- Page 1 Front Suspension Setup and Tuning Guide GEN.00000000005623 Rev A GEN0000000000000 © 2018 SRAM, LLC © 2015 SRAM, LLC...
-
Page 2: Table Of Contents
Table of Contents Introduction ..................................4 Set Sag ....................................5 Dampers ......................................6 Air Springs - Solo Air™, DebonAir™, Dual Position Air™ ......................7 Coil Spring - Dual Crown Forks ..............................10 Coil Spring - External Preload Adjuster Knob ......................... 12 Coil Spring - Paragon™ Silver ...............................15 Rebound Damping ................................17 Rebound - Optimal ..................................18 Rebound - Too Fast ..................................19... - Page 3 Lockout .................................... 27 Compliance and Blow-Off ................................28 Air Spring Bottom Out Tuning - Bottomless Tokens™ ....................29 Fork Models and Damper Adjustments ........................30 Service and Settings ..............................31...
-
Page 4: Introduction
Go to www.sram.com/service for additional product and technical information. • Air spring pressure and coil spring tables are available in the RockShox® Front Suspension Oil, Air, Coil, Token, and Specification documents. -
Page 5: Set Sag
Set Sag Suspension sag can be used to set the proper suspension spring rate. Sag is the amount of travel, measured as a percentage of full travel, that the suspension compresses when the rider, including gear, is on the bicycle in the normal riding position. -
Page 6: Dampers
Dampers Before setting sag, set the dampers to the full open positions. Rotate the knobs counter-clockwise until they stop. Adjust... -
Page 7: Air Springs - Solo Air™, Debonair™, Dual Position Air
Air Springs - Solo Air™, DebonAir™, Dual Position Air™ ≥50% Pressurize the air spring to the Solo Air and DebonAir only: Compress the Pressurize the air spring to the recommended starting air pressure. fork through at least 50% of its travel five recommended starting pressure once more. - Page 8 ≥50% Solo Air™ and DebonAir™ only: Compress With riding gear on, and an assistant holding Have your assistant slide the sag o-ring the fork through at least 50% of its travel five the bike, stand on the pedals, and compress down to the top of the dust wiper seal.
- Page 9 <10% Gently step off the bicycle without Note the sag percentage where the o-ring If your target sag percentage is not compressing the fork any further. stopped. achieved, air pressure must be adjusted. Increase air pressure to decrease sag. Decrease air pressure to increase sag. Repeat the sag process until your target sag percentage is achieved.
-
Page 10: Coil Spring - Dual Crown Forks
Coil Spring - Dual Crown Forks With riding gear on, and an assistant holding Have your assistant slide the sag o-ring Gently step off the bicycle without the bike, stand on the pedals, and compress down to the top of the dust seal. compressing the fork any further. - Page 11 <10% >30% Note the sag percentage where the o-ring If your target sag percentage is not Spring preload can be used to fine tune sag, stopped. achieved, spring preload adjustment and/or but preload does not change coil spring rate coil spring replacement must be performed. and is not a substitute for the proper coil spring rate.
-
Page 12: Coil Spring - External Preload Adjuster Knob
Coil Spring - External Preload Adjuster Knob Turn the preload adjuster knob counter- With riding gear on, and an assistant holding Have your assistant slide the sag o-ring clockwise until it stops. the bike, stand on the pedals, and compress down to the top of the dust seal. - Page 13 >30% <10% Gently step off the bicycle without Note the sag percentage where the o-ring If your target sag percentage is not compressing the fork any further. stopped. achieved, spring preload adjustment and/or coil spring replacement must be performed. Adjust Measure...
- Page 14 External spring preload adjustment Spring preload adjustment can be used to fine tune sag, but preload does not change spring compresses or decompresses the spring rate and is not a substitute for the proper coil spring weight. without initiating travel. If the proper sag cannot be acheived after external preload adjustment, the coil spring Turn the preload adjuster knob clockwise to assembly must be replaced with a softer or firmer spring.
-
Page 15: Coil Spring - Paragon™ Silver
Coil Spring - Paragon™ Silver With riding gear on, and an assistant holding Have your assistant slide the sag o-ring Gently step off the bicycle without the bike, stand on the pedals, and compress down to the top of the dust seal. compressing the fork any further. - Page 16 >30% <10% Note the sag percentage where the o-ring If your target sag percentage is not Remove the top cap to remove or re-orient stopped. achieved, spring preload adjustment must the internal preload spacer. be performed. A) Standard 5 mm (factory installed) preload Coil spring preload in RockShox®...
