User Manual
PCE-5128/7128
LGA1150
®
®
Intel
Core™7/i5/i3/Pentium
/
®
Xeon
PICMG 1.3 Single Host
Board with VGA/ DVI-D/
(ECC)DDR3 /SATA3.0 / USB3.0 /
Dual GbE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-5128 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PCE-5128

Summary of Contents for Advantech PCE-5128

  • Page 1 User Manual PCE-5128/7128 LGA1150 ® ® Intel Core™7/i5/i3/Pentium ® Xeon PICMG 1.3 Single Host Board with VGA/ DVI-D/ (ECC)DDR3 /SATA3.0 / USB3.0 / Dual GbE...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    Whether your new Advantech equipment is destined for the labo- ratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known.
  • Page 4 Memory Compatibility PCE-5128 Compatible Memory Brand Size Speed Type ECC Vendor PN Memory Advantech PN DDR3 1066 TS128MLK64V1U SEC K4B1G0846G-BCH9 96D3-1G1066NN-TR DDR3 1066 TS256MLK64V1U SEC K4B1G0846G-BCH9 96D3-2G1066NN-TR ELPIDA EDJ1108BFBG- DDR3 1333 TS128MLK64V3U 96D3-1G1333NN-TR DJ-F DDR3 1333 TS256MLK64V3U SEC K4B1G0846G-BCH9 96D3-2G1333NN-TR4...
  • Page 5 IZD27 D9PBC 1600 DDR3 TS1GLK64V6H 512x8 Specification Comparison USB2.0 Part Number Memory DVI-D Backplane SATA3.0 USB3.0 RAID (4 for BP) PCE-5128G2- Non-ECC Yes Yes*2 PCE-5BXX 2 GbE 00A1E PCE-7128G2- PCE-5BXX/ C226 Yes*2 2 GbE 00A1E 7BXX PCE-5128/7128 User Manual...

  • Page 6: Processor Support

    22nm 1600 2.4- Core i3-4330TE 2.4GHz 3MB 4M10T PCE-5128/ Pentium G3420 3.2GHz 3MB 7128 Pentium 2.3GHz 3MB G3320TE i7-4790S 3.2GHz 8MB i7-4790T 2.7GHz 8MB i5-4590S 3.0GHz 6MB Haswell-R i5-4590T 2.0GHZ 6MB i3-4360 3.7GHz 4MB i3-4350T 3.1GHz 4MB PCE-5128/7128 User Manual...
  • Page 7 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCE-5128/7128, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.
  • Page 8 PCE-5128/7128 User Manual viii...

  • Page 9: Table Of Contents

    Table 1.2: Connectors ..............5 Board Layout: Jumper and Connector Locations........6 Figure 1.1 Jumper and connector locations......... 6 Block Diagram................... 7 Figure 1.2 PCE-5128 block diagram..........7 Figure 1.3 PCE-7128 block diagram..........7 Safety Precautions ..................8 Jumper Settings ..................8 1.8.1...
  • Page 10 2.12 GPIO Header (GPIO1)................25 2.13 Case Open Connector (JCASE1) ............25 Figure 2.2 PCE-5128/7128 Case Open Jumper Locations ..25 Table 2.3: Case open mode Jumper ......... 26 Figure 2.3 Case Open Warning in BIOS Menu ......26 2.14 Front Panel LAN Indicator Connector (LANLED1)........
  • Page 11 Table B.1: Parallel port connector (LPT1)........88 VGA Connector (VGA1) ................88 Table B.2: VGA connector (VGA1) ..........88 RS 232 Serial Port (COM12)..............89 Table B.3: RS-232 serial port (COM2)........89 USB 2.0 Header (USB56 & 910)............. 89 PCE-5128/7128 User Manual...
  • Page 12 Table B.21:1 MB memory map ........... 97 B.22 PCI Bus Map................... 97 Table B.22:PCI Bus Map ............97 Appendix C Programming the GPIO ....99 Supported GPIO Register ..............100 GPIO Registers..................100 GPIO Example Program-1 ..............100 PCE-5128/7128 User Manual...

  • Page 13: Chapter 1 Hardware Configuration

    Chapter Hardware Configuration...

