lit red when power is ON. Power Lit green when the system is ready. Lit when connected to an Ethernet device. Ethernet Lit green when the speed of transmission hits 10/100Mbps. Blink when data is being Transmitted / Received. -
Page 12: Rear Panel
Rear Panel 5210G RC 5200G RC / 5200G RD Meaning Power Switch Power ON / OFF switch. Power adapter Connect with the supplied power adapter. When the device power is on, press to reset or to restore its factory default setting. Reset Press 1-3 seconds to reset the device. -
Page 13: Cabling
Cabling One of the most common causes of problem is bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the front panel of your router is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify if you are using the proper cables. Make sure that all devices (e.g. -
Page 14: Chapter 3: Basic Installation
Chapter 3: Basic Installation The router can be configured through your web browser. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 7/98/NT/2000/XP/Me/Vista, etc. The product provides an easy and user-friendly interface for configuration. Please check your PC network components. -
Page 15: Network Configuration
Network Configuration Configuring PC in Windows 7 1. Go to Start. Click on Control Panel. 2. Then click Network Internet. 3. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. 4. - Page 16 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.
-
Page 17: Configuring Pc In Windows Vista
Configuring PC in Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When the Network and Sharing Center window pops up, select and click on Manage network connetions on the left window column. - Page 18 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.
-
Page 19: Configuring Pc In Windows Xp
Configuring PC in Windows XP 1. Go to Start > Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. -
Page 20: Configuring Pc In Windows 2000
Configuring PC in Windows 2000 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. -
Page 21: Configuring Pc In Windows 95/98/Me
Configuring PC in Windows 95/98/Me 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP > NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3. -
Page 22: Configuring Pc In Windows Nt4.0
Configuring PC in Windows NT4.0 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol click Proerties. 3. Select the Obtain an IP address from a DHCP server radio button and click... -
Page 23: Step By Step Installation
Step by Step Installation 1. Insert the CD into the CD-ROM drive. 2. Execute the Windows Utility. 3. When the Welcome screen appears, click on Next. 4. When the Hardware Installation wizard appears, you will notice that there are 4 diferent links on the screen. - Page 24 4.2 LAN Connection 4.3 ADSL Connection 4.4 USB Connection (Only for 5210G RC)
- Page 25 4.5 Micro-Filter Connection 4.6 Splitter Connection...
- Page 26 5. When Hardware Installation is complete, click Next to proceed to Network Card Seletion step. 6. Diagnostic Screen: If the connection fails, the FAIL status will be displayed on the screen. Check the connection of the router to see if it is correct.
- Page 27 10. Configure the Wireless LAN setting. Then click Next. 11. Click Next to run a diagnostic test on all your configurations and connections. 12. When all diagnostic tests are passed, you have completed the installation and can conect to the internet. 13.
-
Page 28: Factory Default Settings
Factory Default Settings Before configuring your router, you need to know the following default settings. Web Interface (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. Device LAN IP settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site PPPoE... -
Page 29: Information From Your Isp
Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) to find out what kind of service is provided such as DHCP (Obtain an IP Address Automatically, Static IP (Fixed IP Address) or PPPoE. Gather the information as illustrated in the following table and keep it for reference. -
Page 30: Configuring With Your Web Browser
Configuring with your Web Browser Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt will appear. The default username and password are “admin” and “admin” respectively. (See Figure 3.14) Figure 3.14: User name &... -
Page 31: Chapter 4: Configuration
Chapter 4: Configuration At the configuration homepage, the top navigation column provides you the link to each configuration page. The category of each configuration page is listed as below. Quickstart Interface Setup Advanced Setup Access Management Maintenance Status Help Quickstart For detailed instructions on configuring WAN settings, see the Interface Setup section of this manual. - Page 32 Click RUN WIZARD, then the Quick Start Wizard window appears, follow it step by step to configure the Quick Start. Step 1: Setup your new password. Then click Next.
- Page 33 Step 2: Choose your time zone, then click Next.
- Page 34 Step 3: Set your internet connection. Choose the appropriate internet connection and enter the necessary information from your ISP.
- Page 35 Step 4: Wireless network configuration.
- Page 36 Step 5: Save settings of this ADSL router.
-
Page 37: Interface Setup
Interface Setup Click this item to access the following sub-items to configure the router: Internet, LAN and Wireless. These functions are described in the following sections. -
Page 38: Internet
Internet... - Page 39 ATM VC ATM settings are used to connect to your ISP. Your ISP provides VPI, VCI settings to you. In this Device, you can setup a total of 8 VCs on different encapsulations, if you apply 8 different virtual circuits from your ISP. You need to activate the VC for it to take effect. For PVCs management, you can use ATM QoS to setup each the priority of each PVC traffic line.
- Page 40 Dynamic IP: Select this option if your ISP provides you an IP address automatically. This option is typically used for Cable services. Please enter the Dynamic IP information accord- ingly. Static IP: Select this option to set static IP information. You will need to enter in the Connetion type, IP address, subnet mask, and gateway address, provided to you by your ISP.
