LASER EMISSION DATA

ALL
* As measured under IEC measurement conditions for classification.
Laser Classification： Class 3B
Beam Diameter：r <5mm at aperture
Diverg3ence(each beam)： <12 mrad
Divergence(total light) ：<90 degrees
Transverse Beam Mode： TEM00
Cooling ： Fan Cooling
DM450B
Blue Laser Medium LD： InGaN 450nm, typical
Laser Power:450mW 450nm Blue CW
DM100G
Green Laser Medium DPSS： Nd:YVO4+KTP,532nm
Laser Power: 100mW 532nm Green CW
DM400RGB
Green Laser Medium DPSS： Nd:YVO4+KTP,532nm
Red Laser Medium LD： GaAIAs 650nm,typical
Blue Laser Medium LD： InGaN 450nm, typical
Laser Power:200mW 650nm Red CW, 50mW 532nm Green CW, 150mW 450nm Blue CW
DM200RGY
Green Laser Medium DPSS： Nd:YVO4+KTP,532nm
Red Laser Medium LD： GaAIAs 650nm,typical
Laser Power:200mW 650nm Red CW, 50mW 532nm Green CW
DM300RBP
Red Laser Medium LD： GaAIAs 650nm,typical
Blue Laser Medium LD： InGaN 450nm, typical
Laser Power:150mW 650nm Red CW, 150mW 450nm Blue CW
TDM-RGB400
Green Laser Medium DPSS： Nd:YVO4+KTP,532nm
Red Laser Medium LD： GaAIAs 650nm,typical
Blue Laser Medium LD： InGaN 450nm, typical
Laser Power:200mW 650nm Red CW, 50mW 532nm Green CW, 150mW 450nm Blue CW
