4.3.2 Front side

4.3.3 Rear side

4.3.3.1 Power connector
Illustration 59: Power
Connector
2 If not available then use pin 6 of the GPS connector
measurement innovation measurement innovation
Doc-Version: 1.4.2
DEWESoft® DEWESoft® DEWESoft®
Illustration 57: SIRIUS-SBOX2: Connectors at the front side
Illustration 58: SIRIUS-SBOX2: Connectors at the rear side
Pin Name
1 V+
2 GND
3 Remote-On
measurement innovation measurement innovation
DEWESoft® DEWESoft®
L2B3f
Power connector (on the S-BOX): ECG.2B.303.CLV
Mating connector (for the cable): FGJ.2B.303.CLAD92
To power the system on, press the Power switch OR apply a
2
voltage between 3 and 30V to Remote-On pin
To power off the system press the Power switch or reduce the
voltage on Remote-On below 0.5V for more than one second.
measurement innovation
www.dewesoft.com
Enclosure Overview
DEWESoft® DEWESoft® DEWESoft®
measurement innovation
DEWESoft®
measurement innovation
Page 31/166
