Schematics, Assembly Drawings, and BOM

9. Schematics, Assembly Drawings, and BOM
9.1 Board Files
The schematics, assembly drawings and bill of materials (BOM) for the CPT213B Capacitive Sense Evaluation Board are available
through Simplicity Studio when the kit documentation package has been installed. To access these documents, click the [Kit Docu-
mentation] tile after selecting the device in the left pane.
9.2 Board Revision History
• A00 — Initial production revision.
A00 Revision Boards
These boards do not currently have any known issues.
