  • Page 1 PCA-6155V ® Full-size Pentium PICMG PCI/ISA-bus CPU card with VGA...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted, 1998. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Packing List

    If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1. Visit the Advantech web sites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product.

  • Page 4: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 70 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 5 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.

  • Page 6: Table Of Contents

    Contents Chapter 1 Hardware Configuration ......1 Introduction ................2 Specifications ..............3 Standard SBC functions ............3 VGA interface ..............4 SSD function ................4 Mechanical and environmental specifications .....4 Board Layout: Dimensions ..........5 Jumpers and Connectors ...........6 Board Layout: Jumper Locations ........8 Board Layout: Connector Locations ........9 Safety Precautions ............10 Jumper Settings ..............10 1.8.1 CPU clock ratio selection (JP12) ......11...
  • Page 7 Chapter 2 Connecting Peripherals ......19 Enhanced IDE Connector (CON1, CON2) ....21 Floppy Drive Connector (CN1) ........22 Parallel Port Connector (CN2) ........22 IR Connector (CN5) ............23 USB Connector (CN6) .............23 VGA Display Connector (CN7) ........23 Keyboard & PS/2 Mouse Connector (CN16)....23 Front Panel Connector (CN3 and CN4;...
  • Page 8 Chapter 4 PCI SVGA Setup ........39 Introduction ..............40 Before You Begin .............40 Utility Disk ................41 Driver Installation ............41 4.4.1 Windows setup ............42 4.4.2 DOS setup ..............43 Windows 95 Drivers Setup Procedure ......44 Windows NT Drivers Setup Procedure ......45 Step 1..................45 Step 2..................45 Step 3..................45 OS/2 Drivers Setup Procedure ........46...
  • Page 9 Appendix A Programming the Watchdog Timer ..51 Programming the Watchdog Timer .........52 Appendix B Installing PC/104 Modules ..... 55 Installing PC/104 modules ..........56 Appendix C Pin Assignments ........59 C.1 CRT Display Connector (CN7) ........60 C.2 COM2 RS-232/422/485 Serial Port (CN9, CN11) ....60 C.3 External Keyboard Connector (CN10) ......61 C.4 COM1 RS-232 Serial Port (CN13) .........61 C.5 Keyboard and Mouse Connnector (CN16) ....
  • Page 10 Table 2-1: PCA-6155V connectors ................20 Table 2-2: Serial port connections (COM1, COM2) ..........25 Table 2-3: PCA-6155V serial port default settings ............. 25 Table B-1: PCA-6155V PC/104 connectors (CN14) ..........58 Table C-1: PCA-6155V CRT display connector ............60 Table C-2: PCA-6155V COM2 RS-232/422/485 series port ........
  • Page 11 Figures Figure 1-1: PCA-6155V board layout: dimensions ............5 Figure 1-2: PCA-6155V board layout: Jumper locations ..........8 Figure 1-3: PCA-6155V board layout: Connector locations ........9 Figure 3-1: Setup program initial screen ..............28 Figure 3-2: CMOS setup screen .................. 29 Figure 3-3: BIOS features setup screen ...............

  • Page 13: Chapter 1 Hardware Configuration

    Hardware Configuration This chapter gives background information on the PCA-6155V. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Specifications • Board layout: dimensions • Board layout: jumper locations •...

  • Page 14: Introduction

    CPU card which can release the Pentium processor's full potential and provide unprecedented performance compared to current 64-bit processor board. The PCA-6155V offers all the func- tions of an industrial computer on a single board, full-size CPU card. This card uses an Intel Pentium, Pentium MMX, AMD K5, AMD K6, Cyrix M1 or Cyrix MX processor.

  • Page 15: Specifications

    Specifications Standard SBC functions ® • CPU: Intel Pentium , Pentium MMX, AMD K5, AMD K6, Cyrix M1, Cyrix MX, or IDT Win Chip C6 • BIOS: Award 128 KB (1 Mbit) memory; supports plug and play • Chipset: SiS5598 •...

  • Page 16: Vga Interface

    • Board size: 338 x 122 mm • Max. power requirements: +5 V (4.75 ~ 5.25 V) @ 7 A • Operating temperature: 0 ~ 60° C (32 ~ 140° F) • Board weight: 0.5 kg (1.2 lb) PCA-6155V User's Manual...

  • Page 18: Jumpers And Connectors

    The table below lists the function of each of the board's jumpers and connectors. Later sections in this chapter give instructions on setting jumpers and detailed information on each jumper setting. Chapter 2 gives instructions for connecting external devices to your card. Table 1-1: PCA-6155V jumpers Number Function HDD/LED Hardware reset...

