Software Set Up
2.3 Code Composer Studio Software Development Platform emulation - additional steps
1. Connect the JTAG emulator cable to connector J20.
2. See Software Set-up Code Composer Studio - Development.
For full details (schematics, pin-out table, etc) of the hardware, see the Hardware Developer's Package,
ACDC-HWdevPkg. See
3 Software Set Up
The ac/dc kit application software example, GUI, step-by-step lab style documentation, and other useful
soft collateral is available on the TI website. If you already have your own software project and do not
require this collateral, skip this section. As explained in the hardware set up section, the target mother
board can be run either with the GUI or Code Composer Studio. The GUI executable file is found as part
of the main software download. Follow the steps below for either case.
To run any of the application-specific software in Code Composer Studio, first install the baseline code
that contains the header files, libraries, etc. If you already have the base-line software installed, skip the
baseline install steps and go to the acdc Kit section.
To download the free TI soft collateral follow these steps:
Step 1. Baseline soft collateral and hardware documents (skip this if you already have this software
installed)
a. On an Internet browser type:
b. At the C2000 collateral page, choose the ACDC Developer's Kit download link.
c. When prompted, fill in the TI customer registration details and click ok.
d. Save the .zip file to the directory of your choice
e. Unzip the file and run the install program baseline software set up.
f. The installer creates the following default directories:
C:\TI_F28xxx_SysSW
C:\TI_F28xxx_SysHW
6 TMS320C2000™ AC/DC Developer's Kit Overview
Section 3 for download location.
http://www.ti.com/f28xkits
~Docs
~GeneralPurposeGUI
~HexConverterUtility
~SupportFiles
FlashingLeds
CC280xxHWdevPkg
CC2833xHWdevPkg
DockingStnHWdevPkg
