Miscellaneous (Environmental) Discrete
Telemetry Test
...........................................................................................................................................................................................................................................................
365-372-304
Issue 7, March 2003
Figure 7-2 Miscellaneous (Environmental) Discrete Functions
Env. Alarm/Status
Inputs (Open Door,
High Temp, High
Water, Fire, etc.)
To
Generator,
Pump, etc.
Lucent Technologies - Proprietary
See notice on first page
Remote Terminal
Input Common
20
Env. Input #1
1
Env. Input #2
2
Env. Input #19
19
Env. Output #1
21
Env. Output #2
22
Env. Output #3
23
Env. Output #4
24
Output Common
25
J11
Operational Tests
7 - 2 1