  • Page 19: Table 1-2: Pca-6155V Connectors

    Table 1-2: PCA-6155V connectors Number Function Floppy disk connector Parallel port Speaker connector Power LED and keyboard lock IR port USB connector VGA connector COM2 RS-422/485 port CN10 External keyboard CN11 COM2 RS-232 port CN13 COM1 port CN14 PC/104 A, B, C, D...

  • Page 22: Safety Precautions

    To "open" a jumper you remove the cap. Sometimes a jumper will have three pins, labeled 1, 2 and 3. In this case you connect either pins 1 and 2 or 2 and 3. PCA-6155V User's Manual...

  • Page 23: Cpu Clock Ratio Selection (Jp12)

    Open Open Open Open Open Closed Closed Closed Closed Closed Closed 2-3 Closed 2-3 Closed 2-3 Closed 2-3 Closed 2-3 The jumper settings are schematically depicted in this manual as follows: Open Open Closed Closed Closed 2 - 3 Closed 2 - 3 Open Open Open...

  • Page 24: Cpu External (Bus) Frequency Selection (Jp3)

    CPU. These allow the selection of the CPU's external frequency (or bus clock). The CPU's external frequency multiplied by the CPU clock ratio equals the CPU's internal frequency (i.e. the advertised CPU speed). Table 1-4: CPU external (bus) frequency selection (JP3) PCA-6155V User's Manual...

  • Page 25: Cpu Core Voltage Select (Jp4)

    1.8.3 CPU core voltage select (JP4) Table 1-5: CPU voltage select (JP4) Voltage Voltage 2.0 V 2.1 V 2.2 V 2.3 V 2.4 V 2.5 V 2.6 V 2.7 V 2.8 V 2.9 V 3.0 V 3.1 V 3.2 V *3.3 V 3.4 V 3.5 V...

  • Page 26: Table 1-6: Setting Jumpers According To Internal Speed Of Cpu

    CPU Model Freq. Ratio Bus Freq. Bus Freq. (JP3) Freq. Ratio (JP12) 1 - 2 3 - 4 1 - 2 3 - 4 5 - 6 Intel Pentium 3.5x Intel Pentium 3.0x Intel Pentium 2.5x Intel Pentium 2.5x Intel Pentium 2.0x Intel Pentium 2.0x...

  • Page 27: Watchdog Timer Configuration (Jp7)

    1.8.4 Watchdog timer configuration (JP7) An on-board watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup involves two jumpers and running the control software. (Refer to Appendix A.) 1.8.5 Watchdog timer action (JP7) When the watchdog timer activates (CPU processing has come to a...

  • Page 28: Doc ® 2000 Address Setting (Jp5)

    "Clear CMOS". Table 1-10: CMOS clear selection (JP15) *Normal CMOS data clear JP15 * default setting 1.8.9 External speaker and internal buzzer (CN3) Table 1-11: External speaker and internal buzzer (CN3) External speaker *Internal buzzer * default setting PCA-6155V User's Manual...

  • Page 29: Installing Dram (Simms And Dimms)

    Installing DRAM (SIMMs and DIMMs) You can install from 2 to 256 MB of any brand DRAM into your PCA-6155V. The card provides two 72-pin SIMM (Single In-line Memory Module) and two 168-pin DIMM (Dual In-line Memory Module) sockets. Each socket accepts 1, 4, 8, 16, 32 or 64 MB SIMMs, or 8 to 128 MB DIMMs.

  • Page 30: Installing Dimms

    Note: We do not recomend the use of both SIMMs and DIMMs at the same time, due to their different voltages. This may result in unstable system operation. PCA-6155V User's Manual...

  • Page 31: Chapter 2 Connecting Peripherals

    Peripherals This chapter explains how to connect peripherals, switches and indicators to the PCA-6155V board. You can access most of the connectors from the top of the board while it is installed in the chassis. If you have a number of cards installed, or...

  • Page 32: Table 2-1: Pca-6155V Connectors

    The following table lists the connectors on the PCA-6155V. Table 2-1: PCA-6155V connectors Number Function CON 1/ CON 2 Enhanced IDE ports Floppy disk connector Parallel port Speaker connector Power LED and keyboard lock IR port USB connector VGA connector...

  • Page 33: Enhanced Ide Connector (Con1, Con2)

    Enhanced IDE Connectors (CON 1, CON 2) You can attach four IDE (Integrated Device Electronics) drives to the PCA-6155V’s internal controller. The PCA-6155V CPU card has two EIDE connectors. Wire number 1 on the cable is red or blue, the other wires are gray.