- Page 41 Bridged IP in the Encapsulation field in the previous screen. NAT: Select this option to Activate/Deactivated the NAT (Network Address Translation) function for this VC. The NAT function can be activated or deactivated per PVC basis.Default Route: if enable this function, the current PVC will be the default gateway to internet from this device. TCP MTU Option: Enter the TCP maximum transmission unit (MTU).
-
Page 42: Lan
A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a building. Router Local IP IP Address: Enter the IP address of ADSL Router in dotted decimal notation, for example, 192.168.1.254 (factory default). - Page 43 membership in a Multicast group - it is not used to carry user data. BiPAC 5200G RC Series router supports IGMP-v1, IGMP-v2 and IGMP-v3. Select Disabled to disable the function. IGMP Snoop: IGMP helps to reduces the network traffic.Choose Disable or Enable IGMP Snoop function.
-
Page 44: Wireless
Wireless This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as simple as two computers with wireless LAN cards communicating in a peer-to-peer network or as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN. - Page 45 Setting this attribute to be larger than the maximum MSDU (MAC service data unit) size turns off the RTS/CTS handshake. Setting this attribute to zero turns on the RTS/CTS handshake Enter a value between 1500 and 2347. Fragmentation Threshold: The threshold (number of bytes) for the fragmentation boundary for directed messages.
- Page 46 Wireless MAC Address Filter The MAC filter screen allows you to configure the router to give exclusive access up to 8 devices (Allow Association) or exclude up to 8 devices from accessing the router (Deny Association). Every Ethernet device has a unique MAC (Media Access Control) address. The MAC address is assigned at the factory and consists of six pairs of hexadecimal characters, for example, 00:AA:BB:00:00:02.
- Page 47 Key 1 to Key 4: Enter the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router. There are four keys to your selection. The input format is in HEX style, 10 and 26 HEX codes are required for 64-bit WEP and 128-bit WEP respectively.
-
Page 48: Advanced Setup
Advanced Setup Firewall Your router includes a firewall for controlling Internet access from your LAN that helps to prevent attacks from hackers. In addition to this, when using NAT (Network Address Translation) the router acts as a “natural” Internet firewall, since all PCs on your LAN use private IP addresses that cannot be directly accessed from the Internet. -
Page 49: Routing
Routing If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet. #: Item number Dest IP: IP address of the destination network Mask: The destination mask address. Gateway IP: IP address of the gateway or existing interface that this route uses. - Page 50 Add Route To add a new route, press the Add Route button. Then fill in all the parameters needed for the route. When done, press the Save button. Destination IP Address: This is the destination subnet IP address. IP Subnet Mask: A subnet mask allows IP networks to be subdivided for security and performance purposes.
-
Page 51: Nat
The NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet. The default setting is Dynamic NAT. It provides dynamic Network Address Translation capability between LAN and multiple WAN connections, and the LAN traffic is routed to appropriate WAN connections based on the destination IP addresses and Route Table. - Page 52 The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets that do not use a port number which is already used by any other Virtual Server entries will first be checked by the Firewall and NAT algorithms before it is passed to the DMZ host.
- Page 53 The reason for this is that when using NAT, your publicly accessible IP address will be used by and point to your router, which then needs to deliver all traffic to the private IP addresses used by yourPCs. Please see the WAN configuration section of this manual for more information on NAT.The device can be configured as a virtual server so that remote users accessing services such as Web or FTP services via the public (WAN) IP address can be automatically redirected to the local servers on the LAN network.
- Page 54 IP Address Mapping Address Mapping Rule: Shows the PVC where the rule will be applied to. Rule Index: Choose the rule number. Rule Type: One-to-one: This is the mode maps one local IP address to one global IP address. Note that port numbers do not change for the One-to-one NAT mapping type.
- Page 55 N/A for Server port mapping. Local End IP: This is the end range for Inside Local IP Address (ILA). If your rule is for all local IP addresses, then enter 0.0.0.0 as the Local Start IP address and 255.255.255.255 as the Local End IP address.
-
Page 56: Adsl
ADSL ADSL Mode: The default setting is Auto Sync-UP. This mode will automatically detect your ADSL, ADSL2+, ADSL2, G.dmt, G.lite, and T1.413. But in some area, multimode cannot detect the ADSL line code well. If it is the case, please adjust the ADSL line code to G.dmt or T1.413 first. If it still fails, please try the other values such as ALCTL, ADI, etc. -
Page 57: Access Management
Access Management Access Control Listing allows you to determine which services/protocols can access BiPAC 5200G RC Series router interface and from which computers. ACL: Select whether to activate to configure this ACL function. If you select Deactivated, then the following is not available. ACL Rule Index: This is item number. -
Page 58: Filter
Filter You can Filter the packages by IP port, MAC and Application. Filter Type Filter Type Selection: There are three types ”IP/MAC Filter”, ”Application Filter”, and “URL Filter” that user can select for this connection. IP / MAC Filter Set Editing IP/MAC filter Set Index: This is item number. - Page 59 IP / MAC Filter Rule Editing IP/MAC Filter Rule Index: This is item number. Rule Type: Choose “IP” or “MAC” rules Active: Select Yes from the drop down list box to enable IP filter rule. Source IP Address: The source IP address or range of packets to be monitored. Subnet Mask: It is the source IP addresses based on the above subnet IP source.