-
Page 17: Rebound Damping
Rebound Damping Rebound damping controls suspension fork extension/return speed which affects traction and control. • Optimal rebound damping allows the fork to extend at a controlled speed and maintain traction and control. • Rebound that is too fast allows the fork to extend too quickly which causes the wheel to bounce off of objects and the ground resulting in a 'pogo' effect. -
Page 18: Rebound - Optimal
Rebound - Optimal The fork rebounds at a controlled speed and the wheel maintains contact with the ground. The fork crown, handlebars, and rider are more level with the ground over each bump. Suspension movement is predictable and controlled. Adjustment - No adjustment is needed. -
Page 19: Rebound - Too Fast
Rebound - Too Fast The fork rebounds too quickly causing a 'pogo' effect where the wheel bounces off of the terrain unpredictably. Traction and control are decreased. The fork crown and handlebars are forced upward after the wheel bounces off of the ground. Rider weight may shift upward and back uncontrollably. -
Page 20: Rebound - Too Slow
Rebound - Too Slow The fork does not extend quickly enough after absorbing a bump. The fork stays compressed through successive bumps, reducing travel and increasing impact firmness. Available travel, traction and control are decreased. The fork stays in a compressed state which puts the crown and handlebars in a lowered position. Rider weight may shift forward. -
Page 21: Low Speed Compression Damping
Low Speed Compression Damping Low speed compression (LSC) damping adjustment controls compression stroke speed, or the rate at which the fork compresses, during slow compression stroke scenarios. LSC affects bump absorption and efficiency during rider weight shifts, transitions, cornering, more gradual bump impacts, and braking. -
Page 22: Rolling Terrain
Rolling Terrain Low Speed Compression Damping - Open / Too Soft Adjustment: The fork compresses low into the compression stroke through the low point of the terrain. Suspension travel is To improve efficiency on used quickly, the rider's weight may shift forward, and bicycle momentum may be reduced. rolling and smoother terrain, rotate the LSC or Compression adjuster knob clockwise to... -
Page 23: Bumps
Bumps Low Speed Compression Damping - Soft to Mid Adjustment: At bump impact, the fork compresses quickly and freely, and the bump is absorbed. Traction is maintained. To increase small bump sensitivity rotate the LSC or Compression adjuster knob The fork reacts quickly to the impact. The crown and handlebar rise slightly as the bump is absorbed. counter-clockwise to decrease compression damping and firmness, and increase... -
Page 24: High Speed Compression Damping
High Speed Compression Damping High speed compression (HSC) damping adjustment controls compression stroke speed, or the rate at which the fork compresses, during quick compression scenarios. HSC affects bump impact absorption and efficiency over large and square edge bumps, and down drops. Bump size and shape, as well as riding speed, can affect compression stroke speed. -
Page 25: Square Bumps And Drops
Square Bumps and Drops HSC Damping - Soft Adjustment: The fork compresses through full Rotate the HSC adjuster knob travel quickly and freely. The fork counter-clockwise to decrease can bottom out as the impacts are fully compression damping and absorbed. increase stroke speed. -
Page 26: Threshold (Pedal)
To activate threshold, rotate the knob to the Pedal or lock positions. Threshold on forks equipped with a remote can be actuated with the handlebar mounted remote at any time during use. Refer to the appropriate remote user manual at www.sram.com/rockshox/component/remotes more information. RCT3 - CHARGER RCT3 - MOTION CONTROL™... -
Page 27: Lockout
Lockout on forks equipped with a remote can be actuated with the handlebar mounted remote at any time during use. Refer to the appropriate remote user manual at www.sram.com/rockshox/component/ remotes for more information. RL / TK RL / TK - Paragon™... -
Page 28: Compliance And Blow-Off
Compliance and Blow-Off Lockout mode features key rider benefits when activated - Compliance and Blow-Off. Motion Control™ and Turnkey™ (A) Compliance - A fixed amount of suspension fork movement that improves traction and control over small bumps while in the lock position. When locked out a small amount of compliance prevents the wheel from bouncing off of impacts which helps maintain traction. -
Page 29: Air Spring Bottom Out Tuning - Bottomless Tokens
Tokens compatible with your fork. TOKENS For a complete list of available Bottomless Tokens™, consult the RockShox Spare Parts Catalog at www.sram.com/service. For Bottomless Token installation and removal procedures, consult the service manual for your fork at www.sram.com/service. COMPRESSION STROKE - TRAVEL... -
Page 30: Fork Models And Damper Adjustments
Fork Models and Damper Adjustments Damper Adjustments Low Speed High Speed Fork Model Damper Rebound Threshold Lockout Remote Compression Compression BoXXer™ World Cup (RC2) Charger 2 Damper™ ✓ ✓ ✓ Charger 2 Damper ✓ ✓ ✓ RCT3 Charger 2 Damper ✓... -
Page 31: Service And Settings
