5.11.3 MULTI-L2B16f

Pin Name
1 TEDS TEDS
2 Exc+ Excitation +
3 Exc- Excitation -
4 R+
5 In+
6 Aout Analogue output
7 Sns+ Sense +
8 Sns- Sense -
9 GND Ground
10 In-
11 +5V +5V (max. 100mA) supply
12 +14V5 +14.5V (max. 50mA) supply
13 IN0/A Counter input IN0/A
14 IN1/B Counter input IN1/B
15 IN2/Z Counter input IN2/Z
16 -14V5 -14.5V (max. 50mA) supply
HINT
5.11.3.1 MULTI-L2B16f: Voltage
measurement innovation measurement innovation
Doc-Version: 1.4.2
DEWESoft® DEWESoft®
Description
¼ Bridge/Shunt
Input +
Input -
You can use the analogue input, analogue output and counters at the same time.
Voltage - Single Ended
measurement innovation
DEWESoft® DEWESoft® DEWESoft®
Illustration 119: SIRIUS-MULTI-L2B16F pin-out
Voltage – Differential
Use only when the sensor is powered by the
excitation voltage of the module.