- Page 60 Application Filter Application Filter: Select this option to Activated/Deactivated the Application filter. ICQ: Select this option to Allow / Deny ICQ. MSN: Select this option to Allow / Deny MSN. YMSG: Select this option to Allow / Deny Yahoo messenger. Real Audio/Video: Select this option to Allow / Deny Real Audio / Video.
- Page 61 Active: Select Actived to enable URL Filter. URL Index: This is item number. URL: Allow you to prevent users on your network from accessing particular websites by their URL. Press SAVE to confirm your settings, and the corresponding settings will be listed in the URL Filter Listing table.
-
Page 62: Snmp
SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. BiPAC 5200G RC Series router supports SNMP agent function that enables manager station to manage and monitor the router through the network. -
Page 63: Upnp
UPnP UPnP offers peer-to-peer network connectivity for PCs and other network devices, along with controlling data transfer between devices. UPnP offers many advantages for users running NAT routers through UPnP NAT Traversal and on supported systems. Task handling such as port forwarding becomes easier by letting the application control the required settings, removing the need for the user to control advanced configuration of their device. -
Page 64: Ddns
DDNS Dynamic DNS function allows you to alias a dynamic IP address to a static hostname, allowing users whose ISP does not assign them a static IP address to use a domain name. This is useful when hosting servers via your ADSL connection, so that anyone wishes to connect to you may use your domain name rather than having to use your ever changing dynamic IP address. -
Page 65: Maintenance
Maintenance Administration In default setting, the username and password are both "admin". You can change the default password to ensure that someone cannot adjust your settings without your permission. Every time you change your password, please record the password and keep it safe. New Password: Type the new password in this field Confirm Password: Type the new password again in this field. -
Page 66: Time Zone
Time Zone The router does not have a real time clock onboard. Instead it gets the current time through the Simple Network Time Protocol (SNTP) from an SNTP server outside your network. Choose your local time zone. After a successful connection to the Internet, the router will retrieve the correct local time from the SNTP server you have specified. -
Page 67: Firmware
Firmware Your router firmware is the like a software that allows your router to operate and perform all its functions. Thus, by upgrading your router to the latest firmware, you can experience the greater features and functionality that have been created. To upgrade the firmware of your router, you should download or copy the firmware to your local environment first. -
Page 68: Sysrestart
SysRestart Click SysRestart with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings. -
Page 69: Diagnostics
Diagnostics The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. -
Page 70: Status
Status Device Info This page displays the current information for the ADSL Router. It will display the Firmware version, LAN, WAN, and MAC address information. Device Information Firmware version: This is the Firmware version. MAC Address: This is the router MAC Address. - Page 71 IP Address: LAN port IP address. Sub Net Mask: LAN port IP subnet mask. DHCP Server: LAN port DHCP role - Enabled, Relay or disabled. Virtual Circuit: There are eight groups of PVC can be defined. Status: “Not connected” or “Connected”. Connection Type: Name of the WAN connection.
-
Page 72: System Log
System Log Display system logs accumulated up to the present time. You can trace historical information with this function. -
Page 73: Statistics
Statistics Read-only information here includes port status and packet specific statistics. Also provided are "Transmit Statistics" and "Receive Statistics". Ethernet Interface: This field displays the type of port. Transmit Frames: This field displays the number of frames transmitted in the last second. Transmit Multicast Frames: This field displays the number of multicast frames transmitted in the last second. - Page 74 ADSL Transmit total PDUs: This field displays the number of total PDU transmitted in the last second. Transmit total Error Counts: This field displays the number of total error transmitted in the last second. Receive total PDUs: This field displays the number of total PDU received in the last second. Receive total Error Counts: This field displays the number of total error received in the last second.
- Page 75 WLAN Tx Frame Count: This field displays the number of frames transmitted in the last second. Tx Errors Count: This field displays the number of errors frames transmitted in the last second. Tx Drops Count: This field displays the number of drops frames transmitted in the last second. Rx Frames Count: This field displays the number of frames received in the last second.
-
Page 76: Help
Help This help page provides you some useful messages such as the introductions of some concepts and some guidances.When some problems are encountered, you can turn to this page for help. For example, if you don’t understand what is Quick Start, you can go to this page, click on Quick Start, then you’ll see some messages about it, and understand it quickly. - Page 77 If your router is not functioning properly, please refer to the suggested solutions provided in this chapter. If your problems persist or the suggested solutions do not meet your needs, please kindly contact your service provider or Billion for support. Problems with the router...
- Page 78 Problem with LAN interface Problem Suggested Action Cannot PING any PC on LAN Check the Ethernet LEDs on the front panel. The LED should be on for the port that has a PC connected. If it does not lit, check to see if the cable between your router and the PC is properly connected.
-
Page 79: Appendix: Product Support & Contact
However if your problems persist or you come across other technical issues that are not listed in the Troubleshooting section, please contact the dealer from where you purchased your product. Contact Billion Worldwide: http://www.billion.com MAC OS is a registered Trademark of Apple Computer, Inc.
