Retrieve Performance Monitoring (cont'd)
PHASE1S Response Example (cont'd):
"SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,
0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,
0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-58-20"
/* LINK: 5001, CMD: RTRV-PM-EQPT::SPAN-A:C:: PHASE1S,,,,, */
;
PHASE1M Response Format:
<sid> <date> <time>
M <ctag>COMPLD
"SPAN-a:PHASE1M,<monval>,<monval>,
<monval>,<monval>,<monval>,<monval>,
<monval>,<monval>,<monval>,<monval>,
<vldty>,,,,<mondat>,<montm>"
/*LINK:<link>,CMD:<command>*/
;
Note:
•
•
•
•
TimeSource 3100
TL1 Reference
097-72020-01 Issue 9: November 2003
S S S S S S S S S
. . .
. . .
. . .
PHASE1M Data types:
The TimeSource 3100 collects a full 7 days of 1 minute phase data.
The 1 minute phase data is displayed in 1 hour groups. Each request for 1 minute
phase is synchronized to the hour.
Any mondat/montm combination outside of the past 7 day window is denied. Any
time increment may be entered. The system rounds the value to the nearest hour, i.e.,
the minute and second field of the montm is ignored.
The first value (monval) is the oldest value in the range selected. For example, if
montm = 8:45:32, the first monval will exceed time 8:00:00 followed by the value at
8:01:00, etc.