  • Page 14: Introduction

    Introduction PCE-5128/7128 is a PICMG 1.3 form-factor single host board which is designed with Intel®Q87 (PCE-5128) and C226 (PCE-7128) PCH for industrial applications that need high computing power and strong I/O capability. PCE-5128/7128 supports 22nm manufacturing technology, LGA1150 socket Intel® Core™ i7/i5/i3, Pentium®...

  • Page 15: Specifications

    Memory RAM:  – PCE-5128: Up to 16 GB in two 240-pin DIMM sockets. Supports dual-chan- nel DDR3 1333/1600 MHz SDRAM WITHOUT ECC function. – PCE-7128: Up to 16 GB in two 240-pin DIMM sockets. Supports dual-chan- nel DDR3 1333/1600 MHz SDRAM WITH or WITHOUT ECC function.

  • Page 16: Graphics

    Supports single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated PCI Express x1 bus which provides 500 MB/s data transmission rate.  Controller: – LAN 1: Intel® I217LM for both PCE-5128 and PCE-7128. – LAN 2: Intel® I211(PCE-5128) and I210(PCE-7128). 1.3.6 Industrial features ...

  • Page 17: Jumpers And Connectors

    Jumpers and Connectors Connectors on the PCE-5128/7128 single host board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application.

  • Page 18: Board Layout: Jumper And Connector Locations

    COM2 DIMM A1 SATA3 LPT1 USB78 1,2,4,5 LANLED1 USB56 USB3 JCASE1 LAN2 LAN1 VGA1 KBMS1 JIR1 JCMOS1 JOBS1 JME1 DVI1 CPU1 JERP1 DVI2 JWDT1 GPIO1 AUDIO1 BMC1 SPI_CN1 LPC1 KBMS2 (PCE-7128) Figure 1.1 Jumper and connector locations PCE-5128/7128 User Manual...

  • Page 19: Block Diagram

    Block Diagram Figure 1.2 PCE-5128 block diagram Figure 1.3 PCE-7128 block diagram PCE-5128/7128 User Manual...

  • Page 20: Safety Precautions

    1, 2 and 3. In this case you connect either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set- ting jumpers. PCE-5128/7128 User Manual...

  • Page 21: Bios Cmos (Jcmos1)

    1.8.3 Watchdog timer output (JWDT1) The PCE-5128/7128 contains a watchdog timer that will reset the CPU in the event the CPU stops processing. This feature means the PCE-5128/7128 will recover from a software failure or an EMI problem. The JWDT1 jumper settings control the out- come of what the computer will do in the event the watchdog timer is tripped.

  • Page 22: System Memory

    0 DIMM slots (DIMMA1) empty, or it may cause some system abnormality. 1.11 Cache Memory CPUs supported by PCE-5128/7128 have 8 MB, 6 MB, 3 MB L3 cache memory sizes. Note! Please refer to the Intel CPU data sheet for detailed information.
  • Page 23 The PCE-5128/7128 is designed for Intel® LGA 1150 socket processors. Pull the bar beside the processor socket outward and lift it. Remove the socket protection cap. Align the cuts on the processor with the edges of the socket. PCE-5128/7128 User Manual...

  • Page 24: Processor Cooler Installation

    1.13 Processor Cooler Installation Purchasing PCE-5128/7128 optimized CPU cooler (P/N: 1960047831N001) from Advantech is a must. Other brand CPU coolers are NOT compatible with PCE-5128/ 7128. Advantech offers a specially designed CPU cooler for PCE-5128/7128 for better heat dissipation efficiency and enhancing rigidity of the CPU card - part number 1960047831N001.
  • Page 25 CPU cooler into the steel back-plate on PCB. Note the direction of CPU cooler; it must follow that shown abov Installing a CPU cooler in the wrong direction may cause poor heat dissipation that may damage the CPU card. PCE-5128/7128 User Manual...
  • Page 26 PCE-5128/7128 User Manual...

  • Page 27: Chapter 2 Connecting Peripherals

    Chapter Connecting Peripherals...