  • Page 34: Floppy Drive Connector (Cn1)

    Floppy Drive Connector (CN1) You can attach up to two floppy disk drives to the PCA-6155V’s on-board controller. You can use any combination of 5.25" (360 KB/1.2 MB) and/or 3.5" (720 KB/1.44/2.88 MB) drives. The card comes with a 34-pin daisy-chain drive connector cable. On one end of the cable is a 34-pin flat-cable connector.

  • Page 35: Ir Connector (Cn5)

    The USB interfaces can be disabled in the system BIOS setup. VGA Display Connector (CN7) The PCA-6155V provides a VGA controller for a high resolution VGA interface. The PCA-6155V's CN7 is a DB-15 connector for VGA monitor input. Pin assignments for the CRT display are detailed in Appendix C.

  • Page 36: Front Panel Connector (Cn3 And Cn4; Jp1, Jp2)

    JP1, JP2) Next, you may want to install external switches to monitor and control the PCA-6155V. These features are optional - install them only if you need them. The front panel connector (CN3) is a 4-pin male; CN4 is a...

  • Page 37: Rs-232 Connection (Com1-Cn13)

    BIOS setup. The table below shows the settings for the PCA-6155V board's ports: Table 2-3: PCA-6155V serial port default settings Port Address Interrupt...
  • Page 38 PCA-6155V User's Manual...

  • Page 39: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 40: Award Bios Setup

    This type of information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off. 3.1.1 Entering setup Turning on the computer and pressing <DEL> immediately will allow you to enter Setup. PCA-6155V User's Manual...

  • Page 41: Standard Cmos Setup

    3.1.2 Standard CMOS setup Choose the “STANDARD CMOS SETUP” option from the INITIAL SETUP SCREEN Menu, and the screen below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. ROM PCI/ISA BIOS (2A5IIAKB) CMOS SETUP UTILITY AWARD SOFTWARE, INC.

  • Page 42: Bios Features Setup

    The “BIOS FEATURES SETUP” screen appears when choosing the BIOS FEATURES SETUP item from the CMOS SETUP UTILITY Menu. It allows the user to configure the PCA-6155V according to his particular requirements. Below are some major items that are provided in the BIOS...
  • Page 43 CPU Internal Cache/External Cache Depending on the CPU/chipset design, these options can speed up memory access when enabled. Quick Power On Self Test This option speeds up the Power-On Self Test (POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or skips some of the items during the test.
  • Page 44 Typematic Rate: 6, 8, 10, 12, 15, 20, 24, 30. Typematic Delay (msec) When holding down a key, the Typematic Delay is the time interval between the appearance of the first and second characters. The input values (msec) for this category are: 250, 500, 750, 1000. PCA-6155V User's Manual...
  • Page 45 Security Option This setting determines whether the system will boot if the password is denied, while limiting access to Setup. Note: To disable security, select PASSWORD SETTING in the main menu. At this point, you will be asked to enter a password. Simply press the <ENTER> key to disable security.

  • Page 46: Chipset Features Setup

    PCA-6155V. Figure 3-4: CHIPSET features setup screen VGA Shared Memory Size Share memory architecture can support 0.5 MB, 1MB, 1.5 MB, 2 MB, 3 MB, 3.5 MB and 4 MB of system memory. PCA-6155V User's Manual...

  • Page 47: Power Management Setup

    3.1.5 Power management setup The power management setup controls the CPU card's “green” features. The following screen shows the manufacturer’s default. Figure 3-5: Power management setup screen Power Management This option allows you to determine if the values in power manage- ment are disabled, user-defined, or predefined.

  • Page 48: Pci Configuration Setup

    These default values are loaded automatically if the stored record created by the Setup program becomes corrupted (and therefore unusable). 3.1.8 Load setup defaults “LOAD SETUP DEFAULTS” loads the values required by the system for maximum performance. PCA-6155V User's Manual...

  • Page 49: Integrated Peripherals

    3.1.9 Integrated Peripherals Figure 3-7: Integrated peripherals Note: If you enable the IDE HDD block mode, the en- hanced IDE driver will be enabled. 3.1.10 Password setting To change, confirm, or disable the password, choose the “PASS- WORD SETTING” option from the Setup main menu and press [Enter]. The password can be at most 8 characters long.

  • Page 50: Save & Exit Setup

    This record is required for the system to operate. 3.1.13 Exit without saving Selecting this option and pressing the [ENTER] key lets you exit the Setup program without recording any new values or changing old ones. PCA-6155V User's Manual...

