9 Align the SwingLink™ pivot holes and the SwingLink bushings, then
press the pivot pin into the SwingLink pivot hole until it is flush with the
lever body on both sides.
10
Apply a small amount of Loctite® Threadlocker Blue 242® onto the
T8 TORX wrench
pinch bolt.
®
Use a T8 TORX wrench to thread the SwingLink pinch bolt into the
lever body.
Use a torque wrench and a T8 TORX bit socket to tighten the bolt to
1-1.3 N·m (10-11 in-lb).
Loctite Threadlocker Blue 242 20 mm or 15 mm Thru Axle
T8 TORX bit 1-1.3 N•m (10-11 in-lb) 22 m
Piston Assembly Installation 25
