Compac CNG Service Manual page 20

Parameter Switch
Menu Options
Menu Options
Dispenser Software Version
To Identify the Software Program Version
Number
Compac Industries Ltd.
Listed below is the order in which the Parameter switch menu options are
presented. There are different menu options depending on the current
setting of the C configuration code (see page 35).
The X indicates that you can achieve the displayed menu option,
regardless of what the indicated part is set to. You may need to change the
C configuration in order to access the parameter code you require.
C Configuration Set-Up Code
CXXX61
P
Pr
SE9
Pn
Code
CXXX62 P
PrA
PrB
PnA
PnB
Code
The dispenser software version (
currently loaded in the dispensers C4000.
See Dispenser Software Upgrade/Replacement (see page 64) for
instructions on Upgrading dispenser software
1. Make sure that the dispenser is idle, with the nozzle in its holster.
2. Press and release the Parameter switch once or until
The system enters a diagnostic mode whereby it displays the software
program version and performs a display segment test. It cycles through
this program for approximately 10 seconds before reverting to the
normal display.
When displaying program version data, the display panel shows
Dollars screen and XXXXX, in the Kilograms screen where XXXXX is the
abbreviated program version number. For example: Software version
29260
HIA29.26.0CNG will read
Page 20
Dispenser Set-up
Code Description
Software Program version
Unit Price
CNG Sequencing rate
FAS nOr SLO
( , , )
Hose Number
Dispenser Passcode
Software Program version
Unit Price Side A
Unit Price Side B
Hose Number Side A
Hose Number Side B
Dispenser Passcode
P)
is the version number of the software
P
www.compacngv.com
is displayed.
P
in the
