With Four IRIG-B TOD Outputs

This system (990-72020-05) includes:
•
•
•
•
•
•
Note:
TimeSource 3100
Engineering and Ordering
097-72020-01 Issue 9: November 2003
S S S S S S S S S
TimeSource 3100 Shelf (090-72000-11)
TimeSource 3100 card with IRIG-B TOD outputs (090-72020-05)
Antenna (090-72010-97)
Antenna mounting kit (093-00001-01)
Hardware kit (093-72020-97) includes:
- Lightning suppressor (143-00018-01)
- Lightning suppressor mounting bracket (070-00300-02)
- Craft port-to-PC communications cable (060-00067-01)
System software (992-72020-05 or later)
This system requires a separately ordered BNC output module (990-72100-03).
