- Page 1 User Manual TPC-5212W/TPC-5172T/ TPC-5152T/TPC-B500 Series 電腦 Intel® 6 Generation Core i Computer...
- Page 2 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 型號 （型式） ：TPC-5212W ( 系列型號參見說明書 ) 設備名稱：電腦 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴二苯醚 鉛 汞 鎘 多溴聯苯 Unit Hexavalent Polybrominated Lead Mercury Cadmium...
- Page 3 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 型號 （型式） ：TPC-5172T( 系列型號參見說明書 ) 設備名稱：電腦 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴二苯醚 鉛 汞 鎘 多溴聯苯 Unit Hexavalent Polybrominated Lead Mercury Cadmium Polybrominated...
- Page 4 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 型號 （型式） ：TPC-5152T( 系列型號參見說明書 ) 設備名稱：電腦 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴二苯醚 鉛 汞 鎘 多溴聯苯 Unit Hexavalent Polybrominated Lead Mercury Cadmium Polybrominated...
- Page 5 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 6 TPC5172T67A1904E-T; TPC5172T67A1905E-T; TPC5172T67A2001E-T; TPC5172T67A2002E-T; TPC5172T67A2003E-T; TPC5172T67A2004E-T; TPC5172T67A2005E-T; TPC-5152T TPC-5152T-633AE; TPC-5152T-673AE; TPC-5152T-634AE; TPC-5152T-674AE; TPC5152T63A1701E-T; TPC5152T63A1702E-T; TPC5152T63A1703E-T; TPC5152T63A1704E-T; TPC5152T63A1705E-T; TPC5152T63A1801E-T; TPC5152T63A1802E-T; TPC5152T63A1803E-T; TPC5152T63A1804E-T; TPC5152T63A1805E-T; TPC5152T63A1901E-T; TPC5152T63A1902E-T; TPC5152T63A1903E-T; TPC5152T63A1904E-T; TPC5152T63A1905E-T; TPC5152T63A2001E-T; TPC5152T63A2002E-T; TPC5152T63A2003E-T; TPC5152T63A2004E-T; TPC5152T63A2005E-T; TPC5152T67A1701E-T; TPC5152T67A1702E-T; TPC5152T67A1703E-T; TPC5152T67A1704E-T; TPC5152T67A1705E-T; TPC5152T67A1801E-T; TPC5152T67A1802E-T; TPC5152T67A1803E-T;...
- Page 7 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
-
Page 8: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 9: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 10 安全指示 請仔細閱讀此安全操作說明。 請妥善保存此用戶手冊供日後參考。 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設 備。 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 請勿在潮濕環境中使用設備。 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。 設備機殼的開孔適用於空氣對 , 從而防止設備過熱。請勿覆蓋開孔。 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。 請將電源線布置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。 請注意設備上所有的警告標示。 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動 損壞。 請勿讓任何液體流入通風口，以免引起火災或短路。 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。 如欲下列情況，請由專業人員維修： 電源線或插頭損壞； 設備內部有液體流入； 設備曾暴露在過度潮濕環境中使用； 設備無法正常工作，或您無法透過用戶手冊來正常工作； 設備摔落或損壞； 設備有明顯外觀損壞。 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 -20°C (-4°F) 或高 於 60°C (140°F)，否則可能會造成設備損壞。 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704-1:1982 規定，操作員所在位置音量不可高於 70 分貝。 限制區域：請勿將設備安裝於限制區域使用。...
-
Page 11: Table Of Contents
Contents Chapter General Information ......1 Introduction ....................2 Features ....................2 1.2.1 System Kernel................2 1.2.2 O/S support................... 2 1.2.3 Certification and Environment............2 LCD & Touch Specifications ..............3 Power ......................4 I/O Port Arrangement ................4 Figure 1.1 I/O Port Arrangement ..........4 Panel Mounting .................. - Page 12 Chapter A Easy Installation........ 27 Easy Installation..................28 UI Operating Process................30 Table A.1: Status indicator table..........30 Table A.2: Button code definition..........34 COM1: RS-232 ..................35 COM2: RS-232/422/ 485 ................ 35 RS-422/ 485 mode setting by BIOS............36 TPC-5000 Series User Manual...
