- Page 1 ORIGINAL OPERATING INSTRUCTIONS AERO AEROTUBE WRG smart AEROTUBE AZ smart Wall-mounted ventilator with optional supply and exhaust air function, heat recovery and temperature/humidity sensor. Window systems Door systems Comfort systems...
-
Page 2: Table Of Contents
AEROTUBE Original operating instructions Contents Target group of this documentation ..............................3 Intended use ....................................3 Dimensions ...................................... 3 Safety notes ..................................... 4 Scope of delivery / equipment ............................... 5 Installation ....................................... 6 Unit function ....................................11 Operation general ..................................12 Operation via button on the device ..............................13 Operation via smartphone or tablet .............................13 Care and maintenance .................................14 Accessories ....................................19... -
Page 3: Target Group Of This Documentation
SIEGENIA. The installation instructions in this document must be complied with at all times. • Be sure to attach an original SIEGENIA weather grille to protect the device from the outside. • Do not install the unit in contaminated rooms and ensure that no hazardous substances can be drawn in. -
Page 4: Safety Notes
- Insert the Euro mains plug of the standard connecting cable only into a suitable 230 V AC mains power supply socket. - If the mains connection cable for the unit is damaged, it must be replaced by SIEGENIA, its customer service or an equally qualified person to eliminate hazards. -
Page 5: Scope Of Delivery / Equipment
Original operating instructions AEROTUBE Scope of delivery / equipment Item Designation AEROTUBE WRG smart AZ smart Front panel Casing with slider Mounting cover Axial ventilator Pipe inset (2-part) Filter holder — Filter G3 Heat storage/ceramic heat accumulator — Ventilation pipe Ø 160 Bag of screws (4 screws and dowels) Translation of the original operating instructions Weather grille (optional, see accessories page 19) -
Page 6: Installation
AEROTUBE Original operating instructions Installation Risk of injury due to pipe inset falling out. › Ensure that the pipe inset does not fall down. Proceed with caution. • The installation site of the AEROTUBE should not be accessible to third parties. •... - Page 7 Original operating instructions AEROTUBE 2. Drill core hole Note: To prevent condensate from discharging outwards, the hole must have an incline of 0.5–2°. However, the slope must not exceed 3° as this would make it impossible to remove the pipe inset from the ventilation pipe for maintenance purposes. 3.
- Page 8 AEROTUBE Original operating instructions 5. Shorten pipe 6. Insert pipe Attention! The pipe must be at least 270 mm long. 7. Insulate pipe (according to requirement) 8. Seal pipe Inside airtight seal Outside free-air seal 11.2016...
- Page 9 Original operating instructions AEROTUBE 9. Push complete pipe inset with mounting cover 10. Plaster the wall into the pipe 11. Remove front panel 12. Remove electronics cover 13. Remove mounting cover 14. Position filter casing 11.2016...
- Page 10 AEROTUBE Original operating instructions 15. Fix filter casing into place 16. Connect mains cable 17. Clip electronic cover into place 18. Connect axial ventilator 19. Clip front panel into place 20. Position the weather grille, screw into place and seal (according to version) 11.2016...
-
Page 11: Unit Function
Original operating instructions AEROTUBE Unit function Ventilation with blowers • Supply air operation The outside air (1) is drawn in and proceeds into the room as filtered supply air (2). • Exhaust air operation The exhaust air (3) is drawn in and proceeds into the atmosphere as exhaust air (4). •... -
Page 12: Operation General
AEROTUBE Original operating instructions Operation general LED indicator on button Operating status No LED lights up Blower level 0 (AEROTUBE is switched off) LED 1 lights up (green) Blower level 1 LED 2 lights up (green) Blower level 2 LED 1 lights up (green) Blower level 3 LED 2 lights up (green) Automatic mode... -
Page 13: Operation Via Button On The Device
Original operating instructions AEROTUBE Operation via button on the device • By pressing the button several times, you can activate the required blower levels and automatic mode (relaying). • After a power failure, the device switches to the last level to be used. Blower level 1 Blower level 2 Blower level 0... -
Page 14: Care And Maintenance
• The filter should be replaced as soon as the filter change LED flashes. • The filter should be replaced every 12 months, at the latest. • Only use genuine filters from SIEGENIA. You can purchase replacement filters from SIEGENIA or from specialist retailers (see accessories page 19). - Page 15 Original operating instructions AEROTUBE Filter replacement and cleaning of ceramic heat accumulator - AEROTUBE WRG smart Risk of injury due to pipe inset falling out. › Ensure that the pipe inset does not fall down. Proceed with caution. 1. Remove front panel 2.
- Page 16 AEROTUBE Original operating instructions 4. Remove filter and ceramic heat accumulator 5. Dispose of the old filter 6. Clean ceramic heat accumulator and leave to dry 7. Position ceramic heat accumulator in pipe inset 8. Clamp new filter behind filter holder 9.
- Page 17 Original operating instructions AEROTUBE 10. Push complete pipe inset into pipe 11. Connect axial ventilator 12. Clip front panel into place Attention! The cable outlet in the front panel must be on the slider side. 11.2016...
- Page 18 AEROTUBE Original operating instructions Filter replacement AEROTUBE AZ smart 1. Remove front panel 2. Remove filter 3. Dispose of the old filter 4. Insert new filter 5. Clip front panel into place Attention! The cable outlet in the front panel must be on the slider side.
-
Page 19: Accessories
In case of a malfunction, do not open the device or try to repair it under any circumstances. If the problem is not listed in the table below, please contact your installation firm or SIEGENIA directly: Tel. +49 271 3931-0... -
Page 20: Technical Specifications
-15°C - 40°C -15°C - 40°C Product data sheet according to EU Regulation 1254/2014 1253/2014 a Manufacturer SIEGENIA SIEGENIA b Model identification AEROTUBE WRG smart AEROTUBE AZ smart ― 17.62 kWh/(m² · a); E ― 10.99 kWh/(m² · a); E c Energy consumption (SEV);... - Page 21 Original operating instructions AEROTUBE Dimensions 11.2016...
-
Page 22: Liability
Environmental protection Although our products do not fall within the scope of the German Electrical and Electronic Equipment Act, SIEGENIA will continue to meet the requirements of this Act and will endeavour to completely eliminate the use of substances that are hazar- dous to the environment as soon as this becomes technically feasible. -
Page 23: Eu Declaration Of Conformity With Regard To Ce Marking
EN 50581:2012 Technical documentation on the evaluation of electrical and electronic devices with reference to the restriction of hazardous substances This declaration is responsible for the manufacturers / importers based in the European Union submitted by: SIEGENIA-AUBI KG Hardware and ventilation technology Duisburger Straße 8... - Page 24 Phone: + Industriestraße Telefax: + Wilnsdorf info@sie enia.com GERMANY www.sie enia.com Hun ary Phone: + SIEGENIA worldwide: Austria Phone: + Italy Phone: + Belarus Phone: + Poland Phone: + Benelux Phone: + Russia Phone: + China Phone: + South Korea Phone: +...