  • Page 28: Introduction

    USB Ports (USB12, USB3, USB4, USB56, USB78) The PCE-5128/7128 provides up to 8 USB (Universal Serial Bus) on-board ports with complete Plug & Play and hot swap support for up to 127 external devices. These USB ports comply with USB Specification 2.0 and 3.0, and support transfer rates up to 480 Mbps (USB2.0) and 5 Gbps (USB 3.0).

  • Page 29: Vga Connectors (Vga1)

    COM1 COM2 The PCE-5128/7128 offers two serial ports. These ports can connect to serial devices, such as a mouse or a printer, or to a communications network. The IRQ and address ranges for both ports are fixed. However, if you want to disable the port or change these parameters later, you can do this in the system BIOS setup.

  • Page 30: Ps/2 Keyboard And Mouse Connector (Kbms1/Kbms2)

    The on-board KBMS2 pin header provides connection to the front panel PS/2 key- board and mouse connector of the chassis. CPU Fan Connector (CPUFAN1) This fan connector supports 3-pin or 4-pin fan coolers and smart fan functions. Note: Fan speed is controlled by voltage. CPU FAN1 PCE-5128/7128 User Manual...

  • Page 31: Front Panel Connectors (Jfp1, Jfp2 & Jfp3)

    PWR_LED & Key Lock 2.8.2 External speaker (JFP2) JFP2 is a 4-pin connector for an external speaker. The PCE-5128/7128 provides an onboard buzzer as an alternative to an external speaker. To enable the buzzer, set pins 3 and 4 as closed.

  • Page 32: Reset Connector (Jfp1)

    If your computer case is equipped with an ATX power supply, you should connect the power on/off button on your computer case to JFP1. This connection enables you to turn your computer on and off. JFP1 PWR_SW Reset HDD LED SNMP JFP2 Speaker JFP3 PWR_LED & Key Lock PCE-5128/7128 User Manual...

  • Page 33: H/W Monitor/Watchdog Timer/Infrared

    Open: Disables OBS Alarm 2.9.2 Watchdog timer (JWDT1) This is for setting action trigger by watchdog timer. 1-2 Pin Close: No Action 2-3 Pin Close: System Reset 2.9.3 Infrared interface (JIR1) This is a 5-pin header for an infrared device. PCE-5128/7128 User Manual...

  • Page 34: Lan Ports (Lan1 & Lan2)

    LAN Ports (LAN1 & LAN2) LAN2 LAN1 The PCE-5128/7128 is equipped with one or two high-performance 1000 Mbps Ethernet LANs. They are supported by all major network operating systems. The RJ- 45 jacks on the rear plate provide convenient connectivity.

  • Page 35: High Definition Audio Module Interface (Hdaud1)

    2.11 High Definition Audio Module Interface (HDAUD1) AUDIO1 This HDAUD1 pin header is the connection interface to Advantech's 7.1 channel high definition audio module. Note! Advantech 7.1 channel high definition audio module ordering informa- tion. P/N: PCA-AUDIO-HDA1E PCE-5128/7128 User Manual...

  • Page 36: Figure 2.1 Jumper And Connector Locations Of Pca-Audio Hda1E

    CPU card with the HD audio cable (PN:1701120251) Figure 2.1 Jumper and connector locations of PCA-AUDIO-HDA1E Note! Please remove the yellow jumper cap on the CPU card's HDAUD1 pin- header before connecting the HD audio cable to it. PCE-5128/7128 User Manual...

  • Page 37: Gpio Header (Gpio1)

    2.13 Case Open Connector (JCASE1) PCE-5128/7128 Case Open installation PCE-5128/7128 supports case open with both Normally Open(N.O.) and Normally Closed(N.C.) mode. Please follow below directions to install Case Open for your sys- tem. Please consult with your chassis provider for which case open mode is sup- ported.

  • Page 38: Front Panel Lan Indicator Connector (Lanled1)

    LED1 LED2 1000Mbps Link On Green On 1000Mbps Active Green on Flash 1000Mbps Link Off 100Mbps Link On Orange On 100Mbps Active Orange On Flash 100Mbps Link Off 10Mbps Link On 10Mbps Active Flash 10Mbps Link Off PCE-5128/7128 User Manual...

