Procedure E. Power-Up (cont'd)
Step
11 Push the latching levers flat against the front panel to complete the card insertion.
12 Tighten the knurled screw above each latching lever to secure the card in the shelf.
13 Replace the connector panel cover.
14 Unplug and remove the grounding wrist strap.
15 Install the battery source fuse in the rack fuse bay that supplies power to the TimeSource
3100. The TimeSource 3100 enters its warm-up mode when power is applied. During the
warm-up period, the following conditions exist:
• Status GPS lamp is green
• Status SYS lamp is off
• E1 outputs are squelched, sending AIS (factory setting), or sending an SSM message,
as specified in the ED-EQPT command
• Optional eight T1 outputs (if equipped) are squelched, sending AIS (factory setting), or
3
sending an SSM message, as specified in the ED-EQPT command
• Optional four IRIG-B outputs (if equipped) are squelched
• 10 MHz and 1 pps outputs are on (unreliable while Status SYS lamp is off)
• TOD output is not enabled (factory setting)
Notes:
1. The CRIT lamp and other alarm indication lamps may light. The host computer may
display transient and standing alarm condition messages. Ignore alarms while the Status
SYS lamp is off during warm up, unless alarms apply to inputs and outputs that were
previously entered.
2. TL1 commands may be entered during warm-up to enable inputs and outputs, and to set
system parameters.
16 Use the Activate User command to log onto the system.
ACT-USER::TELECOM:<ctag>::TS3000!!;
17 If UTC time is desired, skip to Step 18. If local time is desired, use the Edit Date command
to set the date and time.
ED-DAT:::<ctag>::yyyy-mm-dd,hh-mm-ss:MODE=LOCAL;
yyyy= year (1998 to 2096)
mm= month (mm = 01 to 12)
dd=day in (dd = 01 to 31)
hh=hours (hh = 00 to 23)
mm= minutes (mm = 00 to 59)
ss=seconds (ss = 00 to 59)
Example command to set local time:
ED-DAT:::123::2000-06-15,14-25-00:MODE=LOCAL;