-
Page 13: Chapter 1 General Information
Chapter General Information... -
Page 14: Introduction
Introduction TPC-5000 Touch Panel Computer is a state-of-the-art Modular designed Human Machine Inter-face featuring displays ranging from 12" to 21.5" and Intel 6 Core i CPU provides the high computing performance in a compact fan-less system. The key features are as follows: ... -
Page 15: Lcd & Touch Specifications
BSMI The front bezel is compliant with IP66 Environment Operating Temperature: -0 ~ 55°C (32 ~ 131°F) Storage Temperature: -20 ~ 60°C (-4 ~ 140°F) Humidity: 10 ~ 95% RH @ 40°C,non-condensing Vibration: With SSD: 3Grms (5 ~ 500 Hz) (Operating, random vibration) LCD &... -
Page 16: Power
Power Input Voltage: 24VDC +/-20% Typical: – TPC-5122T: 24 VDC @ 3.7 Amp – TPC-5152T: 24 VDC @ 3.7 Amp – TPC-5172T: 24 VDC @ 3.7 Amp – TPC-5182W: 24 VDC @ 3.7 Amp – TPC-5212W: 24 VDC @ 3.7 Amp I/O Port Arrangement The arrangement of the I/O ports is shown in Figure 1.1. -
Page 17: Panel Mounting
Panel Mounting There is an adhesive waterproof gasket on the Mg front bezel. Make sure the waterproof gasket is in position before installing TPC into the panel opening. Install the TPC into the panel opening. Find the clamps and long screws in the accessory pack. Hook the clamps to the holes around the four sides of the bezel. -
Page 18: Dimensions And Cutout
Dimensions and Cutout HEIGHT WIDTH Z Nim./Z Max TPC-B500 Box Dimension: W269 x L203 x H58.5 TPC-5000 Series User Manual... -
Page 19: Chapter 2 System Setup
Chapter System Setup... -
Page 20: Transport And Unpacking
Transport and Unpacking When accepting a delivery, please check the packaging for visible transport damage and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately. -
Page 21: Figure 2.3 Power Connector And Power Lines
Warning! It is suggested turning OFF the system power to plug in or pull out the memory card, even though the CFast storage is hotswappable. Ilestsuggéré de désactiverl'alimentation du système que vousbran- chez ouretirez le carte mémoire, mêmesi la mémoire CompactFlash estrem- plaçable àchaud. -
Page 22: Driver Installation
With administrator-level privilege on your computer, run the installer of Advan- tech Watchdog WDM driver. Below is an example of Advantech Watchdog WDM driver Setup. If you want to stop the setup, press the “Cancel” button in the setup program. The Setup program will stop the procedure automatically. - Page 23 Click the “Install” button to continue the installation of Advantech Watchdog WDM driver. Click on "Restart” button or "Close” button on the "Advantech Watchdog Driver" to complete the setup program. TPC-5000 Series User Manual...
-
Page 24: Panel Mounting
Panel Mounting Position the TPC against the panel. Insert the clamps into the side of the TPC. TPC-5000 Series User Manual... - Page 25 Secure the clamp to the panel using the included screws. TPC-5000 Series User Manual...
-
Page 26: Cabinet Installation And Earth Grounding Setup
Cabinet Installation and Earth Grounding setup Follow the following steps to setup TPC system, and please pay attention that Ground pin of TPC system should be connected to earth ground. Under this circum- stance, TPC system could have the best performance such as EMI immunity, ESD immunity, Surge immunity and also system isolation. -
Page 27: Power/Digital Ground And Earth Ground
Step E: Connect the I/O to the controller if needed. Step F: Connect the V+ and V- of power supply to TPC system. While completing step A to F step by step, you can supply power to TPC system now. Note! Make sure all wires follow the installation guidelines or it may cause. -
Page 28: Installation Of Extension
Installation of extension 2.7.1 Installation of M.2(2280) SSD Remove the 2 screws of the extension door. Figure 2.5 Install M.2 SSD-1 Slide out the back door by hands. Figure 2.6 Install M.2 SSD-2 TPC-5000 Series User Manual... -
Page 29: Installation Of Idoor
Insert the M.2(2280) SSD and tightening the screws attached on the screw holes. Figure 2.7 Install M.2 SSD-3 2.7.2 Installation of iDoor Remove the 2 screws of the extension door. Figure 2.8 Install iDoor-1 TPC-5000 Series User Manual... -
Page 30: Figure 2.9 Install Idoor-2
Slide out the back door by hands. Figure 2.9 Install iDoor-2 Remove the 2 screws of the iDoor. Figure 2.10 Install iDoor-3 TPC-5000 Series User Manual... -
Page 31: Installation Of The Riser Card
Plug in the power cable and the signal cable Figure 2.11 Install iDoor-4 Lock the iDoor and tighten the screws to fix it. 2.7.3 Installation of the riser card Remove the 2 screws of the extension door. Figure 2.12 Install M.2 SSD-1 TPC-5000 Series User Manual... -
Page 32: Figure 2.13Install M.2 Ssd-2
Slide out the back door by hands. Figure 2.13 Install M.2 SSD-2 Remove the screw of the door stop of the riser card Figure 2.14 Install Riser-Card-1 TPC-5000 Series User Manual... -
Page 33: Figure 2.15Install Riser-Card-2
Plug in the riser card by slide through the track. Figure 2.15 Install Riser-Card-2 Tightening the screw to fix the riser card. Figure 2.16 Install Riser-Card-3 TPC-5000 Series User Manual... - Page 34 TPC-5000 Series User Manual...
