5.11.2.1 MULTI DSUB-15: Voltage
5.11.2.2 MULTI DSUB-15: Current
5.11.2.3 MULTI DSUB-15: Potentiometer
measurement innovation measurement innovation
Doc-Version: 1.4.2
DEWESoft® DEWESoft® DEWESoft®
Voltage - Single Ended
External Direct Shunt
measurement innovation
DEWESoft® DEWESoft®
Voltage – Differential
Use only when the sensor is powered by the
excitation voltage of the module.
External Loop Powered Shunt
