9.2 Documentation version history

Revision number: 850
Last modified: Fri 13 Nov 2015, 09:22
Date
Version [dd.mm.yyyy]
1.0.0 26.11.2011
1.0.1 04.12.2011
1.0.2 04.12.2011
1.0.3 16.01.2012
1.0.4 12.03.2012
1.1.0 01.12.2012
1.1.1 21.12.2012
1.1.2 15.03.2013
1.1.3 16.03.2013
1.1.4 20.06.2013
measurement innovation measurement innovation
Page 164/166
DEWESoft® DEWESoft® DEWESoft®
☑ initial revision
☑ changes to orig. wiring image: counter voltage is 12V (instead of 15V)
☑ changes to orig. wiring image: CAN voltage is 15V (instead of 12V)
☑ Added bridge ranges of MULTI8
☑ corrected Illustration 62: SIRIUS-MULTI8 pin-out DSUB-15 (pin 12)
☑ updated/corrected module specifications
☑ updated Illustration 53: SIRIUS chassis: connectors on the back side
☑ removed STG module
☑ corrected captions of: Illustration 61: SIRIUS-MULTI8 and Illustration 63: SIRIUS-HV8
☑ Added bridge connection diagrams
☑ Corrected text of Bridge measurement tables
☑ Corrected typical power consumption: Table 7: SIRIUS-ACC8 specifications
☑ Added chapter about 'Isolation'
☑ Added 3.3.1.1 Troubleshooting
☑ Corrected module overview: MULTI module does not have digital output
☑ Intermediate version for VOLVO - only STG modules!
☑ added STG-M pin-out
☑ added STG8 modules
☑ major changes to chapter 5 SIRIUS Hardware
☑ added new chapter 6.1 Wireless Connection#
☑ updated to DEWESoftX 7.1 (screenshots, installation info)
☑ Major changes
☑ added ACC, HV, MULTI, STGM
☑ added STG LEMO10
☑ STG-LEMO7: pinnings were wrong
☑ updated specifications
☑ Added STGM+
☑ 4.7 DS-BP2: Battery Pack: added weight
☑ ACC+: added connector article numbers
☑ SNR → Typ. SNR
☑ STGM: Typ. SNR for 10 V range (Dual Core) is now 125dB (was 119dB).
☑ Corrected caption of Illustration 59 (was back side)
☑ added: 4.6.3.2 S-BOX: GPS connector
☑ removed Excitation Voltage from: Table 6: SIRIUS-ACC8 specifications
☑ changed counter specification tables for ACC+ and STGM+ to show values per module,
STGM+: removed digital output from specs table
☑ STG specifications enhanced
☑ Analogue-out specifications updated