-
Page 35: Chapter 3 Features In Windows Embedded
Chapter Features in Windows Embedded... -
Page 36: Features In Windows Embedded
Applying changes to an image applies all changes made to the operat- ing system during a specific period of time. Advantech provide utility to operate EWF. Refer below steps if you want to enable. Click Start Menu->All Programs->Advantech->AdvWF and click EWF Utility. - Page 37 Click EWF tab, and click “Enable” button. After the system is rebooted automatically, EWF enable. TPC-5000 Series User Manual...
-
Page 38: File-Based Write Filter (Fbwf)
Writes to folders with write- through exceptions will be persisted when the device restarts. Advantech provide utility to operate FBWF. Refer below steps if you want to enable Click Start Menu->All Programs->Advantech->AdvWF and click FBWF Utility. -
Page 39: Chapter A Easy Installation
Chapter Easy Installation... -
Page 40: Easy Installation
Easy Installation With easy installation, a person can complete panel mount process by himself, just follow following steps: To install the TPC to the cabinet: Step 1: Models of 4:3 screen ratio Snap hook on the top of TPC to hook TPC in the cabinet. Release the pillar on the bottom of TPC for sitting in the cabinet. - Page 41 Step 2: Sit TPC cross the cabinet wall. Push the upper part of TPC to the wall until snap hooks flip back, the snap hook will hold the machine on the wall. To remove the panel from cabinet: For cabinet thickness equals or less than 2mm, using stick Ø≤ 4mm to pull out the panel;...
-
Page 42: Ui Operating Process
UI Operating Process This section is to introduce how to operate HMI utility(GL_Utility), you can download the utility from Advantech's product support portal of the TPC at http://support.advantech.com. See the process below: As you can find 2 function buttons in the lower right corner of front panel, represents “intelligent”... - Page 43 One press Home Key-> Home – Back to desktop (default setting) Home - Execute Home-key App (Set up in setting page) Long press Home Key-> Home - Long press to disable / enable touch function TPC-5000 Series User Manual...
- Page 44 One press Intelligent Key-> GLToolbar Utility A. Quick start-> – Press “+” to add shortcut – Long press the icon to perform “right click” until an “X” mark appears in upper right corner to “delete” TPC-5000 Series User Manual...
- Page 45 B. Setting -> – Password confirmation for authority confirmation when first log in, default password is “1234” without input order to active. – Setting - Home-key: Select an execute file to set up as "Home-key" App, in default path is to show “desktop” –...
-
Page 46: Table A.2: Button Code Definition
C. System management-> – System information: – Self Diagnosis: Note!* TPC-5000 series also provides open button code as following definition for customer's configuration to their Apps/SW applications. The codes are defined from general keyboard input. Table A.2: Button code definition One press Long press I key (icon) -
Page 47: Com1: Rs-232
COM1: RS-232 Pin Definition COM1 Signal COM2: RS-232/422/ 485 The serial port COM2 on the TPC-5000 series are adjustable by BIOS. It can be set to RS-422 or RS-485 mode. This port is designed with auto data flow control capabil- ity.In other words, the TPC-5000 series can automatically detect the data flow direc- tion at this port when the two wired RS-485 communication is activated. -
Page 48: Rs-422/ 485 Mode Setting By Bios
RS-422/ 485 mode setting by BIOS Enter into BIOS setup utility Enter into Advanced tab and select Serial ports Configuration. Select Serial Port 2 Configuration (COM2) for RS-422/ 485 mode setting. TPC-5000 Series User Manual... - Page 49 TPC-5000 Series User Manual...