  • Page 39: Serial Ata Interface (Sata1~Sata6)

    SATA3 1,2,4,5 The PCE-5128/7128 features high performance serial ATA interface (2* 600MB/s and 4* 300MB/s) which eases cabling to hard drivers or CD/DVD drivers with long cables. These six on-board SATA ports can be configured as RAID 0, 1, 10, or 5. Please see the detailed BIOS setting instructions for this in Chapter 3.

  • Page 40: Lpc Extension Interface (Lpc1)

    2.16 LPC Extension Interface (LPC1) LPC1 LPC1 is a 14-pin female pin header for connection with an Advantech LPC module. PCE-5128/7128 User Manual...

  • Page 41: Chapter 3 Ami Bios Setup

    Chapter AMI BIOS Setup...

  • Page 42: Introduction

    The Setup program uses a number of menus for making changes and turning the special features on or off. This chapter describes the basic navigation of the PCE-5128/7128 setup screens. Figure 3.1 Setup program initial screen...

  • Page 43: Entering Setup

    Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. PCE-5128/7128 User Manual...

  • Page 44: Advanced Bios Features Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from the PCE-5128/7128 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can dis- play an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 45: Figure 3.4 Pci Subsystem Settings

    3.2.2.1 PCI Subsystem Settings Figure 3.4 PCI Subsystem Settings PCI Common Settings  PCI Latency Timer Value to be programed into PCI Latency Timer Register. VGA Palette Snoop Enables/Disables VGA palette registers snooping. PCE-5128/7128 User Manual...

  • Page 46: Figure 3.5 Pci Express Settings

    Defines number of retry attempts software will take to retrain the link if previous training attempt was unsuccessful.  Link Training Timeout Defines number of micro-seconds software will wait before polling "Link Training " bit in link status register. Values range from 10 to 1000 uS. PCE-5128/7128 User Manual...

  • Page 47: Figure 3.6 Acpi Settings

    Choose this item correspond with your power supply type ATX or AT.  Enable Hibernation "Enable or disable" Hibernate (OS/S4 Sleep State). This option may not be effective with some OS.  PowerOn by Modem "Enabled" or "Disabled" PowerOn by Modem PCE-5128/7128 User Manual...

  • Page 48: Figure 3.7 Trust Computing

    3.2.2.3 Trust Computing Figure 3.7 Trust Computing  Security Device Support Enable or disable BIOS for security device support. You can purchase Advan- tech TPM (Trust Platform Module) PCA-TPM-00A1E for your security device. PCE-5128/7128 User Manual...

  • Page 49: Figure 3.8 S5 Rtc Configuration

    Figure 3.8 S5 RTC configuration  Wake System with Fixed Time Enable or disable system wake on alarm event, When enabled, the system will wake on the hr:min:sec as specified. 3.2.2.5 CPU Configuration Figure 3.9 CPU Configuration PCE-5128/7128 User Manual...
  • Page 50 You may choose to enable or disable it.  CPU C states Intel C states setting for power saving.  Intel TXT(LT) Support Enable or Disable Intel TXT support PCE-5128/7128 User Manual...

  • Page 51: Figure 3.10Sata Configuration

    3.2.2.6 SATA Configuration Figure 3.10 SATA Configuration  SATA Controller(s) Enable or disable SATA Device  SATA Mode This can be configured as IDE, RAID, and AHCI PCE-5128/7128 User Manual...
  • Page 52 To identify the SATA that is connected to a Solid State or Hard Disk Drive. Note! Some OS request to install under AHCI mode so please consult your local OS vendor for more detailed information. i.e. Fedora and Ubuntu requests to install under AHCI mode. PCE-5128/7128 User Manual...

  • Page 53: Figure 3.11Firmware Update Configuration

    3.2.2.7 PCH-FW Configuration Figure 3.11 Firmware Update Configuration ME FW Image Re-Flash  Enable/Disable ME FW Image Re-Flash function. PCE-5128/7128 User Manual...

  • Page 54: Figure 3.12Amt Configuration

    Un-configure ME without password.  Amt Wait Timer Set timer to wait before sending ASF_GET_Boot_Options.  Disable ME Set ME to soft temporary disable.  Enable/Disable alert specification format.  Active Remote Assistance Process Trigger CIRA boot. PCE-5128/7128 User Manual...

