Probes

Probes
When powered-up, the PosiTector automatically determines
which probe is attached and does a self-check.
To disconnect a probe from a body, slide the plastic probe
connector horizontally (in the direction of the arrow) away from the
body. Reverse these steps to attach a different probe. It
is not necessary to power-down the Gage when
switching probes.
The PosiTector body accepts a wide variety of probe
types including magnetic, eddy current and ultrasonic
coating thickness, surface profile, shore hardness
durometer, salt contamination and ultrasonic wall
thickness probes. See www.defelsko.com/probes
PosiTector DPM probes:
PosiTector DPM PosiTector DPM-S
Integral Surface Temperature Sensor
Magnetic Surface Temperature Sensor
Surface
Temperature
Air Temperature &
Relative Humidity
K-Type
Connector
Surface
Temperature
Probe also accepts other K-Type
thermocouple sensors (optional)
PosiTector DPM-A Anemometer PosiTector DPM-D
Integral Surface Temperature Sensor Cabled probe with NPT threads
1/2" NPT
Threads
Air Temperature &
Relative Humidity
Air Temperature &
Wind
Relative Humidity
Velocity
Sintered Metal Tip
(protects sensor)
7
