Table 1-12 10/100Base-T Ethernet Cable Assemblies - Lucent Technologies Metropolis Installation Manual

10/100Base-T Ethernet Cable Installation

Table 1-12 10/100Base-T Ethernet Cable Assemblies

Description
10/100baseT Ethernet cable
...........................................................................................................................................................................................................................................................
1 - 4 8
Black Box CAT5 protected pach panel JSM110A, for intra-office
applications only.
Important!
Groups as follows:
• J1, J2
• J3, J4
• J5, J6
• J7, J8
............................................................................................................................................................................
Step 6 Check off the appropriate box in Appendix E, Installation Checklist.
End of Steps
...........................................................................................................................................................................
Lucent Technologies - Proprietary
See notice on first page
Backplane connectors are associated with function
Function Group A
Function Group B
Function Group C
Function Group D
Cable Cable Length
Assembly # (feet)
848778114 20
848778122 50
848778106 100
848778148 150
848778130 300
Equipment and Cable Installation
®
Metropolis
DMX Backplane
Connections
J1-J8
365-372-304
Issue 7, March 2003