  • Page 55: Figure 3.13Usb Configuration

    USB Mass Storage Driver Support Enable/Disable USB Mass Storage Driver Support.  USB transfer time-out Allows you to select the USB transfer time-out value. [1,5,10,20sec].  Device reset time-out Allows you to select the USB device reset time-out value. [1,5,10,20sec]. PCE-5128/7128 User Manual...

  • Page 56: Figure 3.14Smart Setting

    This item appears only when you set device power-up delay item to [manual].  USB Flash Driver PMAP 3.2.2.10 Smart Setting Figure 3.14 Smart Setting Smart self test  Run SMART self test on all HDDs during POST. PCE-5128/7128 User Manual...

  • Page 57: Figure 3.15Super Io Configuration

    3.2.2.11 Super IO Configuration Figure 3.15 Super IO Configuration Figure 3.16 Serial Port 1 Configuration PCE-5128/7128 User Manual...

  • Page 58: Figure 3.17Serial Port 2 Configuration

    Figure 3.17 Serial Port 2 Configuration Figure 3.18 Parallel Configuration  Serial Port 1 -2 configuration "Enable or Disable" serial port Parallel Port configuration  "Enable or Disable" parallel port PCE-5128/7128 User Manual...

  • Page 59: Figure 3.19Pc Health Status

    Use this to set the ACPI shutdown temperature threshold. When the system reaches the shutdown temperature, it will be automatically shut down by ACPI OS to protect the system from overheating damage. CPUFAN1 Mode  Enable/Disable Smart Fan. PCE-5128/7128 User Manual...

  • Page 60: Chipset

    3.2.3 Chipset Figure 3.20 Chipset 3.2.3.1 PCH-IO Configuration Figure 3.21 PCH IO Configuration  LAN1 Controller Enable or Disable LAN1 controller. PCE-5128/7128 User Manual...
  • Page 61 Enable or Disable PCIE to wake the system from S5.  SLP_S4 Assertion Width Select a minimum assertion width of the SLP_S4# signal.  Restore AC Power Loss Power Off, Power On or last state to restore AC power loss. 3.2.3.2 PCI Express Configuration PCE-5128/7128 User Manual...

  • Page 62: Figure 3.22Pci Express Configuration

    Set the ASPM Level: Disable, L0s, L1, L0sL1, auto.  PCIe Speed Select PCI Express port speed (Auto, Gen1, Gen2).  Detect Non-Compliance Device Detect Non-Compliance PCI Express. If enabled, it will take more time at POST time. PCE-5128/7128 User Manual...

  • Page 63: Figure 3.23Usb Configuration

    Select Smart auto, Auto, Enable, and Disable mode of operation of XHCI con- troller. Note! Smart auto setting remembers last setting, but auto mode does not.  USB Ports Pre-port Disable Control Control each of the USB ports disabling. PCE-5128/7128 User Manual...

  • Page 64: Figure 3.24Pch Azalia Configuration

    3.2.3.4 PCH Azalia Configuration Figure 3.24 PCH Azalia Configuration  Azalia Control detection of the Azalia device. Disable=Azalia will be unconditionally disabled. Enable=Azalia will be unconditionally enabled. Auto=Azalia will be enabled if present, disabled otherwise. PCE-5128/7128 User Manual...

  • Page 65: Figure 3.25System Agent (Sa) Configuration

    3.2.3.5 System Agent (SA) Configuration Figure 3.25 System Agent (SA) Configuration  VT-d Check to enable VT-d function on MCH. 3.2.3.6 Graphics Configuration PCE-5128/7128 User Manual...

  • Page 66: Figure 3.26Graphics Configuration

    Select 128 M, 256 M or MAX DVMT5.0 total graphics memory size used by the internal graphics device.  Gfx Low Power Mode Enable/Disable Gfx Low power mode.  LCD Control Select Primary IGFX Boot Display (VBIOS Default, CRT, DVI1, DVI2). PCE-5128/7128 User Manual...

  • Page 67: Figure 3.27Nb Pcie Configuration

    Disabled: PCIe ASPM will be programme before OpROM.  PEG0 De-emphasis Control Configure the De-emphasis control on PEG.  PEG0 ASPM Control ASPM support for the PEG: Device 1 Function 0. This has no effect if PEG is not the currently active device. PCE-5128/7128 User Manual...

