Page 1: User Guide
SIM2 Multimedia M.150 User Guide... -
Page 2: Table Of Contents
Switching On and Off Chapter 4: Operation Viewing 3D Content 3D Menu Input Menu Main Menu Picture Image Setup Menu Memories Info Quick Menus Messages Chapter 5: Troubleshooting Chapter 6: Specifications Chapter 7: Projection Distances Chapter 8: Dimensions M.150 User Guide... -
Page 3: Important Information
Important information About this User Guide This User Guide describes how to set up and operate the M.150 LED 3D projector. Information contained in this User Guide may be updated from time to time due to product improvements and customer feedback. Visit www.sim2.com... - Page 4 EN 60825-1:1994 + A2:2001 + A1:2002 Take special care regarding movement of the lens Do not place objects in the slots on the side of the lens and also ensure that vertical lens movements are not impeded by external objects. Important information M.150 User Guide...
-
Page 5: Environment
• take it to your local waste disposal facility for recycling. You may return your old equipment to your SIM2 Authorized Dealer free of • charge when you buy a new product that is equivalent or has the same func- tions as the old one. - Page 6 As the optical system of the M.150 is extremely compact and has the purpose of de- veloping very high brightness and contrast, it is possible that a small quantity of light is visible outside of the projection area and will vary depending on the type of lens used and the zoom and shift setup.
-
Page 7: Chapter 1: Introduction
This all adds up to an incredible 3D experi- ence at home. The M.150 is designed for use with large screen sizes – up to 4 m (14 ft.) wide. A choice of two high quality glass lenses (T1 and T2) is available, giving the projectors a total throw ratio of 1.5-3.9:1. -
Page 8: System Components
1 x CD with Live Color Calibration software (for Windows-based computers) • If any items are missing or damaged, contact your SIM2 Authorized Dealer as soon as possible. Keep the original packaging in case anything has to be shipped. Optional Accessories Visus system (4 SIM2 Visus active shutter glasses and 1 IR emitter for SIM2 •... -
Page 9: Chapter 2: Overview
Plug here the female end of the AC power cord that is appropriate in main power switch your area. Switches the projector on or off. ❾ Connector Panel Contains the connections for all input, control and output signals. “Connections” on page for details Overview M.150 User Guide... -
Page 10: Remote Control
If you are using a programmable remote control, the setup software probably • allows importing of Pronto Hex codes. See SIM2 M.150 IR Control for a list of all the projector codes in Pronto Hex format, including a number of discrete codes for: ◦... -
Page 11: Projector Keypad
Operation The M.150 projector has two IR receivers, one on the front and one on the back of the unit. The operative range of the remote control is approximately 10 m (33 ft.). Make sure that there is nothing obstructing the infrared beam between the remote control and the IR receiver you are pointing to. -
Page 12: Connections
See “Screen” on page TRIG 3 12 V 100 mA max output, for motorized ana- morphic lens position control. See “Anamorphic Lens” on page ❽ 3D Sync OUT VESA DIN-3 connector for 3D IR Emitter cable. Overview M.150 User Guide... -
Page 13: 3D Ir Emitter
For CR2032 (3 V DC / 0.2 A) batteries ❷ Indicator light Indicates glasses status ❸ IR receiver Receives infrared signals from the 3D Emitter ❹ Lens Liquid crystal shutter ❺ Button Button for on and off Overview M.150 User Guide... -
Page 14: Chapter 3: Installation
Power Outlets Verify that the powers outlets are grounded and preferably shielded from power surges and fluctuations. A UPS is optional. M.150 power supply operates on any nom- inal line voltage between 100-240 V AC, 50-60 Hz. Cables Check planned cable lengths for video and control cables and make sure these lengths do not exceed specifications. - Page 15 Do not over-tighten the screws. Orientation By default, the M.150 is configured for a Front installation (projector installed upright and in front of the screen). If the projector is installed behind the screen or inverted, you can use the image orientation function of the projector (see “Orientation”...
-
Page 16: Connections
Keys” on page for details. Connections Proceed as follows to connect the M.150 to video sources, control devices, screen control systems, 3D sync emitter and AC power. When connecting your equipment: turn off all equipment before making any connections •... - Page 17 “RGBS Sync” on page 29. Control You can connect the M.150 projector to a Personal Computer or a control system through one of the following methods: RS-232 port, using a standard 9-pin straight serial cable • RS-232 port, using a USB to serial converter cable. In this case, installation of a •...
-
Page 18: Switching On And Off
3. The indicator light turns green and red and the status display shows 88 for a while. 4. The SIM2 logo appears on the screen within five seconds. 5. When the projector is ready for use (this can take approximately 40 seconds), if a valid signal is detected, an image appears on the screen (otherwise a black screen with the “No... -
Page 19: Chapter 4: Operation
Read 3D safety information at the beginning of this User Guide before viewing 3D content. Your M.150 projector is capable of displaying 3D Images of exceptional high quality; to ensure maximum enjoyment and trouble free viewing we recommend the following guidelines. -
Page 20: 3D Menu
OSD. To Watch 3D Content via Satellite, Cable and Games Console Switch on the M.150 and all other relevant products such as Satellite receiver • and AV receiver and ensure the correct inputs have been selected. - Page 21 PureMotion adjustment is available. 3D Input Format The M.150 checks AVI infoframe data and input signal resolution in order to determ- ine the appropriate 3D format. When automatic detection of 3D format is not pos- sible, choose one of the following options: (S-S) Side by Side Left and right halves of the image are separated, rescaled •...
