Installation

This section provides instructions for the installation of the NERO3PLUS projector.
Important: Installation procedures should be performed by a qualified AV system specialist.
Location
When installing the NERO3PLUS projector, take the following considerations into account.
Installation Type
Select the installation type that best suits your needs:
front or rear projection
•
floor or ceiling mount
•
Cooling
Make sure that the planned location for the projector has adequate ventilation. Check that
room temperature is below 35° C and that the projector is away from heating vents. Ensure a
minimum 0.20 m (5 in.) clearance on the left, right and rear sides of the projector.
Power Outlets
Verify that the powers outlets are grounded and preferably shielded from power surges and
fluctuations. A UPS is optional. NERO3PLUS power supply operates on any nominal line voltage
between 100-240 V AC, 50-60 Hz.
Cables
Check planned cable lengths for video and control cables and make sure these lengths do not
exceed specifications.
Ambient Light
Avoid or minimize light sources directed at the screen to preserve the quality of the projected
image.
Mounting
The projector can be Floor mounted (upright) or Ceiling mounted (inverted). Choose the
method that best suits your installation.
The NERO3PLUS projector has been design to be submit the EN60950/UL950 Safety Norms with
it's glass cabinet.
To determine where to position the projector, consider the size and shape of your screen, the
location of your power outlets, and the distance between the projector and the rest of your
equipment.
Important: The projection lens is centered to the chassis. Make sure the centerline of the lens is
centered horizontally to the center of the screen.
Floor Mounting
Place the projector on a secure and flat surface (such as a table or a shelf). Adjust the four
elevator feet at the bottom of the projector until the projector is level on all sides. Rotate the
adjustable feet clockwise to raise the projector or counter clockwise to lower it. Repeat with the
remaining feet as needed.
