Elo TouchSystems 15D1 User Manual

15-inch lcd multifunction touchcomputer
Hide thumbs Also See for 15D1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
15D1 Touchcomputer User Guide
15D1 15-inch LCD Multifunction Touchcomputer
[Model 15D1]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15D1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elo TouchSystems 15D1

Summary of Contents for Elo TouchSystems 15D1

  • Page 1 15D1 Touchcomputer User Guide 15D1 15-inch LCD Multifunction Touchcomputer [Model 15D1]...
  • Page 2 Elo TouchSystems 15D1 Touchcomputer User Guide 15-inch LCD Multifunction Touchcomputer 15D1 Revision A P/N E674343 Elo TouchSystems 1-800-ELOTOUCH (1-800-356-8682) www.elotouch.com...
  • Page 3 References in this publication to Elo TouchSystems products or services do not imply that Elo TouchSystems intends to make them available in all countries in which Elo TouchSystems operates. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Elo TouchSystems to notify any person of such revisions or changes.

  • Page 4: Table Of Contents

    Safety ............. .27 15D1 U...
  • Page 5 Using the Phone ...........38 Regulatory Information Warranty Index 15D1 U OUCHCOMPUTER UIDE...

  • Page 6: Setup

    Chapter 3, “Options and Upgrades.” Unpacking Your Touchcomputer Check that the following items are present and in good condition: ← AND → Power cable US/Canada Power cable Europe Touchcomputer Recovery DVD and Ad clips Optional Quick Install Guide security screw 15D1 U OUCHCOMPUTER UIDE...

  • Page 7: Adjusting The Display

    Selecting the Language Windows uses English as the default language in menus and dialog boxes. You can change this language to suit your preferences. Follow these steps. In the Control Panel, select Regional and Language Options. 15D1 U OUCHCOMPUTER UIDE...
  • Page 8 If required, check the boxes for “Install files for complex script and right-to-left languages” and “Install files for East Asian languages.” Select the Regional Options tab. Select your preferred language from the drop-down list in the Standards and formats pane. 15D1 U OUCHCOMPUTER UIDE...
  • Page 9 ETTING P THE PERATING YSTEM Click Apply. Select your location from the drop-down list in the Locations pane. Click OK. 15D1 U OUCHCOMPUTER UIDE...

  • Page 10: Selecting The Time Zone

    The touchscreen is pre-calibrated for accurate touch response. If for any reason the touchscreen needs to be recalibrated, right-click the Elo icon in the Task bar and then click “Properties.” The following window opens. : Calibration not applicable to APR models. 15D1 U OUCHCOMPUTER UIDE...
  • Page 11 ALIBRATING THE OUCHSCREEN Click the Align button. This launches the calibration program. The window shown below opens. Follow the instructions to calibrate the touchscreen. 15D1 U OUCHCOMPUTER UIDE...

  • Page 12: Securing The Base

    ECURING THE Securing the Base There are two mounting options for the 15D1 touchcomputer. In both cases, the base must be mounted on a horizontal surface. Option 1: Secure from below. Use the four pretapped holes to secure the four m6 ◆...
  • Page 13 DVERTISING RACKETS Then insert the advertising material as shown below. 15D1 U OUCHCOMPUTER UIDE...

  • Page 14: Operation

    5 6 7 8 9 1. HDD status LED 2. Computer power LED 3. Head power LED 4. Touch power LED 5. Menu button 6. Left button 7. Right button 8. Select button 9. Power ON/OFF button 15D1 U OUCHCOMPUTER UIDE...

  • Page 15: On-Screen Display (Osd)

    Timeout: Adjusts the amount of time that the OSD menu is displayed. Language Changes language to English, French, Italian, German, Spanish, Japanese, Simplified Chinese, or Traditional Chinese. Recall Sets color recall and recall defaults. Restores original factory settings. 15D1 U OUCHCOMPUTER UIDE...

  • Page 16: Osd And Power Button Control

    LED Functionality Base Power Status LED The 15D1 base has two LEDs that indicate the power status and hard drive status. See the figure on page 9, item 1 for the location of this LED. The light can be green, flashing green, red, or off.

  • Page 17: Touch Power Status Led

    Hard disk drive activity is indicated by a flashing LED on the base, just under the computer power LED (#2 in the figure on page 9). Reading from and writing to the disk causes the LED to flash. LED Color to Observer State No activity Flashes green Activity 15D1 U OUCHCOMPUTER UIDE...

  • Page 18: Using The I/O Panel

    To access the I/O ports, open the cable cover door on the left side of the unit, as shown below. Optional security screw Opening for cables The touchcomputer provides a number of I/O interfaces for connecting a wide variety of compliant devices as shown in the following figure. 15D1 U OUCHCOMPUTER UIDE...
  • Page 19 I/O P SING THE ANEL 15D1 U OUCHCOMPUTER UIDE...
  • Page 20 : The Customer display, fingerprint reader and barcode scanner are designed to connect to the USB 2.0 ports on the I/O panel. If all three peripherals were connected, there would be four USB 2.0 ports remaining. 15D1 U OUCHCOMPUTER UIDE...