-
Page 22: Input Menu
● Others Side by Side ● Top and Bottom Notes: 1. except Panoramic Input Menu The desired input can be selected by pressing the corresponding number key on the remote control or through the Input menu. Operation M.150 User Guide... -
Page 23: Main Menu
• function (see “Memories” on page 32) Setup and Menu sections provide access to installation and OSD adjustments. The set- tings in these sections are global (for all inputs and modes, not just the active one). Operation M.150 User Guide... -
Page 24: Picture
Alternatively use a scene composed of well-lit white objects surrounded by light objects with lower level lighting, and try to ensure that all the ob- jects can be separately identified. Operation M.150 User Guide... - Page 25 When viewing 3D contents, the PureMotion3D mode is automatically activated. DynamicBlack Improves the level of black and increases the depth and the detail of the image espe- cially in parts with low and medium brightness. It regulates light based on the Operation M.150 User Guide...
-
Page 26: Image
Anamorphic correctly displays a 16:9 image with over scan. • Letterbox displays a 4:3 letterbox image (source signal with black bands above • and below the picture) in such a way that it fills the 16:9 screen and maintains Operation M.150 User Guide... - Page 27 ◦ Standard the white point associated to the value selected in column 1 ◦ High, Medium, Low default white balance levels ◦ Native the projector native white point ◦ D75, D65, D55 the C standard CIE illuminants Operation M.150 User Guide...
- Page 28 To accurately set the Primaries and White Point you will need access to special- ized color measuring equipment and also the knowledge to use such equipment. Al- ternatively, contact the SIM2 Authorized Dealer where you purchased your product and ask them to arrange for an ISF certified calibrator to set up your projector.
-
Page 29: Setup
Keystone may cause artifacts in the image and may not be available when dis- playing specific 3D content (see Table 4.2). SIM2 recommends that you use this fea- ture only when necessary. RGBS Sync Indicates where the sync relative to the RGB signal is supplied. Choose: HV when the HV connector is used for the RBGS sync signal •... - Page 30 Menu This menu section provides access to OSD adjustments. Language Selects the desired OSD language. The M.150 can display the menus in English, Italian, French, German, Spanish, Swedish, Portuguese, Russian and Simplified Chinese. Source List Allows customization of the Input list. To change the status of an input: 1.
- Page 31 When enabled (Yes), the projector displays information about the current input signal every time a new signal is detected. If disabled (No) no information is displayed. Help Menu When enabled, the Help bar (providing tips for menu navigation) is displayed at the bottom of the main menu. Operation M.150 User Guide...
-
Page 32: Memories
● ● ● Color White ● ● ● ● Gamma ● ● ● ● LED Overlap ● ● ● 3D Input Format ● Notes: 1. YPrPb only 2. See Table 4.2 on page for more information Operation M.150 User Guide... - Page 33 3. press ● to open the corresponding pull-down menu 4. press ▴ and ▾ to highlight Rename 5. press ● on the remote control to enter Text Entry menu 6. use ◂ and ▸ to underline the character you would like to change Operation M.150 User Guide...
-
Page 34: Info
Out of range. This message appears when either the resolution or the vertic- • al/horizontal frequency of the input signal exceeds system specifications (for example a QXGA graphic signal). Operation M.150 User Guide... -
Page 35: Chapter 5: Troubleshooting
• until cooling is complete. After Standby mode is entered (indicator light solid red or solid orange), turn projector on again. Check the Status Display for any errors. Contact your SIM2 Authorized Dealer • for assistance if the error persists. - Page 36 ◦ If the problem persists then it is more than likely to be cable related. Try other cables. ◦ Try bypassing other product in the system chain. For example connect the Blu-ray player direct to the projector. Troubleshooting M.150 User Guide...
-
Page 37: Chapter 6: Specifications
Composite: NTSC 3.58/4.43, PAL B/G/H/I/M/N/60, SECAM (automatically selected) Components/RGBHV: 480i, 576i, 480p, 576p, 1080i 50/60, 720p 50/60, 1080p 24/25/30/50/60, VGA, SVGA, XGA, SXGA, UXGA HDMI: 480i, 576i, 480p, 576p, 1080i 50/60, 720p 50/60, 1080p 24/25/30/50/60, VGA, SVGA, XGA Specifications M.150 User Guide... - Page 38 Weight: 28.0 kg (61.7 lb.) approx. Temperature Operating: 10° C to 35° C Storage: -15° C to 55° C Certifications Low Voltage Directive: EN 60950-1/UL60950 EMC Directives: EN 55022, EN 55022 A1 A2, EN61000-3-2, EN61000-3-3 Specifications M.150 User Guide...
-
Page 39: Chapter 7: Projection Distances
21.5 73.2 41.2 12.6 12.7 25.0 80.2 45.1 13.8 13.9 27.4 87.2 49.0 10.7 15.0 15.1 29.8 115.9 65.2 14.3 20.0 20.1 39.6 130.7 73.5 16.1 22.5 22.6 44.7 174.3 98.1 21.4 30.0 30.2 59.6 Projection Distances M.150 User Guide... -
Page 40: Chapter 8: Dimensions
8 Dimensions M.150 dimensions in millimeters and (inches). Dimensions M.150 User Guide... - Page 44 10108 USA Today Way Miramar, FL 33025 USA Phone: + 1 954 4422999 Fax: + 1 954 4422998 Email: sales@sim2usa.com www.sim2usa.com SIM2 BRIONVEGA Co., Ltd Room 303-304, No. 244 Liaoning Road Shanghai 200080 – CN Phone/Fax: 86 1 62881991 Email: InfoCHINA@sim2.com SIM2 UK Steinway House Worth Farm Little Horsted Nr.
