NOTES:
• PosiSoft.net and the PosiTector App are used to insert an
Image and Notes into a batch.
• Remove the last reading from the current open batch by
pressing (-).
• Calibration adjustments cannot be made if any measurements
were taken with that setting and stored into a batch.
• If memory is ON while continuous measurements are being
taken, only the last value on the display (when the probe is
lifted) is stored
measurements into memory (pg. 15).
• Each batch can contain a maximum of 10,000 readings.
Displays a summary of all stored
batches including the name, probe
type, number of readings and type.
In the following example, Batch 3
(B3) indicates an "F" 6000 coating
thickness probe was used to record a
total of "6" readings in "PA2" mode.
Press both (-)(+) buttons at any time to capture and save an image
copy of the current display. The last 10 screen captures are stored
in memory and can be accessed when connected to a computer
(see PosiSoft USB Drive pg. 27).
into memory. Scan Mode stores ALL
(Advanced models only)
S c r e e n
Sample Screen Captures
23
C a p t u r e