  • Page 21: Options And Upgrades

    Hard disk drive ◆ Printer power cable ◆ : The peripherals described are all options that are purchased separately. : Testing software is available in the folder 15D1 Test Applications, which is located on the Desktop. 15D1 U OUCHCOMPUTER UIDE...

  • Page 22: Magnetic Stripe Reader (Msr)

    (FPR) Magnetic Stripe Reader (MSR) You can add a magnetic stripe reader (MSR) to the 15D1 touchcomputer using a USB port located on the display head. The MSR is a USB 2.0 device that reads all three data stripes on standard credit cards or driver’s licenses conforming to ISO/ANSI standards.
  • Page 23 Double-click the MagSwipe HID Demo icon to start the test application. Slide a card through the MSR and verify that the data is displayed in the application window. If the card ID appears in the Reader Output window, the reader is functioning. 15D1 U OUCHCOMPUTER UIDE...

  • Page 24: Customer Display

    ERIPHERALS Customer Display You can optionally add a customer display to the 15D1 touchcomputer. Each display has two lines of 20 characters (2x20 VFD). The customer display can be adjusted to a 30 degree range up and down and swivels 30 degrees side to side.

  • Page 25: Fingerprint Reader (Fpr)

    Current draw – idle mode 140 mA (typical) Current draw – suspend mode 1.5 mA (typical) Image resolution 512 dpi Image color 8-bit gray level Scan capture size 14.6mm (nominal width) x 18.1mm (nominal length) Image capture speed 100 ms 15D1 U OUCHCOMPUTER UIDE...

  • Page 26: Barcode Scanner

    When a scanner is chosen, a USB-SSI (Simple Serial Interface) converter board is included. Both barcode scanners are powered with the USB interface. One-dimensional scanner (Elo P/N E946856) specifications: ◆ - Ability to generate 1-D scanning pattern - Low-cost solution - USB powered 15D1 U OUCHCOMPUTER UIDE...
  • Page 27 Scan the barcodes below to enable PDF417 and MicroPDF417. These are both types of 2-D barcodes. Now scan the barcode below to change the scanning pattern. Using this scanning pattern allows you to read 2-D barcodes (you can still read 1-D barcodes). 15D1 U OUCHCOMPUTER UIDE...
  • Page 28 In the box labeled Param Number, enter the value 238. In the box labeled New Value enter the value 1. Check the box labeled Permanent Param Change. Scan a barcode (sample given below). The scanned data should appear in the “Messages” section of SSIContainer. 15D1 U OUCHCOMPUTER UIDE...

  • Page 29: Wireless Card

    Wireless Card A wireless card can be installed as an option in the 15D1 touchcomputer to provide wireless LAN capabilities using a miniPCI slot. A PCI to miniPCI converter board is provided in the wireless kit.

  • Page 30: Third-Party Peripherals

    ARTY ERIPHERALS Third-Party Peripherals The 15D1 touchcomputer includes two pre-configured ports for a printer and cash drawer. These peripherals are not available from Elo TouchSystems. Printer Port A 24VDC printer power port to connect a compatible receipt printer is provided. The 24VDC printer power cable is Elo P/N E337867.

  • Page 31: Additional Hard Drives

    For additional information, see “Cash Drawer Port Specifications” on page 34. Additional Hard Drives The 15D1 touchcomputer comes with one standard 80GB hard disk drive. You can add an optional second SATA hard disk drive (Elo P/N E828965). Elo POS Demo Software POS demo software created by Elo TouchSystems is located on the Desktop.

  • Page 32: Safety And Maintenance

    Do not attempt to fit the plug into an outlet that has not been configured for this purpose. Do not use a damaged power cord. Only use the power cord that comes with your Elo TouchSystems touchcomputer. Use of an unauthorized power cord might invalidate your warranty.

  • Page 33: Care And Handling

    In the European Union, the Waste Electrical and Electronic Equipment (WEEE) directive label shown to the left indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. 15D1 U OUCHCOMPUTER UIDE...

  • Page 34: Recovering The Operating System

    Follow the on-screen instructions to complete recovery. : All data is deleted during the recovery process. The user must back up files when necessary. Elo TouchSystems does not accept liability for lost data or software. : The end-user must adhere to Microsoft's Licensing Agreement.

  • Page 35: Technical Specifications

    C H A P T E R Technical Specifications Touchcomputer Specifications : Not all operating systems or options are supported in all regions. Please contact your local Elo TouchSystems representative for details. Feature Description Processor Intel Celeron 430M 1.8GHz CPU 512K L2 cache, w/800MHz...
  • Page 36 Internal 12VDC universal-type power supply brick AC input voltage: 100-240V AC Input frequency: 50-60Hz Input current: 2.5-5A Max output power: 270W DC output: +3.3V / 5.0A +5V / 16.0A +12V / 12.0A +24V / 2.3A +5Vsb / 3A -12V / 0.4A 15D1 U OUCHCOMPUTER UIDE...
  • Page 37 OUCHCOMPUTER PECIFICATIONS Feature Description Max. power rating 15D1 touchcomputer (without peripherals, receipt printer, cash drawer, or power serial ports connected: 169.95 W Cash drawer: 2.4 W max. Receipt printer; 45.6 W max. Powered serial ports: 24 W max Total power drawn with all possible peripherals: 252.45 W...

