Table B.2: MicroATX motherboard options/MicroATX母板选择/MicroATX主
機板選擇
Model Name/
型号名称 /
PCI
型號名稱
1 (PCIe x16)
AIMB-581
1 (PCIe x4)
2 (PCI 32-bit)
1 (PCIe x16)
AIMB-580
1 (PCIe x4)
2 (PCI 32-bit)
1 (PCIe x16)
1 (PCIe x4)
AIMB-567
1 (PCIe x1)
2 (PCI 32-bit)
1 (PCIe x4)
AIMB-566
1 (PCI 32-bit)
1 (PCIe x16)
AIMB-564
1 (PCIe x4)
2 (PCI 32-bit)
1 (PCIe x1)
AIMB-562
2 (PCI 32-bit)
Table B.3: PICMG 1.3 Backplane options/PICMG 1.3 底板选择 /PICMG 1.3
底板選擇
Model Name/
型号名称 /
PCI
型號名稱
1 (PCIe x16), Gen 3
PCE-5B09-04A1E
3 (PCIe x4), Gen 3
4 (PCI 32-bit)
1 (PCIe x16), Gen 3
PCE-5B09-06A1E
1 (PCIe x4), Gen 3
6 (PCI 32-bit)
Bus/ 总线 / 匯流排
PCI/ISA
ISA
-
-
-
-
-
-
-
-
-
-
-
-
Bus/ 总线 / 匯流排
PCI/ISA
ISA
-
-
-
-
IPC-7132 User Manual/ 用户手册
17
SATA
4
6
4
6
7
2
SATA
7
7
