Environmental Specifications/ 环境规格 / 環境規格
1.3
Table 1.2: Environment Specifications
Environment
Temperature
Humidity
Vibration
Dimension Diagram/ 产品尺寸 / 產品尺寸
1.4
Operating
0 to 40° C (32 ~ 104° F)
10% to 85% @ 40° C
1 Gms
Figure 1.1 Dimension Diagram/ 产品尺寸 / 產品尺寸
Non-operating
-20 to 60° C (-4 ~ 140° F)
10% to 95% @ 40° C
2 Gms
IPC-7132 User Manual/ 用户手册
3
Unit: mm [inch]
