Displays a summary of all stored
batches including the name, probe
type, number of readings and type.
In the following example, Batch 3
(B3) indicates an "F" 6000 coating
thickness probe was used to record a
total of "6" readings in "PA2" mode.
Press both (-)(+) buttons at any time to capture and save an image
copy of the current display. The last 10 screen captures are stored
in memory and can be accessed when connected to a computer
(see PosiSoft USB Drive pg. 19).
The PosiTector DPM can automatically record datasets into
memory at user selected time intervals. When selected, the Auto
Log icon will appear on the display, with a countdown timer until
the next dataset is stored. Readings on the display are only
updated when a dataset is stored.
Auto Log continues recording until the instrument loses power or
the user turns off Auto Log mode. Stored datasets will remain in
memory until full, then the oldest dataset or batch will be
overwritten to allow space for the next dataset.
Turn on Gage/
Cancel Auto Log
mode
NOTE:
It is recommended that fresh alkaline batteries be
installed prior to an extended Auto Log if not connected to
continuous USB
source for long-term use using the included USB cable.
(Advanced models only)

Screen Capture

Screen Capture

Auto Log Mode

Auto Log Mode
power. Connect the Gage to a USB power
17
Scroll through display
modes (Advanced
models only)
