SRAM Guide Ultimate Service Manual page 27

Use a torque wrench and a T10 TORX
4
bolt to 1-1.3 N·m (10-11 in-lb).
5 5 Press the bladder into the reservoir cap, the bladder must be flush with
the cap to be properly installed.
6 Insert the reservoir cap/bladder assembly onto the lever body.
7 Use your fingers to insert the detent ball followed by the detent spring
into the lever body reservoir hole closest to the lever blade.
®
bit socket to tighten each pivot
T10 TORX bit 1-1.3 N•m (10-11 in-lb)
Lever Blade Installation 27