  • Page 51: Chapter 4 Pci Svga Setup

    PCI SVGA Setup The PCA-6155V features an on-board VGA interface. This chapter provides instructions for installing and operating the software drivers on the included display driver diskette.

  • Page 52: Introduction

    The enhanced display drivers for the PCA-6155V board are located on the software installation diskette. You must install the drivers and utility software by using the supplied SETUP program for DOS drivers.

  • Page 53: Utility Disk

    Utility Disk The PCA-6155V is supplied with software utility disks that hold the necessary files for setting up the VGA display and Ethernet and Windows controller. The disks are labeled as follows: Disk 1: VGA utility for Windows NT Disk 2: VGA utility for Windows 3.1 English version...

  • Page 54: Windows Setup

    To change the color scheme, select the Control Panel from the Main window. Select the Color icon. You will be shown the current color scheme. Choose a new color scheme and click the OK button. PCA-6155V User's Manual...

  • Page 55: Dos Setup

    4.4.2 DOS setup Step 1: Install Windows as you normally would for a VGA display. Run Windows to make sure that it is working correctly. Then exit Windows. Step 2: Place the display driver diskette in drive A. Type A: <EN- TER>...

  • Page 56: Windows 95 Drivers Setup Procedure

    1. Boot system with VGA or SuperVGA driver. 2. Select properties from a menu after right button press. 3. Select Display. 4. Select Change Display. 5. Select Change Monitor. 6. Select Change Adapter. 7. Select Have Disk. PCA-6155V User's Manual...

  • Page 57: Windows Nt Drivers Setup Procedure

    Windows NT Drivers Setup Procedure Step 1 1. Install Windows NT as you normally would for a VGA display. 2. First click the Start button, choose Settings and click on the Control Panel. 3. Choose the Display icon and click on the icon. 4.

  • Page 58: Os/2 Drivers Setup Procedure

    When the setup program is completed, you will need to perform a shutdown and then restart the system in order for changes to take effect. A log of the information output during the install can be found in <root>:\OS2\INSTALL\DISPLAY.LOG PCA-6155V User's Manual...
  • Page 59 4. After restarting the system: a) Open the OS/2 System folder. b) Open the System Setup folder. c) Open the Display Driver Install Object. Steps a), b) and c) will execute the Display Driver Installation (DSPINSTL) utility program to finish installation of the new drivers.

  • Page 60: Selecting Monitor Type

    Note that refresh rates other than 60 Hz are only valid when the display is switched to CRT Only display mode. 5. Close the System-Settings notebook. 6. Perform the shutdown and restart for the changes to take effect. PCA-6155V User's Manual...

  • Page 61: Installation Notes

    Installation notes 1. During the installation of this driver, DISPLAY.LOG and DSPINSTL.LOG files are created in the \OS2\INSTALL directory. These files identify the OS/2 system files that were updated, and indicate whether the installation was successful. the DISPLAY.LOG file also contains a string that identifies the version of driver that was installed.
  • Page 62 PCA-6155V User's Manual...

  • Page 63: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCA-6155V is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 64: Programming The Watchdog Timer

    The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec. to 62 sec. Data Time Interval 1 sec. 2 sec. 3 sec. 4 sec. • • • • • • 62 sec. PCA-6155V User's Manual...
  • Page 65 After data entry, your program must refresh the watchdog timer by rewriting the I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). The following example shows how you might program the watchdog timer in BASIC: Watchdog timer example program OUT &H443, data REM...
  • Page 66 PCA-6155V User's Manual...

  • Page 67: Appendix B Installing Pc/104 Modules

    Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules.

  • Page 68: Installing Pc/104 Modules

    The PCA-6155V's PC/104 connectors give you the flexibility to attach PC/104 modules. Installing these modules on the PCA-6155V is quick and simple. The following steps show how to mount the PC/104 modules: 1. Remove the PCA-6155V from your system paying particular attention to the safety instructions already mentioned above.

  • Page 69: Figure B-1: Pc/104 Module Mounting

    PC/104 Mounting Support Figure B-1: PC/104 module mounting diagram 82.5 95.9 φ 90.8 φ Unit: mm (±0.1) 85.1 90.2 Figure B-2: PC/104 module dimensions Appendix B Installing PC/104 Modules...

  • Page 70: Table B-1: Pca-6155V Pc/104 Connectors (Cn14)

    Table B-1: PCA-6155V PC/104 connectors (CN14) Signal Signal Number Row A Row B Row C Row D IOCHCHK* 0 V SBHE* MEMCS16* RESETDRV LA23 IOCS16* +5 V LA22 IRQ10 IRQ9 LA21 IRQ11 -5 V LA20 IRQ12 DRQ2 LA19 IRQ15 -12 V...

