Table Of Contents; Package Contents; Installation - Interlogix UVC-XP4DN-HR Quick Start Manual

Content
Package contents 3
Installation 3
Video connections 4
Set the lens mode 4
Attach the lens 5
Connect power 6
Mount the camera 6
Connect the monitor 7
Programming 7
OSD controls 7
Main menu 7
Specifications 9
Menu map 12

Package contents

Check the package and contents for visible damage. If any
components are damaged or missing, do not attempt to use the unit;
contact the supplier immediately. If the unit is returned, it must be
shipped back in its original packaging.
Package contents:

Multilingual Quick Start Guide

CD with User Manual in several languages

Camera

C-mount adaptor
CAUTION: Use direct plug-in UL listed power supplies marked Class
2 or LPS (limited power source) of the required output rating as listed
on the unit.

Installation

This section provides information on how to install the camera.
Quick Start Guide 3 EN