  • Page 68: Boot

    3.2.3.8 Memory Configuration Overview memory detail information. Figure 3.28 Memory Information 3.2.4 Boot Figure 3.29 Boot PCE-5128/7128 User Manual...
  • Page 69 1 MB.  Option Rom Messages Set display mode for option ROM.  INT19 Trap Response BIOS reaction on INT19 trapping by option ROM:  IMMEDATE-execute the trap right away POSTPONED-execute the trap during legacy boot. PCE-5128/7128 User Manual...

  • Page 70: Security

    Security Figure 3.30 Security Select Security Setup from the PCE-5128/7128 setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>.

  • Page 71: Save & Exit

    Discard changes and Reset Select this option to quit setup and reset computer without making any permanent changes to the system configuration. Save Changes Select this option to save your changes. Discard Changes Select this option to discard your changes. PCE-5128/7128 User Manual...
  • Page 72 This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available file system devices. *When you make some critical changes, the system will still reboot even if you chose "Save changes and exit". PCE-5128/7128 User Manual...

  • Page 73: Chapter 4 Value-Added Software Services

    Chapter Value-Added Software Services...

  • Page 74: Value-Added Software Services

    Advantech platforms. API plays the role of catalyst between developer and solution, and make Advantech embedded platforms easier and simpler to adopt and operate with customer applications.

  • Page 75: Software Utility

    The Monitoring utility allows the customer to monitor sys- tem health, including voltage, CPU and system tempera- ture and fan speed. These items are important to a device; if critical errors happen and are not solved immediately, permanent damage may be caused. PCE-5128/7128 User Manual...
  • Page 76 PCE-5128/7128 User Manual...

  • Page 77: Chapter 5 Chipset Software Installation Utility

    Chapter Chipset Software Installation Utility...

  • Page 78: Before You Begin

    To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the PCE-5128/7128 are located on the software installation CD. The driver in the folder of the driver CD will guide and link you to the utilities and drivers for Windows.

  • Page 79: Windows® 7 / Windows® 8 Driver Setup

    Navigate to the "00_Chipset" folder and click "infinst_autol.exe" to complete the installation of the driver. Note! Wrong driver installation may cause unexpected system instability. The drivers on this CD support both Windows 7 32-bit /64-bit and Win- dows 8 32-bit/64-bit. PCE-5128/7128 User Manual...
  • Page 80 PCE-5128/7128 User Manual...

  • Page 81: Chapter 6 Integrated Graphic Device Setup

    Chapter Integrated Graphic Device Setup...

  • Page 82: Introduction

    Insert the driver CD into your system’s CD-ROM drive. You can see the driver folder items. Navigate to the "01_Graphics_x86 or 02_Graphics_x64" folder and click "setup.exe" to complete the installation of the driver. Note! Wrong driver installation may cause unexpected system instability. PCE-5128/7128 User Manual...

  • Page 83: Lan Configuration

    Chapter LAN Configuration...

  • Page 84: Introduction

    Introduction The PCE-5128/7128 has dual Gigabit Ethernet LANs via dedicated PCI Express x1 lanes (Intel I217LM (LAN1) and I211AT (LAN2 of PCE-5128) or I210AT (LAN2 of PCE-7128) that offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ethernet at 1000 Mbps.

  • Page 85: Intel Me

    Chapter Intel ME...

  • Page 86: Introduction

    9.0_5MB" folder and click "setup.exe" to complete the installation of the driver. Note! If the Intel® Management Engine (Intel® ME) driver has not been suc- cessfully installed, you may see an error on a "PCI Simple Communica- tions Controller" in Device Manager. PCE-5128/7128 User Manual...

  • Page 87: Chapter 9 Intel Usb 3.0

    Chapter Intel USB 3.0...

  • Page 88: Introduction

    Introduction PCE-5128/7128 provides Intel® USB 3.0 and the data transfer rates of USB 3.0 (5 Gbps) which is 10 times faster that USB 2.0 (480Mbps). Installation Insert the driver CD into your system’s CD-ROM drive. Navigate to the "05_USB3.0" folder and click "setup.exe" to complete the installation of the driver.

