Tools, Test Equipment and
Accessories

Tools, Test Equipment and Accessories

........................................................................................................................................................................
Overview
Tools, Test Equipment and
Accessories
Quantity
...........................................................................................................................................................................................................................................................
365-372-304
Issue 7, March 2003
This section lists the tools, test equipment and accessories needed to
perform all the procedures in this installation manual. Installers should
have both metric and English unit tools.
...................................................................................................................
Listed below are the required tools, test equipment and accessories.
Description
Screwdriver(s)
1 Thomas & Betts
Crimping Tool
†
2 Paladin Coaxial Wire
Stripper R-5648B D5
Replacement Paladin
Cassette R-5648B D5
1 Wire-Wrap Gun R-4496A
1 ESD Wrist Strap R-4987
1 Torque Wrench R-5952
1 Multimeter (Optional)ITE-
6379C
Lucent Technologies - Proprietary
See notice on first page
®
Metropolis DMX Access Multiplexer Physical Installation and Powering
Comments
A screwdriver(s) with the appropriate head(s) is
(are) required for securing the mounting
screws, repositioning the mounting brackets,
installing the interfacing cables, and for setting
the circuit breakers to the OFF position.
*
R-5648B The crimping tool and wire stripper are only
required if installing DS3 cables. The
replacement cassette is for the wire stripper
tool.
†
The wire-wrap gun is required for terminating
DS1 cable and must be able to accommodate 24
gauge wire.
A wrist strap must be worn when handling
circuit packs. Use the electrostatic discharge
(ESD) jack provided on the shelf.
A torque wrench (50-250 IN-LBS) is used
when tightening the
and Fan shelf to the frame. It is also used when
reattaching the mounting brackets to the
Metropolis
The voltmeter must be capable of measuring
DC voltage in the 40 to 60 volt range. The use
of the voltmeter is optional since the shelf will
alarm or shut down if the proper voltage is not
supplied.
®
Metropolis
DMX shelf
®
DMX shelf and Fan shelf.