  • Page 38: Connector Specifications

    SER DTR SER DTR SER GND SER GND SER DSR SER DSR SER RTS SER RTS SER CTS SER CTS SER RI 5V(default)/ 12V Printer Power Input Pin Definition Pin # Signal Name +24V Ground Flat 15D1 U OUCHCOMPUTER UIDE...

  • Page 39: Cash Drawer Port Specifications

    L ( + ) +12V/24V (default) for drawer kick-out supplied CD 2-drawer kick-out drive signal 2 ( - ) Ground Cash Drawer Port Power Selection Setting Function Pins 1-2 short/closed Pins 2-3 short/closed 24V (default) 15D1 U OUCHCOMPUTER UIDE...

  • Page 40: Display Screen Specifications

    (min.) Response time : 2.3 ms (typical) rise : 6 ms (typical) fall Display color 16.7 million colors Vertical viewing angle 60° looking up typical at a CR=10 (up/down) 65° looking down typical at a CR=10 15D1 U OUCHCOMPUTER UIDE...

  • Page 41: Environmental Specifications

    Non-operating (38.7°C maximum wet bulb 5 to 95% temperature) Altitude Operating 0 to + 12,000 feet [3,658m] Equivalent to 14.7 to 10.1 psia Non-operating 0 to + 40,000 feet [12,192m] Equivalent to 14.7 to 4.4 psia 15D1 U OUCHCOMPUTER UIDE...

  • Page 42: Technical Support

    You can access support information in System Properties by clicking the Support Information button. You can get to System Properties by either of the following methods: Right click My Computer and choose Properties. ◆ Click the Start button, select Control Panel, and double-click the System icon. ◆ 15D1 U OUCHCOMPUTER UIDE...

  • Page 43: Using The Web

    For online self-help, go to www.elotouch.com/go/websupport. For technical support, go to www.elotouch.com/go/contactsupport. For current Elo news, product updates, and announcements, or to register to receive our Touchcomputer newsletter, go to www.elotouch.com/go/news. Using the Phone Call toll-free 1-800-ELO-TOUCH (1-800-356-8682). 15D1 U OUCHCOMPUTER UIDE...

  • Page 44: Regulatory Information

    This Information Technology Equipment (ITE) is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards: 15D1 U OUCHCOMPUTER UIDE...
  • Page 45 AC adapter plugs. (Removing or cutting the line cord ground may increase RF emission levels and may also present a lethal shock hazard to the user.) vii. If you need additional help, consult your dealer, manufacturer, or an experienced radio or television technician. 15D1 U OUCHCOMPUTER UIDE...
  • Page 46 The following certifications have been issued for the monitor: Argentina S-Mark Russia PCT ◆ ◆ ◆ Australia C-Tick IMERC Taiwan BSMI ◆ ◆ ◆ Japan VCCI ◆ ◆ ◆ China CCC Korea EK/KCC ◆ ◆ ◆ China RoHS Mexico NOM WEEE ◆ ◆ ◆ 15D1 U OUCHCOMPUTER UIDE...

  • Page 47: Warranty

    LIMITED TO A REFUND OF THE PURCHASE PRICE OF THE PRODUCT. IN NO EVENT SHALL SELLER BE LIABLE FOR THE COST OF PROCUREMENT OR INSTALLATION OF SUBSTITUTE GOODS BY BUYER OR FOR ANY SPECIAL, CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES. 15D1 U OUCHCOMPUTER UIDE...
  • Page 48 Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attributable to Buyer’s products or representations or warranties concerning same. 15D1 U OUCHCOMPUTER UIDE...

  • Page 49: Index

    Index address, Elo TouchSystems 46 fingerprint reader (FPR) audio ports, description 15 overview 20 specifications 20 testing 21 barcode scanner enabling 2-D scanning 22 overview 21 head power status 12 specifications 21 testing 23 base power status 11 I/O panel...
  • Page 50 FPR 20 peripherals hardware 30 adding 16 printer power port 33 third-party 25 receipt printer 25 phone number, Elo TouchSystems 38, 46 serial ports 33, 34 ports technical 30 to 36 accessing 13 audio 15 cash drawer 15 Ethernet 15...

  • Page 51: Product Information

    Belgium Asia-Pacific Elo TouchSystems Tyco Electronics Raychem GmbH Tyco Electronics Raychem N.V. Sun Hamada Bldg. 2F 301 Constitution Drive (Elo TouchSystems Division) (Elo TouchSystems Division) 1-19-20 ShinYokohama Menlo Park, CA 94025 Finsinger Feld 1 Diestsesteenweg 692 Kanagawa 222-0033 D-85521 Ottobrunn...