  • Page 71: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CRT display connector • RS-232/422/485 serial port connector • Keyboard and mouse connector • External keyboard connector • IDE connector • USB connector • CPU fan power connector •...

  • Page 72: Crt Display Connector (Cn7)

    Table C-1: PCA-6155V CRT display connector Signal Signal GREEN BLUE DDCDAT H-SYNC V-SYNC DDCCLK C.2 COM2 RS-232/422/485 Serial Port (CN9, CN11) Table C-2: PCA-6155V COM2 RS-232/422/485 series port CN11 RS-232 port RS-422 port RS-485 port TXD- DATA- TXD+ DATA+ RXD+ RXD-...

  • Page 73: External Keyboard Connector (Cn10)

    C.3 External Keyboard Connector (CN10) Table C-3: PCA-6155V external keyboard connector Signal DATA C.4 COM1 RS-232 Serial Port (CN13) Table C-4: PCA-6155V COM1 RS-232 serial port Signal Appendix C Pin Assignments...

  • Page 74: Keyboard And Mouse Connnector (Cn16)

    C.5 Keyboard and Mouse Connnector (CN16) Table C-5: PCA-6155V keyboard and mouse connector Signal KB DATA MS DATA KB CLOCK MS CLOCK PCA-6155V User's Manual...

  • Page 75: Ide Hard Drive Connector (Con1, Con2)

    C.6 IDE Hard Drive Connector (CON1, CON2) 39 37 ..3 1 40 38 ..4 2 Table C-6: PCA-6155V IDE hard drive connector Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10...

  • Page 76: Usb Connector (Cn6)

    C.7 USB Connector (CN6) Table C-7: USB1/USB2 connector USB1 USB2 Signal Signal +5 V +5 V Chassis GND C.8 CPU Fan Power Connector (CN15) Table C-8: PCA-6155V CPU fan power connector Signal +12 V PCA-6155V User's Manual...

  • Page 77: Floppy Drive Connector (Cn1)

    C.9 Floppy Drive Connector (CN1) 33 31 ..34 32 ..4 Table C-9: PCA-6155V floppy drive connector Signal Signal DENSITY SELECT* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0*...

  • Page 78: Parallel Port Connector (Cn2)

    C.10 Parallel Port Connector (CN2) 25 23 ..26 24 ..Table C-10: PCA-6155V parallel port connector Signal \STROBE \AUTOFD \INIT \SLCTINI \ACK BUSY SLCT PCA-6155V User's Manual...

  • Page 79: Hdd Led Connector (Jp1)

    C.11 IR Connector (CN5) Table C-11: PCA-6155V IR connector Signal +5 V IR_RX IR_TX C.12 HDD LED Connector (JP1) Table C-12: PCA-6155V HDD LED connector Signal Appendix C Pin Assignments...

  • Page 80: System I/O Ports

    Monochrome display and printer adapter(LPT1) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 * PNP audio I/O map range from 220 ~ 250H (16 bytes) MPU-401 select from 300 ~ 330H (2 bytes) PCA-6155V User's Manual...

  • Page 81: Dma Channel Assignments

    C.14 DMA Channel Assignments Table C-14: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available * Audio DMA select 0, 1 or 3 Appendix C Pin Assignments...

  • Page 82: Interrupt Assignments

    Addr. range (Hex) Device F000h - FFFFh System ROM C800h - EFFFh Unused C000h - C7FFh Expansion ROM B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused A000h - AFFFh EGA/VGA graphics 0000h - 9FFFh Base memory PCA-6155V User's Manual...

  • Page 83: Appendix D Doc ® 2000 Installation Guide

    ® 2000 Installation Guide This appendix contains information on ® the DiskOnChip 2000 quick installation guide. It includes: ® • DiskOnChip 2000 installation instructions • Additional information and assistance...

  • Page 84: Diskonchip ® 2000 Quick Installation Guide

    (c:) using the DUPDATE utility. (set as c:) DUPDATE D /S: DOC104.EXB /FIRST (set as d:) DUPDATE C /S: DOC104.EXB PCA-6155V User's Manual...

  • Page 85: Additional Information And Assistance

    Additional information and assistance 1. Visit M-Systems' Web site at www.m-sys.com where you can find Utilities Manual, Data Sheet and Application Notes. In ® addition, you can find the latest DiskOnChip 2000 S/W Utilities. 2. Contact your dealer for technical support if you need additional assistance, and have the following information ready: •...
  • Page 86 PCA-6155V User's Manual...