  • Page 89: Sata Raid Setup

    Chapter SATA RAID Setup...

  • Page 90: Introduction

    For the detailed installation instructions for the SATA RAID driver and utility, please check the User Guide in the driver CD. Path: "07_Others/ Raid/". Note! Before you install the Intel Rapid Storage Technology, please read the "readme.txt" which is in the folder "07_Others/Raid/". PCE-5128/7128 User Manual...

  • Page 91: Appendix A Programming The Watchdog Timer

    Appendix Programming the Watchdog Timer...

  • Page 92: Introduction

    Introduction The PCE-5128/7128’s watchdog timer can be used to monitor system software oper- ation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it.

  • Page 93: Table A.1: Watchdog Timer Registers

    Write 1 to bit 4: Watchdog timer count mode is 1000 times faster. If bit 3 is 0, the count mode is 1/1000 seconds mode. If bit 3 is 1, the count mode is 1/1000 minutes mode. PCE-5128/7128 User Manual...

  • Page 94: Example Program

    ; Enable the function of watchdog timer al,30h dx,al al,dx al,01h dx,al ;----------------------------------------------------------- Dec dx ; Set second as counting unit al,0f5h dx,al al,dx And al,not 08h dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 10 seconds and start counting al,0f6h PCE-5128/7128 User Manual...
  • Page 95 ;----------------------------------------------------------- Dec dx ; Set minute as counting unit al,0f5h dx,al al,dx al,08h dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting al,0f6h dx,al al,5 ; 5 minutes dx,al ;----------------------------------------------------------- PCE-5128/7128 User Manual...
  • Page 96 ;----------------------------------------------------------- Dec dx ; Lock NCT6776D al,0aah dx,al Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; Unlock NCT6776D Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer PCE-5128/7128 User Manual...
  • Page 97 Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer dx,al al,08h dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer al,30h dx,al al,01h dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal PCE-5128/7128 User Manual...
  • Page 98 ;Write 1 to bit 5 of F7 register al,dx Or al,20h dx,al ;----------------------------------------------------------- Dec dx ; Lock NCT6776D al,0aah dx,al PCE-5128/7128 User Manual...

  • Page 99: Appendix B I/O Pin Assignments

    Appendix I/O Pin Assignments...

  • Page 100: Parallel Port Connector (Lpt1)

    Parallel Port Connector (LPT1) Table B.1: Parallel port connector (LPT1) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active VGA Connector (VGA1) Table B.2: VGA connector (VGA1) Signal Signal GREEN BLUE H-SYNC V-SYNC PCE-5128/7128 User Manual...

  • Page 101: Rs 232 Serial Port (Com12)

    RS 232 Serial Port (COM12) Table B.3: RS-232 serial port (COM2) Signal SOUT USB 2.0 Header (USB56 & 910) Table B.4: USB Header (USB56 & 910) Signal Signal USB1_VCC5 USB2_D+ USB2_VCC5 USB1_D- USB2_D- USB1_D+ PCE-5128/7128 User Manual...

  • Page 102: Usb3.0 Header (Usb12)

    Table B.5: USB 3.0 Header (USB12) Signal Signal USB1_VCC5 USB_P+_P2 USB3.0_RXN_P1 USB_P-_P2 USB3.0_RXP_P1 USB3.0_TXP_P2 USB3.0_TXN_P1 USB3.0_TXN_P2 USB3.0_TXP_P1 USB3.0_RXP_P2 USB_P-_P1 USB3.0_RXN_P2 USB_P+_P1 USB2_VCC5 Reserve PS/2 Keyboard/Mouse Connector (KBMS1) Table B.6: PS/2 keyboard/mouse connector (KBMS1) Signal KB DATA MS DATA KB CLOCK MS CLOCK PCE-5128/7128 User Manual...

  • Page 103: External Keyboard Connector (Kbms2)

    Table B.8: CPU fan power connector (CPUFAN1) Signal +12V Detect Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) Table B.9: Power LED and keyboard lock connector (JFP3 / PWR_LED & KEY LOCK) Signal LED power (+3.3 V) KEYLOCK# PCE-5128/7128 User Manual...

