2. Kit Block Diagram
An overview of the CPT213B Capacitive Sense Evaluation Board is shown in the figure below.
USB Mini-B
Connector
Device
Configuration
silabs.com | Building a more connected world.
CS00 CS01 CS02
CS04 CS05 CS06
CS09 CS10 CS11
CPT213B
I2C IEC Capacitive
Sense Device
Figure 2.1. CPT213B SLEXP8019A Block Diagram
UG294: CPT213B SLEXP8019A Kit User's Guide
CS03
CS07 CS08
CS12
I2C
Kit Block Diagram
Device
Configuration
EXP Header
Buzzer
