4
3
Use a T25 TORX
wrench to remove the banjo bolt. Remove the Guide
Ultimate pad spreader.
Use a 2.5 mm hex wrench to remove the pad retention bolt.
®
5
Use a T25 TORX
wrench to remove each caliper body bolt.
6
Separate the caliper body halves.
Set the heat shield aside.
T25 TORX wrench
T25 TORX wrench
2.5 mm hex wrench
Caliper Piston Removal
10
