DEWESOFT DS-TACHO-1 Technical Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

DS-TACHO-1
TECHNICAL REFERENCE MANUAL
DS-TACHO-1 V20-1





1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-TACHO-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEWESOFT DS-TACHO-1

Summary of Contents for DEWESOFT DS-TACHO-1

  • Page 1   DS-TACHO-1  TECHNICAL REFERENCE MANUAL  DS-TACHO-1 V20-1            1 ...

  • Page 2: Table Of Contents

    6.2. General Safety Instructions 9  6.2.1. Environmental Considerations 10  6.2.2. Product End-of-Life Handling 10  6.2.3. System and Components Recycling 10  6.2.4. General safety and hazard warnings for all Dewesoft systems 10  7. Documentation Version 13        DS-TACHO-1 V20-1...

  • Page 3: About This Document

    It gives you important information about the subject.  Please read carefully!    Hint   It gives you a hint or provides additional information about a subject.      Example   Gives you an example of a specific subject.        DS-TACHO-1 V20-1 3/13   ...

  • Page 4: Technical Data

    Input type  AC-Coupled, 1Hz  Input impedance  150 kOhm  Max input voltage:  ±50 Vdc, ±100 Vac  Power supply output  +5Vdc (max current depending on used  DEWESoft device: eg. DEWE-43: max 800 mA)      3.2. Connectors    Pin  Description  1  P out (+5 V) ...

  • Page 5: Output Connector Pinout

    Image 2: 7 pin LEMO connector on cable side      Pin  Description  1  Digital Out  2  n.c.  3  n.c.  4  n.c.  5  +5V power supply input (from e.g.  DEWE-43, SIRIUS)  6  n.c.  7  GND          DS-TACHO-1 V20-1 5/13   ...

  • Page 6: Operation

    (e.g. for an inductive probe, mount a screw every 90° on the                                     rotating disk and then divide the result by 4).    DS-TACHO-1 V20-1 6/13   ...
  • Page 7 This even makes it possible to correctly                                       detect a bad signal as shown above!          DS-TACHO-1 V20-1 7/13   ...

  • Page 8: Warranty Information

              year, after system delivery.    5.2. Support  Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties                  ...

  • Page 9: Printing History

                        technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ®                      ...

  • Page 10: Environmental Considerations

      2002/95/EC RoHS Directive. However, we take care of our environment and the product is lead-free.  6.2.4. General safety and hazard warnings for all Dewesoft systems  Safety of the operator and the unit depend on following these rules.  Use this system under the terms of the specifications only to avoid any possible danger. ...
  • Page 11                           Dewesoft sales and service office for service and repair to ensure that safety features are                        ...
  • Page 12 IEC 61326-3-1.    Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the                             scope of IEC 61326-3-1.      DS-TACHO-1 V20-1 12/13   ...

  • Page 13: Documentation Version

    Last modified: Mon 14. Sep 2020, 13:25    Doc-Version  Date [dd.mm.yy]  Notes  1.0  26.04.13  Initial revision  Input connector changed from screw terminal to DSUB 9pin  1.1  18.11.13  female  The NEW DSI-TACHO-1 manual - Reworked and revised  V20-1  14.09.2020  version       DS-TACHO-1 V20-1 13/13   ...