  • Page 104: External Speaker Connector (Jfp2 / Speaker)

    SPK_CN17P2 SPK_CN17P3 SPK_CN17P4 B.11 Reset Connector (JFP1 / RESET) Table B.11: Reset connector (JFP1 / RESET) Signal RESET # B.12 HDD LED (JFP2 / HDDLED) Table B.12: HDD LED (JFP2 / HDDLED) Signal HDD LED SATA LED PCE-5128/7128 User Manual...

  • Page 105: Atx Soft Power Switch (Jfp1 / Pwr_Sw)

    Hi-definition Audio Link Connector (HDAUD1) Table B.14: Hi-definition audio link connector (HDAUD1) Signal Signal ACZ_VCC ACZ_SYNC ACZ_BITCLK ACZ_SDOUT ACZ_SDIN0 ACZ_SDIN1 -ACZ_RST ACZ_12V B.15 SM Bus Connector (JFP2 / SNMP) Table B.15: SM bus connector (JFP2 / SNMP) Signal SMB_DATA SMB_CLK PCE-5128/7128 User Manual...

  • Page 106: Lan1 And Lan2 Led Connector (Lanled1)

    Table B.16: LAN1 and LAN2 LED connector (LANLED1) Signal #LAN1_ACT #LAN2_ACT V33_AUX V33_AUX #LAN1_LINK1000 #LAN2_LINK1000 #LAN1_LINK100 #LAN2_LINK100 V33_AUX B.17 GPIO Header (GPIO1) Table B.17: GPIO header (GPIO1) Signal SIO_GPIO0 SIO_GPIO4 SIO_GPIO1 SIO_GPIO5 SIO_GPIO2 SIO_GPIO6 SIO_GPIO3 SIO_GPIO7 VCC_GPIO PCE-5128/7128 User Manual...

  • Page 107: Fixed I/O Ranges Decoded By Intel Pch

    Forwarded to LPC or RESERVED LPC or PCIe2 PCIe 89h–8Bh RESERVED RESERVED Not Decoded Forwarded to LPC or 8Ch–8Eh RESERVED LPC or PCIe2 PCIe RESERVED RESERVED Not Decoded Alias to 80h Alias to 80h Forwarded to LPC PCE-5128/7128 User Manual...

  • Page 108: System I/O Ports

    ECP Printer Port(LPT1) 3B0h-3BBh Graphics 3C0h-3DFh Graphics 3F8h-3FFh Communication Port (COM1) 400h-47Fh PMBASE 500h-57Fh GPIOBASE 600h-67Fh PCA-COM485 Module I/O used 778h-77Fh ECP Printer Port(LPT1) C80h-C9Fh Communication port (COM3-6) for PCA-COM232 module CA0h-CBFh Communication port (COM8-11) for PCA-COM485 module PCE-5128/7128 User Manual...

  • Page 109: Interrupt Assignments

    PCI Slot 2 AD30 INT C, D, A, B GNT B REQ B PCI Slot 3 AD29 INT D, A, B, C GNT C REQ C PCI Slot 4 AD28 INT A, B, C, D GNT D REQ D PCE-5128/7128 User Manual...
  • Page 110 PCE-5128/7128 User Manual...

  • Page 111: Appendix C Programming The Gpio

    Appendix Programming the GPIO...

  • Page 112: Supported Gpio Register

    MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------- Configure logical device, configuration register CRE0,CRE1,CRE2 --------------------------------------------------------------- MOV DX,2EH MOV AL,09H OUT DX,AC DEC DX MOV AL,30H OUT DX,AL INC DX IN AL,DX OR AL,10000000B DEC DX MOV AL,07H OUT DX,AL PCE-5128/7128 User Manual...
  • Page 113 ;Set GPIO is normal not inverter OUT DX,AL; DEC DX MOV AL,E1H OUT DX,AL INC DX MOV AL,??H ; Put the output value into AL OUT DX,AL ------------------------------------------ Exit extended function mode | ------------------------------------------ MOV DX,2EH MOV AL,AAH OUT DX,AL PCE-5128/7128 User Manual...
  • Page 114 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...

This manual is also suitable for:

Pce-7128

Table of Contents
