Remote Control

This section discusses how to connect and conigure the MTP SW6. Topics that are
covered, include:
•
•
•
•
The switcher can be remotely controlled via its rear panel Remote connector (Figure 13).
Remote control devices can be:
•
•
•
Figure 13.
NOTES: • The cable used to connect the Remote port to a computer, control
Simple Instruction Set Control
Windows-Based Program Control
Contact Closure Control
IR 102 Infrared Remote Control
A host device such as a computer or control system
A device such as an Extron IR 102 Universal remote control kit
A contact closure device such as an Extron KP 6 Keypad Control
RS-232
PIN
—
1
TX
2
REMOTE
RX
3
—
4
Gnd
5
—
6
—
7
—
8
—
9
Remote connector pinout
system, contact closure device, or IR control kit may need to be modiied
by removing pins or cutting wires. If unneeded pins are connected, the
switcher may hang up.
• For RS-232, Windows-based program, and IR control, use a control cable
with only pins 2, 3, and 5 connected. Otherwise, either cut the wires to the
other pins in hard-shelled connectors or remove the unneeded pins from
molded plugs
• See Simple Instruction Set Control
• See Windows-Based Program Control
use the control software.
• For contact closure, use a control cable with pins 2 and 3 disconnected.
Otherwise, either cut the wires to these pins in hard-shelled connectors or
remove these pins from molded plugs. See
information on how to make a remote contact closure device.
Contact
Closure Function
In #1 Input #1
— Transmit data
— Receive data
In #2 Input #2
Gnd Ground
In #3 Input #3
In #4 Input #4
In #5 Input #5
In #6 Input #6
for deinitions of the SIS commands.
for details on how to install and
Contact Closure Control
MTP SW6 • Remote Control
