Configurability

One of the key features of the controller is high level of adaptability of the system to the needs of
ever y particular application. The way, how to achieve this, is the configuration.
N :
OTE
Use LiteEdit PC software to read configuration from the controller or disk, view it, modify it and write
the configuration to controller or disk.
The firmware contains a number of binary inputs and outputs needed for all necessary
available in the firmware. But not all functions are required at the same time on different gen-sets and
also the controller hardware does not have so many input and output terminals. One of the main tasks
of the configurat ion is mapping of "logical" firmware inputs and outputs to the "physical" hardware
i nputs and outputs.
C onfiguration parts:
1. Mapping of logical binary inputs (functions)
terminals
2. Mapping of logical binary outputs (functions)
3. Changing language
The controller is delivered with a default configuration, which should fit to most s
applications. This default configuration can be changed only using PC and Lit
LiteEdit documenta tion for details.
N :
OTE
You need one of communication modules to connect the controller to a PC with LiteEdit. There is a
special easy removable service module for cases, where there is no communication module
permanently attached.
Once the configuration is modified, it can be stored in a file for later usage with ano
for backup purposes. The file
image of the controller at the moment of saving (if the controller is online to the PC) except firmware,
i.e. besides configuration there
copy of history log and a copy of alarm l
T he archive can be simply use
identical configu ration and settings.
What is in the package?
Accessories
IA-NT STD InteliATS
IL-NT-RS232 RS232 communication card
IL-NT-RS232-485 RS232 and RS485 communication card
IL-NT-S-USB Service USB communication card
*IL-NT RD Remote display software
IB-Lite Internet commu
*Remote display for IA-NT controllers uses standard IL-NT controller with Remote display software
N :
OTE
For detailed information about extension modules used with IA-NT controllers, please see the IL-NT,
IC-NT, IA-NT, ID-Lite-Accessory Modules manual.
